- Page 1 Operation Manual Type 05 Machine no. Models KM 80 H KM 100 H Sweeper H 690.05-60 Original Operation Manual English 01-2014...
-
Page 2: Table Of Contents
Contents Contents ................................2 Important information ..........................3 General ........................... 3 Symbols ..........................3 Limitation of liability ........................ 3 Copyright ..........................3 Warranty ..........................3 Safety ................................4 Use in compliance with intended purpose ................4 Possible misuse ........................4 General sources of risks ...................... -
Page 3: Important Information
Important information We are pleased that you have selected a machine from Symbols Cramer GmbH in Germany. Please read this Operation Manual before you use the DANGER! machine for the first time and observe the notes and This symbol cautions against an immediate safety instructions. -
Page 4: Safety
Safety • Do not refill the tank when the motor is running - danger of Use in compliance with intended purpose life by burning and explosion. The machine is approved as a sweeper for sweeping • Immediately remove spilled fuel with a cloth - danger of leaves, waste snow. -
Page 5: Safety Instructions
Safety instructions Safety devices • Do not remove any covers during operation. The operation manual and safety • Immediately remedy any damage to safety devices. instructions must be read and observed prior to starting the machine. Behaviour in case of fire Risk by flinging parts with running motor. -
Page 6: Operating Elements For All Models
Operating elements for all models 1. Turning handle for Right-hand handle for drive with continuous speed regulation drive Turn to the right: Continuously increase machine speed Turn to the left or release handle: Machine is at standstill 2. Operating lever Lever on the left for brush activation Brush speed Lever released: Brush is at standstill:... -
Page 7: Working Position And Areas Of Risk
7. Release and tilt back steering 1. Release wing bolts. The wing bolt is located on the right and left above the drive wheel bracket (for transport and storage) 2. Hold Bowden cable at the right and left of the motor block 3. -
Page 8: Delivery, Transport, Storage
Storage (long-term) Risk of high dead weight The following recommendations will help to ensure the long- standing functionality of your Cramer machines: • The machine must not be lifted manually. • Pull the machine off the transporter by its handles. -
Page 9: Operation
Operation Activities prior to use Brush settings Height setting of sweeping brush by adjusting the support Basic setting wheel: Height of sweeping brush is set • The bristles of the sweeping brushes should just touch Fuel tank is filled the ground Throttle is set to •... -
Page 10: Maintenance
Maintenance Safety DANGER ! Risk of injury by inappropriately performed maintenance work! Defective work may result in serious bodily injuries and damage to property. Make sure that you have sufficient working space. Disconnect spark plug connectors when working on the machine Place components separately. -
Page 11: Maintenance Work
Check air filter; replace if required. Check Bowden cable to motor. Fuel line clogged or water in fuel - drain line and tank and refill fuel. Notify Cramer specialist dealer. Carburettor needs readjustment. Motor becomes excessively hot. Check and fill up motor oil. -
Page 12: Technical Data
Technical data KM 80 H KM 100 H Machine data Length x Width x Height, cm 111x83x77 11x103x77 Deadweight (transport weight), kg Drive speed Forward km/h 0 - 4 0 - 4 Brush speed for dirt / snow rpm. 130 / 260... -
Page 13: Declaration Of Conformity
Serial number: see cover nameplate Type(s): KM 80 H, KM 100 H complies with all relevant regulations of the above-stated Directive as well as all other applicable Directives - including their amendments applicable at the date of this declaration. The following other EU Directives were applied:... -
Page 14: Assembly Of Sweeping Brushes
Assembly of sweeping brushes Sweeping brush installation for KM 80 H, KM 100 H Delivery, packaging, assembly Risk of high dead weight • The machine must not be lifted manually. • Pull the machine off the transporter by its handles. - Page 15 1. Left brush overview 1. Left brush Left brush 2. Washer 3. Washer with nibs 2. Press-fit the washer 1. Washer with nibs with nibs (no. 1) into 2. Washer the hollow body recess 3. Recess of the left brush. Lightly hit on it as needed.
