Page 1: Instruction Manual
PDG4.0ZpZtRC (PGZ6310) PDG4.1ZpZtRCA (PGZ6311) PDG5.0ZpZtRCA (PGZ7311) INSTRUCTION MANUAL Sticker with serial number of appliance... -
Page 2: Dear Customer
DEAR CUSTOMER, Thank you for your purchase of an Amica gas hob; we hope you enjoy many years of use from our product. We would ask that you take the time to read through this handbook, even if you have used a gas hob in the past, so that you are familiar with its operation, features and maintenance to ensure the best and most efficient possible use of your hob. -
Page 3: Table Of Contents
TABLE OF CONTENTS GENERAL SAFETY ........................4 WHAT TO DO IF YOU SMELL GAS .................... 5 UNPACKING ........................6 SAFE DISPOSAL ......................6 OVERVIEW OF THE HOB ....................7 INSTALLATION ........................10 OPERATION ........................16 CLEANING AND ROUTINE MAINTENANCE ..............20 TROUBLESHOOTING ..................... -
Page 4: General Safety
GENERAL SAFETY Your safety and that of your family are of the utmost importance to us and although some simple safety when cooking is generally observed it is worth reading through the following points to ensure that your hob is operated as safely as possible at all times to prevent any accidents. -
Page 5: What To Do If You Smell Gas
WHAT TO DO IF YOU SMELL GAS If you smell gas then please follow the points below for your immediate safety. All our gas appliances are checked for gas soundness before they leave our factory and it is extremely rare that one of our products will leak gas. Before calling our service department please ensure that there is a fault with the product as any faults with other gas appliances that you may have or improper installation are not covered by our warranty and any visit may be chargeable to you. -
Page 6: Unpacking
UNPACKING During transportation, protective packaging was used to protect the applian- ce against any damage. After unpacking, please dispose of all elements of packaging in a way that will not cause damage to the environment. All materials used for packaging the appliance are environmentally friendly; they are 100% recyclable and are marked with the appropriate symbol. -
Page 7: Overview Of The Hob
OVERVIEW OF HOB MODEL PDG4.0ZpZtRC 1,2,3 - surface burners 4 - surface burner knobs 5 - pan stand Fig.1 TECHNICAL DATA height 90 mm depth 520 mm width 590 mm weight of the hob 11,6 kg The cooker is equipped with burners: 1 - large burner, output - 2,4 kW 2 - small burner, output... - Page 8 OVERVIEW OF HOB MODEL PDG4.1ZpZtRCA 1,2,3 - surface burners 4 - surface burner knobs 5 - pan stand Fig.2 TECHNICAL DATA height 90 mm depth 520 mm width 590 mm weight of the hob 11,8 kg The cooker is equipped with burners: 1 - WOK burner, output - 2,8 kW 2 - small burner, output...
- Page 9 OVERVIEW OF HOB MODEL PDG5.0ZpZtRCA 1,2,3,4 - surface burners 5 - surface burner knobs 6 - pan stand Fig.3 TECHNICAL DATA height 90 mm depth 520 mm width 790 mm weight of the hob 16,1 kg The cooker is equipped with burners: 1 - WOK burner, output - 2,8 kW 2 - small burner, output...
-
Page 10: Installation
INSTALLATION Installation work and repairs should only be performed by a Gas Safe qualified technician in accordance with all applicable codes and standards. Repairs and service by unqualified persons could be dangerous or incorrect and are not covered by your warranty. Correct in- stallation is absolutely vital for safe operation of this appliance. - Page 11 Fixing the brackets to the work top Fig. 4 1. Work top 2. 4 screws 3. 4 fixing brackets 4. Installed appliance Installation in kitchen furniture Fig. 5 For models: For models: PDG5.0ZpZtRCA (PGZ7311) PDG4.0ZpZtRC (PGZ6310) PDG4.1ZpZtRCA (PGZ6311)
- Page 12 INSTALLATION Notes for the installer: The fitter should: • Bear a valid certificate of Gas Safe Registration • Have studied the contents of the appliance’s type plate containing the suitable type of gas. Compare the data with the characteristics of the gas available in the supply.
- Page 13 INSTALLATION Please make sure you have read and understood the entire operating manual. Do follow the instructions to ensure safe and effective operation of your cooktop. NOTE The appliance uses gas, which is a flammable and explosive substance. Thus, it is necessary for the cooktop to be connected to a gas network which supplies the gas type for which the appliance is suitable.
- Page 14 INSTALLATION Replacement of burner nozzle: loosen the nozzle with a dedicated wrench (7). Fit the new nozzle, suitable for the required gas type (see table above for reference). After you have converted the cooktop to another gas type, make sure you have placed a label containing that information on the appliance.
- Page 15 INSTALLATION Valve adjustment Valve adjustment should be done with the control knob set at Burner ON saving flame po- sition. Remove the knob, and adjust the flame with a tiny screwdriver (see fig. 7 below). Fig. 7 Checking the adjusted flame: heat the burner at full open position for 10 minutes. Then turn the knob into the saving setting.
-
Page 16: Operation
OPERATION Flame selection If the burners are adjusted correctly, the flames should be light blue, and the inner cone should be clearly visible. The size of flame depends on the position of the related burner control knob. Fig. 8 - Burner ON, large flame - Burner ON, small flame (saving mode) -
Page 17: Suitable Pans
OPERATION You can save significant quantities of energy if the appliance is used correctly, parameters set correctly, and appropriate cookware is used. The savings can be as follows: • Up to 60 per cent savings when proper pots are used, •... - Page 18 Using cooktops with leak protection (Zt) spark igniter protection For your safety all Amica gas hob models are fitted with safety thermocouples. The purpose of a thermocouple is to switch off the gas supply to the burner where no flame is detected.
- Page 19 OPERATION What to do if surplus gas leak occurs 1 – gas network 2 – gas cut off valve A – valve ON B – valve OFF Fig.9 In any emergency, proceed as follows: • turn the burners off • set the cut off valve OFF (see fig.
-
Page 20: Cleaning And Routine Maintenance
CLEANING AND ROUTINE MAINTENANCE For gas on glass models: Daily cleaning and proper maintenance have crucial impact on the durability of your ceramic plate. Clean the ceramic plate observing the same rules as for glass. Never use abrasive or aggressive clean- ing agents, scrubbing powders or scratching sponges. -
Page 21: Troubleshooting
TROUBLESHOOTING In each case, proceed as follows: • Turn the burners off • Disconnect power supply • Report for repair • The user can fix some minor malfunctions himself, according to the guidance given in the tables below. Please check the information below before contacting the service depart- ment. - Page 22 Amica Wronki S.A. ul.Mickiewicza 52 64-510 Wronki tel. 067 25 46 100 fax 067 25 40 320 www.amica.com.pl...
- Page 24 Service Help Line 0844 815 8880 For the UK: please call 0818 46 46 46 For Ireland: please call IO 00450/7 (07.2015)
