  • Page 1 FiDO Series SDI/Optical Fiber Mini-Converters Installation and Operation Guide Version 1.1 Published May 31, 2017...
  • Page 2: Notices

    AJA® and Because it matters.® are registered trademarks of AJA Video Systems, Inc. for use with most AJA products. AJA™ is a trademark of AJA Video Systems, Inc. for use with recorder, router, software and camera products. Because it matters.™ is a trademark of AJA Video Systems, Inc.
  • Page 3: Table Of Contents

    Copyright ..........2 Contacting AJA Support ........2 Chapter 1 –...
  • Page 4: Chapter 1 - Introduction

    • Five Year warranty Single-Mode FiDO Models (1310 nm) • FiDO-TR: Single channel SDI/LC fiber transceiver • FiDO-T: Single channel SDI to LC fiber converter with looping SDI output • FiDO-R: Single channel LC fiber to SDI converter with dual SDI outputs •...
  • Page 5: Accessories

    FiDO Models with Single-Mode CWDM and Multi- Mode SFP Options When selecting a FiDO model with single-mode CWDM or multi-mode SFP options, use the AJA SFP Configurator on the AJA website (https://www.aja.com/ config) to correctly match FiDO model cases with compatible SFPs.
  • Page 6: Fido Converter Simplified Block Diagrams

    FiDO Converter Simplified Block Diagrams FiDO-TR and FiDO-TR-X (Multi-Mode) Optical 3G-SDI Optical Equalize & Fiber Receiver Reclock Output Input Optical 3G-SDI Optical Equalize & Fiber Input Reclock Receiver FiDO-T, FiDO-T-SC, FiDO-T-ST, and FiDO-T-X (Multi-Mode) 3G-SDI Optical Equalize & Optical Transmitter...
  • Page 7: Fido Converter I/O Connections

    Reclocked (ST connector) loop-thru of SDI input 3G-SDI Output simplex connection Second SDI (LC connector) Output (DA: same signal) 3G-SDI Output simplex connection Second SDI (SC connector) Output (DA: same signal) FiDO Series SDI/Optical Fiber Mini-Converters v1.1 www.aja.com...
  • Page 8 2 simplex Channels of 1 duplex 3G-SDI connection (LC connector) 2 Independent 2 simplex Channels of 3G-SDI 1 duplex connection (LC connector) 2 Independent 2 simplex Channels of 1 duplex 3G-SDI connection (LC connector) FiDO Series SDI/Optical Fiber Mini-Converters v1.1 www.aja.com...
  • Page 9 Single 4K Input or 4 simplex 4 Independent Channels connections (ST connectors) of 3G-SDI Input Single 4K Output or 4 simplex 4 Independent Channels connections of 3G-SDI Output (ST connectors) FiDO Series SDI/Optical Fiber Mini-Converters v1.1 www.aja.com...
  • Page 10: Installation

    NOTE: The OPT or LOCK indicator for optical receivers may flicker or glow dim with the optical input disconnected. Installation NOTE: AJA does not support use of any SFP modules other than our own; use of any non- AJA SFP module will void the warranty. Installation consists of the following steps: 1.
  • Page 11 (FiDO-T-ST, FiDO-R-ST, FiDO-4T-ST, FiDO-4R-ST. Figure 3. ST Style Optical Fiber Connector 5. FiDO-TR, FiDO-2T, and FiDO-2R all require either a duplex LC cable or two simplex LC cables. Insert each connector until it latches. Figure 4. FiDO to Duplex LC Example 6.
  • Page 12: Operation

    5-20 VDC SDI input SD/HD/3G SDI TO OPTICAL FIBER 7. Apply +5VDC power to the converter (AJA power supply included). Operation FiDO series converters have no user controls. No configuration or settings are required. Once powered, the FiDO converters will begin converting applied fiber/ SDI signals.
  • Page 13: Appendix A - Specifications

    • 2x BNC, 1x Single mode optical fiber, SC connector FiDO-T-ST, FiDO-R-ST: • 2x BNC, 1x Single mode optical fiber, ST connector FiDO-TR, FiDO-2T, FiDO-2TR: • 2x BNC, 2x Single mode optical fiber, LC connectors FiDO-4T-ST, FiDO-4R-ST: • 4x BNC, 4x Single mode optical fiber, ST connectors FiDO-4T, FiDO-4R: •...
  • Page 14 FiDO-4T-ST, FiDO-4R-ST, FiDO-4T, FiDO-4R: • +5 to 20V DC regulated, 4 watts max Size (w x d x h) FiDO-T, FiDO-R (all models), FiDO-TR, FiDO-2T, FiDO-2T-CWDM, FiDO-2R: • 4.6" x 1.71" x 0.8" (117 x 43.5 x 20 mm) FiDO-4T-ST, FiDO-4R-ST, FiDO-4T, FiDO-4R: •...
  • Page 15 Safe Storage Temperature (Power OFF): • -40 to 60 degrees C (-40 to 140 degrees F) FiDO Series SDI/Optical Fiber Mini-Converters v1.1 www.aja.com...
  • Page 16: Appendix B - Safety And Compliance

    AUSTRIA, BELGIUM, BULGARIA, CYPRUS, CZECH REPUBLIC, DENMARK, ESTONIA, FINLAND, FRANCE, GERMANY, GREECE, HUNGARY, IRELAND, ITALY, LATVIA, LITHUANIA, LUXEMBOURG, MALTA, NETHERLANDS, POLAND, PORTUGAL, ROMANIA, SLOVAKIA, SLOVENIA, SPAIN, SWEDEN, UNITED KINGDOM, ICELAND, LICHTENSTEIN, NORWAY, SWITZERLAND FiDO Series SDI/Optical Fiber Mini-Converters v1.1 www.aja.com...
  • Page 17: Korea Kcc Compliance Statement

    As an electromagnetic wave equipment for office use (Class A), (Broadcasting Communication this equipment is intended to use in other than home area. Equipment for Office Use) Sellers or users need to take note of this. FiDO Series SDI/Optical Fiber Mini-Converters v1.1 www.aja.com...
  • Page 18: Taiwan Compliance Statement

    Aviso! Leia e siga todos os avisos e instruções assinalados no produto ou incluídos na documentação. Avviso! Leggere e seguire tutti gli avvisi e le istruzioni presenti sul prodotto o inclusi nella documentazione. FiDO Series SDI/Optical Fiber Mini-Converters v1.1 www.aja.com...
  • Page 19 (incluindo amplificadores) que produzam calor. Avviso! Non installare vicino a fonti di calore come termosifoni, diffusori di aria calda, stufe o altri apparecchi (amplificatori compresi) che emettono calore FiDO Series SDI/Optical Fiber Mini-Converters v1.1 www.aja.com...
  • Page 20 Aviso! Dado que a ficha principal é utilizada como a desconexão para o dispositivo, esta deve manter-se prontamente acessível e funcional. Avviso! Poiché il cavo di alimentazione viene usato come dispositivo di sconnessione, deve rimane prontamente accessibile e operabile. FiDO Series SDI/Optical Fiber Mini-Converters v1.1 www.aja.com...
  • Page 21 Aviso! Desconecte este dispositivo da tomada durante trovoadas ou quando não é utilizado durante longos períodos de tempo. Avviso! Utilizzare soltanto i collegamenti e gli accessori specificati e/o venduti dal produttore, quali il treppiedi e l'esoscheletro. FiDO Series SDI/Optical Fiber Mini-Converters v1.1 www.aja.com...
  • Page 22 Advertência! Não abra o chassi. Não há internamente nenhuma peça que permita manutenção pelo usuário. Abrir o chassi anula a garantia, a menos que a abertura seja realizada por uma central de serviços da AJA ou por um local autorizado. Avvertenza! Non aprire lo chassis. All’interno non ci sono parti riparabili dall’utente.
  • Page 23 ¡Advertencia! Los cables de fibra óptica activos emiten radiación invisible al ojo humano. No mire directamente hacia el extremo de un cable de fibra óptica activo o hacia el conector de fibra óptica del FiDO-TR, FiDO-T, FiDO-2T, FiDO-4T- ST, FiDO-T-SC, or FiDO-T-ST; estos modelos están clasificados como Productos Láser Clase 1.
  • Page 24: Warranty Information

    Video parts or supplies, or d) to service a product that has been modified or integrated with other products when the effect of such a modification or integration increases the time or difficulty of servicing the product.
