  • Page 1 FCC ID : BEJL1530TMM APPENDIX F USER’S MANUAL...
  • Page 2 User’s Guide L1530TM ake sure to read the Safety Precautions before using the product. Keep the User's Guide(CD) in an accessible place for furture reference. ee the label attached on the back cover and quote this information to your dealer when you require service.

  • Page 3: Regulatory Information

    Regulatory Information FCC Compliance Statement CE Conformity Notice (for Europe) This equipment has been tested and found to comply within Products with the “CE” Marking comply with the EMC the limits of a Class B digital device pursuant to Part 15 of Directive(89/336/EEC) and LOW VOLTAGE Directive the FCC Rules.
  • Page 4 Regulatory Information cont. scheme, which provides for international environmental Lead can be found in picture tubes, display screens, solder, labelling of personal computers. The labelling scheme was and capacitors. Lead damages the nervous system and in developed as a joint effort by the TCO (The Swedish higher doses causes lead poisoning.
  • Page 5 Regulatory Information cont. TCO99 The energy requirements include a demand that the computer and/or display, after a certain period of inactivity, shall reduce its power consumption to a lower level in one or more stages. The length of time to reactivate the computer shall be reasonable for Congratulations! the user.
  • Page 6 (U.S.A only) is a set of power-saving guidelines NERGY issued by the U.S. Environmental Protection Agency(EPA). As an ENERGY STAR Partner LG Electronics U.S.A.,Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. EPA POLLUTION PREVENTER...

  • Page 7: Table Of Contents

    Table of Contents Safety Precautions Installation Accessories Major Monitor Features Connection How to Use a Stand Connecting to a PC Using a Tablet Monitor Installing USB Tablet Manager (tablet running driver) Using a Pen Tablet Application Software Screen Selection and Adjustment Input Adjustment on the OSD (On Screen Display) Screen Selection...

  • Page 8: Safety Precautions

    Safety Precautions Please read these safety precautions carefully before using the monitor. If you ignore the warning message, you may be seriously injured or there is a possibility of Warning accident or death. Caution If you ignore the caution message, you may be slightly injured or the product may be damaged Precautions in installing the Monitor Warning Keep away from heat sources like electrical heaters.
  • Page 9 Electrical Power Related Precautions Warning Make sure to connect the power cable to the grounded current. - You may be electrocuted or injured. Use the rated voltage only. - The monitor can be damaged, or you may be electrocuted. During a thunder or lightning storm, unplug the power cable or signal cable. - You may be electrocuted or a fire can break out.
  • Page 10 Safety Precautions Caution Do not shock the monitor when moving it. - You may be electrocuted or the monitor can be damaged Do not dispose the product-packing box. Use it when you move. Make the panel face forward and hold it with both hands to move. - If you drop the monitor, the damaged monitor can cause electric shock or fire.

  • Page 11: Accessories K4

    Accessories Please check all accessories are included in the monitor. * The actual monitor and accessories may look differently than shown in this manual. Monitor Pen/Pen Content (2 ea.)/ Pen Holder Battery (1 ea.) User’s Manual 15-pin D-Sub Signal DVI-D Signal Cable CD/Cards/Software CD Cable USB Cable...

  • Page 12: Major Monitor Features

    Major Monitor Features Tablet Function The monitor’s tablet function enables you to write down a letter or draw a picture on the screen, using the electronic pen writing recognition software with a touch screen. Handwriting can also be saved as an image file, which allows intuitive use of the computer.

  • Page 13: How To Use A Stand

    How to Use a Stand Basic connection – using a stand You can adjust a stand angle by taking the following steps. Set your preferences. Make sure to hold the monitor panel with both hands when adjusting the stand angle. 20˚...
  • Page 14 How to Use a Stand You can separate a stand according to your own requirements. To separate a stand Make the front side face downward and lay the monitor on a cushion or soft cloth. Press down the ( ) button at the rear of the monitor until you can hear a click and then, pull down the stand down to separate it.

  • Page 15: Connecting To A Pc

    * When connecting to a PC AC adapter Macintosh adapter(Adapter) The adapter available in the market may not be compatible with this monitor (if the signaling system is different). Please use the standard Macintosh adapter or the one provided by LG.
  • Page 16 Connecting to a PC Connect the cables as described below Please refer to the following figure to tie up the cables. Once the cable is connected up as shown in the figure, it will be arranged properly, which facilitates stand angle adjustment. Close the back door when the connection is complete Press the Power button on the front side of the monitor to turn it on.

  • Page 17: Using A Tablet Monitor

    Using a Tablet Monitor Installing USB Tablet Manager (tablet running driver) You should install the tablet running driver before using the tablet function. First, see if the signal input cable, power cord and USB cable are connected properly. Then, install the driver as described below. The main window will be automatically displayed when you insert the software CD into your CD-ROM driver, which is included in the User’s Manual.
  • Page 18 Using a Tablet Monitor Buttons (1) Side button : You can set the function of the pen side button. By default, the upper side of the side button (Side Button 2) triggers a double click event, whereas the lower side (Side Button 1) triggers a right mouse click event.

  • Page 19: Using A Pen

    Using a Pen Name and Function of the Parts ON/OFF Button Pen Cab Side Button (Upper) Side Button (Lower) Pen Holder Pen Content [Inserting a Battery] [When Using a Pen] [When Keeping a Pen] Open the pen cab and insert the provided battery into it. Hold the pen as if you’re holding a normal pen or pencil.

  • Page 20: Tablet Application Software

    Using a Tablet Monitor Tablet Application Software Install the provided software to use a tablet monitor more usefully and in various ways. Insert the software CD-ROM included in this manual into the PC DC-ROM drive. Then, the main window will be automatically populated. Click the icon of the software to install and follow the instructions displayed on the screen.
  • Page 21 Power Presenter RE Power Presenter RE is a program designed to be used with PowerPoint presentations. It enables you to highlight the section to emphasize, or provide supplementary description using a whiteboard or blackboard. The presented picture or text can be saved as “*.jpg”, or sent to other person as an e-mail attachment.

  • Page 22: Screen Selection And Adjustment

    Screen Selection and Adjustment Name of the Buttons on the Screen Adjustment Unit Buttons at the rear side of the monitor Screen at the front side of the monitor Power LED A green LED will be displayed in a normal operation mode, or an orange LED will be displayed in a power saving mode.
  • Page 23 > < button Use this button to select the icon or make an adjustment in the OSD (On Screen Display) menu. > SOURCE button When two computers are connected, use this button to select the input signal for the destination computer. If only one computer is connected, it will be recognized automatically.

  • Page 24: Adjustment On The Osd (On Screen Display) Screen

    Screen Selection and Adjustment Adjustment on the OSD (On Screen Display) Screen Selects the Selects the icon Adjusts the status Selects the Pops up the adjustment menu icon value/Closes the OSD screen OSD screen Press the MENU button to open the OSD screen. >...
  • Page 25 OSD Adjustment Menu Main Menu Sub-menu Function Description PICTURE Brightness You can adjust screen contrast and brightness Contrast Gamma PRESET You can set the preferred screen COLOR color GREEN BLUE H POSITION You can adjust screen position POSITION V POSITION CLOCK You can adjust screen clock and TRACKING...

  • Page 26: Osd(On Screen Display) Screen Adjustment

    Screen Selection and Adjustment OSD(On Screen Display) Screen Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
  • Page 27 Main menu Sub menu Description PICTURE B R I G H T N E S S BRIGHTNESS To adjust the brightness of the screen. To adjust the contrast of the screen. CONTRAST GAMMA Set your own gamma value. : -50/0/50 On the monitor, high gamma values display whitish images and low gamma values display high contrast images.

  • Page 28: Factory Reset

    Screen Selection and Adjustment Main menu Sub menu Description TRACKING T R A C K I N G CLOCK To minimize any vertical bars or stripes visible on the screen background.The horizontal screen size will also change. PHASE To adjust the focus of the display. This item allows you to remove any horizontal noise and clear or sharpen the image of characters.

  • Page 29: Lightview

    < Press the LIGHTVIEW( ) Button, then the main menu of the OSD appears. Main menu Sub menu Description LIGHTVIEW L I G H T V I E W This feature lets you easily select the best desired NIGHT image condition optimized to the environment (ambient illumination, image types etc).

  • Page 30: Troubleshooting

    Troubleshooting The monitor is not working Power cord is properly connected to the Make sure to connect the power cord to the monitor. monitor? Power LED is on? See if the power switch is on. The power is on, the power LED is green, Adjust brightness ( ) and contrast ( ) again.
  • Page 31 When the monitor is connected, the “Unknown Monitor” message appears • Install the provided monitor driver again or download Monitor driver is installed? the driver from the LG Electronics web site (http://www.lge.co.kr). See if the plug & play function is supported by the video card by referring to the video card user’s...
  • Page 32 Troubleshooting Tablet pen is not working normally Tablet pen is not working? • See if the tablet driver (USB Tablet Manager) is properly installed. (See the page K12) • See if the USB cable is connected properly. If you have connected the USB cable again, wait until the USB tablet icon appears on the Windows Task Bar before using the pen.

  • Page 33: Product Specification

    Product Specification Product specification is subject to change without a prior notice to improve the product. LCD Panel Type 15 inch (38.0 cm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Size of Visible Diagonal Line: 38.0cm Pixel Pitch 0.297mm Video Signal Max.
  • Page 34 Product Specification PC Mode – Preset Mode Horizontal Vertical Preset mode Frequency (kHz) Frequency (Hz) 31.468 640 x 350 31.468 720 x 400 31.469 640 x 480 VESA 35.000 66.67 640 x 480 VESA 37.861 640 x 480 72.8 37.500 VESA 640 x 480 35.156...
  • Page 35 DVI-D Number Signal T.M.D.S. Data 2- T.M.D.S. Data 2+ T.M.D.S. Data 2/4 Shield T.M.D.S. Data 4- T.M.D.S. Data 4+ DDC Clock DDC Data Analog Vertical Synchronization T.M.D.S. Data 1- T.M.D.S. Data 1+ T.M.D.S. Data 1/3 Shield T.M.D.S. Data 3- T.M.D.S. Data 3+ +5V Power Groundings (return for +5V, horizontal and vertical synchronization) Hot Plug Detect...
  • Page 36 MEMO...
