BATTERY CHARGER – 1202S CHARGER
This charger is a solid-state battery charger designed to charge
your 12-volt battery and maintain and hold it to a full charge.
This charger will keep your battery fully charged and will
never over charge your battery.
The conventional linear battery charger is an electrical device
whereas; the 1202S is a light weight sophisticated electronic
device. Most battery chargers use linear technology which
converts the 115VAC to 12VDC at 60Hz. This requires a large
transformer which has the disadvantage of lower efficiency,
larger size and weight resulting in higher heat generation.
The 1202S battery charger transforms the 115VAC into
12VDC at about 100,000 Hz (1667 times faster than
conventional chargers), which requires a much smaller
transformer and this results in a unit of smaller size, low
weight and improved efficiency.
Operating Instructions
1. Connect the charger to the battery.
2. Connect the charger to an AC outlet. The Green LED will
turn Orange.
3. When the LED is Orange your battery is charging.
4. When the LED turns Green your battery is fully charged.
Remember, you can leave your charger on after the battery
is fully charged.
IMPORTANT SAFETY INSTRUCTIONS
1. Before using any battery charger, read all instructions and
caution warnings on the battery you are charging, and the
item the battery is being used in.
Page 13
