- Page 1 English Operation Manual Sweeper Models Sweeper KM domus 82 V Machine no. Sweeper KM domus 82V Original Operation Manual 687.01-46-1216...
-
Page 2: Table Of Contents
English Contents Important General Information ..........................3 General ..............................3 Symbols ..............................3 Limitation of liability ..........................3 Copyright .............................. 3 Warranty ............................... 3 Safety ................................. 4 Use in compliance with intended purpose .................... 4 Possible misuse ........................... 4 General sources of risks ........................4 2.3.1 Use and operation ....................... -
Page 3: Important General Information
English Important General Information We are pleased that you have selected a machine from Cramer Symbols GmbH in Germany. Please read this Operation Manual before you use the machine DANGER ! for the first time and observe the notes and safety instructions. -
Page 4: Safety
These warning labels on the machine warn you of possible dangers Risk of electric shock. and thus help you to avoid serious injuries and damage to property. If labels have become detached or illegible, please contact your Cramer dealer to have the labels replaced. Sweeper Original Operation Manual... -
Page 5: Required Protection Equipment For Operation
English Safety devices Read and observe the Installation and Safety Instructions prior to starting the Do not remove any covers during operation. machine. Immediately remedy any damage to safety devices. Risk by flinging parts with running motor. Keep a safety distance of 3m. Behaviour in case of fire 1. -
Page 6: Operating Elements For All Models
English Operating elements for all models Lever for brush drive The left-hand lever is used to operate the sweeper brush mechanism. Operate the lever as follows: Lever activated: Brush turns Lever released (O): Deactivate brush Lever for travel drive. The right-hand lever is used to operate the sweeper drive mechanism. Operate the lever as follows: Lever pulled: Machine moves forward... - Page 7 English Charger with battery system This battery system is fitted with a diagnostic Detailed notes on safety and risks of use are contained in the enclosed Operating Instructions charger. The lithium-ion battery does not for the battery and the charger. Please read them before using the machine. Please read develop any memory effect and can be charged them before using the machine.
- Page 8 Cramer front-mounted devices (such as snow-clearing plate, sweepings container, etc.) can be mounted at the attachment points on the sweeping brushes. For a complete list of Cramer accessories, please refer to our catalogue or our homepage. Mounting accessories: Mount accessories in the provided elongated hole guide and secure them using the included R-clips.
-
Page 9: Operation
Adjust brush to the left or right in order to sweep dirt aside. 4. Stop the machine Release the travel drive lever, release the brush drive lever. Should functional failures occur, please contact your authorized Cramer dealer. Sweeper Original Operation Manual... -
Page 10: Activities After Use
• Tilt the machine as little as possible. Storage The following recommendations will help to ensure the long-standing functionality of your Cramer machines: • Do not store the machine outdoors. • Remove the battery after using and before storing the machine and check the battery for damage. -
Page 11: Maintenance
6.3 Maintenance work maintenance work requiring special tools should be performed by qualified staff, e.g. at your Cramer dealer or by a qualified mechanic. Only original parts should be used for maintenance. Spare parts should be replaced by an authorized service engineer. -
Page 12: Troubleshooting
Cramer GmbH Cramer GmbH Serial number: see cover nameplate Reimersstraße 36 Type(s): KM domus 82 V 26789 Leer complies with all relevant regulations of the above-stated Directive as Place: Leer well as all other applicable Directives - including their amendments... -
Page 13: Technical Data
English Technical data KM domus 82 V Device data Length x Width x Height, cm 135 x 71 x 110 Deadweight (transport weight), kg Drive speed, forward km/h Brush speed rpm Climbing power, max % Climbing power with accessories, max %... - Page 14 English Sweeper Original Operation Manual...
- Page 15 English Sweeper Original Operation Manual...
-
Page 16: Installation Of Sweeping Brushes, Installation Of Side Covers
English Installation of sweeping brushes, installation of side covers Safety Delivery, packaging, assembly Risk of high dead weight • The machine must not be lifted manually. • CAUTION! Pull the machine off the transporter at its handles. • Remove machine parts separately from packaging. Squeezing hazard during assembly Perform transport inspection •... - Page 17 English Left brush installation 1. Left brush 1. Left brush overview 2. Washer 3. Washer with nibs 2. Press-fit the washer with nibs (no. 1) into the hollow body recess of the left brush. Lightly hit on it as 1. Washer with nibs needed.
- Page 18 English In order to protect the environment and avoid a waste of resources, we at Cramer attempt to restrict paper consumption to the largest possible extent. For this reason, our machines are delivered inclusive of operation manuals in the national language of the relevant import country only.
- Page 19 English Sweeper Original Operation Manual...
- Page 20 English Picture similar, cover is supplied without stickers ① Weather protection cover The weather protection cover protects the motor against rain and snow. ② White snow brush The snow brushes are especially intended for use on snow. The bristles are harder than those of the comfort brush. Winter set item no.: 1.490.533 Sweeper Original Operation Manual...
