Summary of Contents for Cramer KM domus 82 V
- Page 1 German Operation Manual Sweeper Models Sweeper KM domus 82 V Machine no. Sweeper KM domus 82V Original Operation Manual English 687.01-46-1216...
-
Page 2: Table Of Contents
German Contents Important General Information ..........................3 General ..............................3 Symbols ..............................3 Limitation of liability ..........................3 Copyright .............................. 3 Warranty ............................... 3 Safety ................................. 4 Use in compliance with intended purpose .................... 4 Possible misuse ........................... 4 General sources of risks ........................4 2.3.1 Use and operation ....................... -
Page 3: Important General Information
German Important General Information We are pleased that you have selected a machine from Cramer Symbols GmbH in Germany. Please read this Operation Manual before you use the machine DANGER ! for the first time and observe the notes and safety instructions. -
Page 4: Safety
The battery must always be removed during repairs and and thus help you to avoid serious injuries and damage to property. maintenance. Risk of electric shocks. If labels have become detached or illegible, please contact your Cramer dealer to have the labels replaced. Sweeper Original Operation Manual... -
Page 5: Required Protection Equipment For Operation
German Safety devices The assembly and safety instructions must be read and observed prior to starting the Do not remove any covers during operation. machine. Immediately remedy any damage to safety devices. Risk by flinging parts with running motor. Keep a safety distance of 3m. -
Page 6: Operating Elements For All Models
German Operating elements for all models Lever for brush drive The left-hand lever is used to operate the sweeper brush mechanism. Operate the lever as follows: Lever activated: Brush turns Lever released (O): Brush deactivated Lever for drive operation The right-hand lever is used to operate the sweeper drive mechanism. Operate the lever as follows: Lever pulled: Machine moves forward... - Page 7 German Charger with battery system This battery system has a diagnostic charger. More detailed information on safety and dangers of use can be found in the enclosed The lithium-ion accu does not develop a memory operation manual for accu and charger Please read in advance.
- Page 8 Cramer front-mounted devices (such as snow-clearing plate, sweepings container, etc.) can be mounted at the attachment points on the sweeping brushes. For a complete list of Cramer accessories, please refer to our catalogue or our homepage. Mounting accessories: Mount accessories in the provided elongated hole guide and secure them using the included R-clips.
-
Page 9: Operation
Adjust brush on the left or right in order to sweep dirt aside. 4. Switch off the machine Release the drive lever, release the brush drive lever. Should functional failures occur, please contact your authorized Cramer dealer. Sweeper Original Operation Manual... -
Page 10: Activities After Use
• Tilt the machine as little as possible. Storage The following recommendations will help to ensure the long-standing functionality of your Cramer machines: • Do not store the machine outdoors. • Disconnect the machine after use and before storing it from the accu and check for damages. -
Page 11: Maintenance
Maintenance work maintenance work requiring special tools should be performed by qualified staff, e.g. at your Cramer dealer or by a qualified mechanic. Only original parts should be used during maintenance. The spare parts should only be replaced by an authorised service technician. -
Page 12: Troubleshooting
Cramer GmbH Reimersstraße 36 Serial number: see cover nameplate 26789 Leer Type(s): KM domus 82 V Site: Leer complies with all relevant regulations of the above-stated Directive as Date: 14/12/2016 well as all other applicable Directives - including their amendments applicable at the date of this declaration. -
Page 13: Technical Data
German Technical data KM domus 82 V Machine data Length x Width x Height, cm 135 x 71 x 110 Deadweight (transport weight), kg Drive speed, forward km/h Brush speed rpm Climbing power, max % Climbing power with accessories, max %... -
Page 14: Sweeping Brush Installation, Side Cover Installation
German Sweeping brush installation, side cover installation Safety Delivery, packaging, assembly Risk of high dead weight • The machine must not be lifted manually. • ATTENTION! Pull the machine off the transporter by its handles. • Remove machine parts separately from packaging. Squeezing hazard during assembly Perform transport inspection •... - Page 15 German Left brush installation 1. Left brush 1. Left brush overview 2. Washer 3. Washer with nibs 2. Press-fit the washer with nibs (no. 1) into the hollow body recess of the left brush. Lightly hit on it as 1. Washer with nibs needed.
- Page 16 German In order to protect the environment and avoid a waste of resources, we at Cramer attempt to restrict paper consumption to the largest possible extent. For this reason, our machines are delivered inclusive of operation manuals in the national language of the relevant import country only.
