- Page 1 ProScale™ Model 150 Model 250 User’s Manual for: ProScale Model 150 & 250 Systems using: LCD Digital Displays Firmware V2.1x and Higher Firmware V2.2xC and Higher Manual Revision H, 5-2006...
- Page 2 WARRANTY Accurate Technology, Inc., warrants the ProScale Model 150 and Model 250 against defective parts and workmanship for 3 years commencing from the date of original purchase. Upon notification of a defect, Accurate Technology, Inc., shall have the option to repair or replace any defective part.
-
Page 3: Fcc Notice
FCC NOTICE This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: Table Of Contents
Panel Mount, Basic, Battery............13 Panel Mount, General Purpose, Battery..........13 Panel Mount, Basic, 24VDC............13 Panel Mount, General Purpose, 24VDC..........14 Other Displays..................15 SECTION 2 MODEL 150 & MODEL 250 ..........16 150 ................16 CALE ODEL Scale & ReadHead Installation ............16 250 ................19 CALE ODEL Scale &... - Page 5 SECTION 4 DISPLAY OPERATION............27 LCD....................27 ..................27 ROGRAMMING Programming Parameters ..............28 Primary Key Functions ..............33 ON/OFF ..................33 MODE ..................33 +, 0, and – Keys ................34 Auxiliary Keypad Functions ...............34 ABS - INC..................34 MONitor..................35 HOLD...................35 SEND...................36 F1 / F2..................36 Display Functions ................37 Lock Mode..................37 Segment Offset Adjustment ............37 Offset Addition ................37...
-
Page 6: General Information
(SPC, RS232, RS485) and/or digital accuracy and repeatability is desired. What This Manual Includes This manual includes information for ProScale Model 150 and Model 250 measurement systems with LCD Digital Displays using: • Firmware V2.1x and higher. -
Page 7: Product Specifications
Product Specifications Measuring Range*: Model 150: 2 Standard Sizes: 0-250mm (10in) and 0-450mm (18in) Model 250: 7 Standard Sizes: 0 to 300mm, 600mm, 1.3m, 2.4m, 3.0m, 3.6m, 6.0m (0 to 12in, 24in, 52in, 96in, 120in, 144in, 240in) Accuracy: + (.025 + .064 x L / 430) mm;... -
Page 8: Proscale Terminology
SCALE consists of a series of conductive patterns bonded to an aluminum extrusion. The Model 150 Scale is .765 inches (19mm) wide and comes in standard lengths of 14.25 inches (362mm) and 22.25 inches (565mm) to measure 10 inches (250mm) and 18 inches (450mm) respectively. -
Page 9: Incremental
ReadHeads and Scales of different technologies are not compatible. Incremental Scales have a repeating “bar” pattern on a colored laminate. Incremental Scale All ProScale Model 150 and Model 250 Systems Use Absolute (ABS) parts. Absolute and Incremental Scales are not interchangeable. See Section 7: for Scale Part Number information. -
Page 10: Readheads
Standard Incremental ReadHead is supplied with a 300mm (12in) cable. Part #: 701-1500-N12 (last 3 digits indicate cable length in inches) All ProScale Model 150 and Model 250 Systems Use Absolute (ABS) parts. Absolute and Incremental ReadHeads are not interchangeable. -
Page 11: Displays
Displays ProScale Model 150 and 250 measuring Systems can operate with any of several different Displays (sometimes referred to as Digital Readouts). This manual covers the operation of the General Purpose LCD (Liquid Crystal Display) Displays. Other available Displays are mentioned in this section, and other data acquisition accessories are mentioned in Section 6 of this manual. -
Page 12: Surface Mount Lcd Displays
RF transmitter that allows data to be sent wirelessly to a ProScale-RF receiver (Part # 700- 1036-xxx) which has an RS232 output. (See Section 4: for important battery UMPERS configuration information) Part Number: 700-1600-250 Accurate Technology ProScale Page 12 of 48... -
Page 13: Panel Mount Lcd Displays
Panel Mount LCD Displays The Panel Mount LCD Display for panel and enclosure mounting applications is a perfect choice for manufacturers or OEMs that desire the “built in” appearance for the digital measuring system. This Display comes in three versions, all designed to fit a ¼ DIN (90mm x 90mm, 3.5in x 3.5in) panel opening. -
Page 14: Panel Mount, General Purpose, 24Vdc
Panel Mount, Battery 701-1570-001 700-1600-400 Panel Mount, 24VDC 701-1560-001 700-1600-300 Panel Mount, Battery 701-1525-00x 700-1600-400 Panel Mount, 24VDC 701-1550-00x 700-1600-300 Incremental 701-2000-002 700-1600-025 Incremental 701-1495-002 700-1600-025 (Where ‘x’ denotes any number from 0-4.) Accurate Technology ProScale Page 14 of 48... -
Page 15: Other Displays
Other Displays ProScale Model 150 and 250 systems can also be configured with any of the following Displays. Operation of these Displays is covered in their own respective manuals. 1/8 DIN Panel Mount Readout: Inches, MM (no fractions) Output: RS485 Output... -
Page 16: Model 150 & Model 250
Scale simultaneously. Scale & ReadHead Installation ProScale Model 150 is easy to install. By following the basics of good installation, reliable, error-free operation can be expected. ProScale M150 can be used in many different measurement applications, and with numerous types and brands of equipment. - Page 17 ReadHead will simplify the process.) Determine an appropriate mounting location. Most applications of the Model 150 will have the ReadHead held stationary while the Scale is passed through the ReadHead. The ProScale will also operate properly if the ReadHead is moved along the Scale (see figures on next page).
- Page 18 Do not drill through the green portion of the Scale at any point over which the ReadHead will travel. • Do not mount the Scale so the mounting hardware interferes with the movement of the ReadHead. Typical Model 150 Installations Moving Part Connector Link Readhead Scale...
-
Page 19: Proscale Model 250
ProScale Model 250 ProScale Model 250 shown with Panel Mount General Purpose LCD Display ProScale Model 250 is a general purpose measuring system with seven standard measuring ranges from 0-300mm (12in.) up to 0-6m (20ft.). Model 250 systems use Absolute (ABS) style Scales, Absolute (ABS) style ReadHeads, and any of several available Displays. - Page 20 Do not drill through the green portion of the Scale at any point over which the ReadHead will travel. • Do not mount the Scale so the mounting hardware interferes with the movement of the ReadHead. Accurate Technology ProScale Page 20 of 48...
- Page 21 Typical Model 250 Installation M o vin g P a rt G u id e C lip R e a d h e a d M o d e l 2 5 0 S ca le G u i d e C li p R e a d h e a d 2 1 .
-
Page 22: Display Installation
3mm (0.125") and 20mm (0.750") between the front and rear Display cover. NOTE: If Panel is thinner than 3mm (0.125 in), shorter screws must be used for the Display casing or damage to the front cover of the Display will occur. Accurate Technology ProScale Page 22 of 48... -
Page 23: Calibration/Maintenance
ECTION ALIBRATION AINTENANCE Calibration The accuracy of the ProScale system is dependent on the manufacturing of the Scale. Since the Scale is passive, there are no calibration adjustments available or necessary. The Displays have a built-in “scaling factor” that allows correction for slight linear inaccuracies that may be observed once ProScale has been installed in your application. -
Page 24: Compensation Calibration
5 inches until the maximum measuring range has been achieved. After the last standard distance has been digitized, press the F2 key. The display will momentarily show “ ” indicating that the calibration process has ended. Accurate Technology ProScale Page 24 of 48... -
Page 25: Maintenance
To disable compensation mode, change Pr 27 to 0. This does not erase the compensation table stored in memory. Changing Pr 27 to 1 will re-enable the previously stored compensation. Note: Defaulting the display back to factory settings does not erase the compensation table. -
Page 26: Changing The Batteries
THESE CLIPS ARE DESIGNED TO BE LOOSE WHEN THE CASE IS OPEN AND WILL COMPRESS AND SECURE THE BATTERIES IN PLACE WHEN THE CASES ARE SCREWED TOGETHER. Panel Mount Displays: Remove and replace the 2 D Alkaline batteries noting proper orientation. Accurate Technology ProScale Page 26 of 48... -
Page 27: Display Operation
ECTION ISPLAY PERATION This section covers the programming and operation of ProScale Surface Mount and Panel Mount LCD Displays Firmware* V2.1 and higher. If your Display Firmware is prior to 2.1, or your Display is different than the Displays described here, you must use the appropriate user manual for that Display. * (F/W version is displayed on power-up or when ON/OFF key is pressed.) The LCD The above figure illustrates all the segments available on the Display. -
Page 28: Programming Parameters
MODE of the Display to mm or cm. (ie. If 5.00(in) is set, when the Display is switched to mm the programmed offset/limit is now 127mm.) Accurate Technology ProScale Page 28 of 48... - Page 29 – Reading Direction [0,1] Change/Reverse the direction (+ vs -) of readings. Pr1 – Enable/Disable Segment Offset [0, 1] 0 = For ALL Incremental Scales 1 = For All ABSOLUTE Scales Pr2 – High Speed ReadHead [0, 1] 0 = Normal ReadHead 1 = High Speed ReadHead Use only if instructed.
- Page 30 When offset 4 is selected (see Section 4: FFSET DD ITION this value is added to the current ABS position and displayed. Only active if Pr10 is set to 1. Default is set in Inches. Accurate Technology ProScale Page 30 of 48...
- Page 31 Pr14 – Output Signal Mode [0, 1, 2] Configures the hardware output signal for activation on MONitor drift conditions or Upper/Lower limit alarm conditions. Applies to 24VDC Displays only. SEE Pr15, Pr16, Pr17 ALSO 0 = Off 1 = Monitor Drift 2 = Upper/Lower Limit Pr15 –...
- Page 32 The default is 5 inches. If some other multiple (length) is used, change this value to match the multiple (length). i.e. 6”. * Pr27 and Pr28 are operational ONLY on Displays with Firmware versions ending in “C” Accurate Technology ProScale Page 32 of 48...
-
Page 33: Primary Key Functions
Primary Key Functions ON/OFF Momentarily pressing the ON/OFF key will cause the Display to turn on or off. The Firmware Version is momentarily displayed on power-up. While on, if no key presses or positional changes occur within 15 minutes*, the Display will automatically turn itself off to conserve battery life. -
Page 34: 0, And - Keys
Mode – While in the INC mode, the INC symbol is shown in the upper left corner of the Display. When the INC mode is initially entered, the displayed position will change to reflect a new reference point at the current Accurate Technology ProScale Page 34 of 48... -
Page 35: Monitor
position of the ReadHead. This is typically a position of zero (0) but may be changed by using the keys to provide an offset. Moving the ReadHead in either direction will display the distance moved from the initial INC starting point (plus any offset). -
Page 36: Send
The batteries in the ProScale WIRELESS Display can provide approximately 50,000 data transmissions before needing replacement. F1 / F2 F1 is used for OFFSET ADDITION F2 is only used on ProScale WIRELESS Displays to DELETE the last measurement sent. Accurate Technology ProScale Page 36 of 48... -
Page 37: Display Functions
Display Functions Lock Mode The user can “lock-out” the position offset adjustment functions (+, 0, - keys) to prevent accidental changes of the current displayed position. To activate the lock mode, press and hold the ON/OFF key and then momentarily press MODE key. -
Page 38: Limit Mode
Pr14 should be set to 1. Caution: These functions are active during Programming. If parameters are changed during Programming the output signal could become active immediately! (Programming Parameters 14 and 15) Accurate Technology ProScale Page 38 of 48... -
Page 39: 24Vdc Display Operation
24VDC Display Operation The 24VDC Displays have some additional functions that are not available on battery powered Displays. The same connector that is used for power is also used for the output signals. See below: 24VDC Displays are designed to run on DC voltage ONLY. DO NOT ATTEMPT TO OPERATE THESE DISPLAYS with AC VOLTAGE! COMMON GROUND SIGNAL OUTPUT... -
Page 40: Jumpers
24VDC Displays are not compatible with INCremental systems. Battery Selection 1.5v Alkaline Battery: jumper must be placed across B pins 3.6V Lithium Battery: jumpers must be placed across A-B and B-C (see also JP2) Accurate Technology ProScale Page 40 of 48... -
Page 41: Panel Mount Displays
Panel Mount Displays Panel Mount Display Circuit Board JP1 & JP2 Display Power These jumpers set the Display to operate on either 2 D batteries or 24VDC. To configure the Display to operate on 24VDC power JP1 JP2 should be set to position A. THEY MUST BE SET ON THE SAME SETTING TO AVOID DAMAGE To configure the Display to operate on battery power JP1 JP2 should... -
Page 42: Quick References
Circuit Board Jumpers THIS Surface Mount Panel Mount SYSTEM Jumper Displays Displays Factory Use Battery or 24VDC Encoder/Battery Type Battery or 24VDC Programming Enable Programming Enable Battery or 24VDC Factory Use Battery Selection Accurate Technology ProScale Page 42 of 48... -
Page 43: Programming Summary
Programming Summary Factory THIS SYSTEM Parameter Function Default Reading Direction ______ Segment Offset 1 - On ______ High Speed ReadHead 0 - Off ______ Zero, Offset Entry 1 - Enable ______ Display Resolution 1 - Normal ______ mm or cm 0 - mm ______ Fractions, mm, in... -
Page 44: Key Press Function Summary
(Momentarily) while displaying a Programming Parameter RESULT: Increases Programming Parameter setting. (Momentarily) while displaying a Programming Parameter RESULT: Decreases Programming Parameter setting. (Momentarily) while displaying a Programming Parameter RESULT: Sets Programming Parameter to Default. Accurate Technology ProScale Page 44 of 48... -
Page 45: Section 5 Miscellaneous
ECTION ISCELLANEOUS Frequently Asked Questions What does “no Enc” mean? If the ReadHead is off the Scale, or the ReadHead cable is unplugged from the Display, a “no Enc” will appear on the Display. To clear error: Be sure the ReadHead is on the Scale and properly oriented. Unplug the connector from the Display for one second. -
Page 46: Accessories
ProScale linear measurement system. The AIU provides a DC signal range from 0 to 5 volts or 0 to 10 volts. Accurate Technology ProScale Page 46 of 48... -
Page 47: Spare Parts
ECTION PARE ARTS Description Part # Description / Use + ,,-. / ,,-0 0 , . 1 ,#0 1 , + ,,-. / ,,-0 ,, . 1 ,#0 1 , + ,,-. / ,,-0 ,1 . 1 ,#0 1 , 0 3 4 ! + ,,-. - Page 48 This manual is available at www.proscale.com Please return your Product Registration Card or register your system at: www.proscale.com/registration.htm P/N 800-1097-001, Revision H, 5-2006 Copyright © 2003-2006, Accurate Technology, Inc. All rights reserved. Accurate Technology ProScale Page 48 of 48...
