second line.
Press button (1) to take the third measurement (for example, height). Measured value is displayed in the
second line. The volume value will be displayed in the first line.
Indirect measurement
Pythagorean measurement is used in the condition that the objective needing to be measured is covered or
has no effective reflecting surface and can't be measured directly.
Make sure you adhere to the prescribed sequence of measurement:
All target points must be in a horizontal or vertical plane.
The best results are achieved when the instrument is rotated about a fixed point (e.g. with the positioning
bracket fully folded out and the instrument placed on a wall).
Be sure that the first measurement and distance are measured at right angles.
Indirect measurement – determing a distance using 2 auxilary measurements
This function is used when height and distance can't be measured directly.
Press button (2) 3 times. The symbol "triangle" is displayed. The distance to be measured is blinking in
