Tektronix TDS7054 Service Manual page 250

Mechanical Parts List
Replaceable Parts List (Cont.)
Fig. &
Tektronix part Serial no.
index
number effective
number
- - 23 119- - 5728- - 01 B010100
119- - 5728- - 01 B010100
119- - 6691- - 00 B030000
119- - 6691- - 00 B040000
- - 24 211- - 1070- - 00
- - 25 441- - 2184- - 00 B010100
441- - 2184- - 00 B010100
441- - 2279- - 00 B030100
441- - 2279- - 00 B040100
- - 26 211- - 0720- - 00
- - 27 156- - 4828- - 00 B010100
156- - 9074- - 00 B040100
10- 10
Serial no.
discont'd
Qty Name & description
B029999 1 DISK DRIVE:OPTICAL,644MB,CD- - ROM,16.7 MB/SEC
(TDS7054)
B039999 1 DISK DRIVE:OPTICAL,644MB,CD- - ROM,16.7 MB/SEC
(TDS7104)
1 DISK DRIVE:644MEG,CD- - RW,16.6 MB/SEC,IDE/ATAPI
(TDS7054)
1 DISK DRIVE:644MEG,CD- - RW,16.6 MB/SEC,IDE/ATAPI
(TDS7104)
4 SCREW:M2 X 2MM,PNH,PHL, STL NI PLT
B029999 1 CHASSIS,NLX:ALUMINUM,W/HARDWARE (TDS7054)
B039999 1 CHASSIS,NLX:ALUMINUM,W/HARDWARE (TDS7104)
1 CHASSIS,NLX:ALUMINUM,W/HARDWARE (TDS7054)
1 CHASSIS,NLX:ALUMINUM,W/HARDWARE (TDS7104)
5 SCR,ASSEM WSHR:6- - 32,0.500,PNH,STL,CDPL,T- - 15
B039999 1 IC,MEMORY:CMOS,SDRAM,16MEG X 64, SYNC,
UNBUFFERED,3.3V,MC- - 4516CD646- - A10,DIMM168
2 IC,MEMORY; CMOS,DRAM;32MEG X 64,256MEG,
SDRAM,PC100;MT16LSDT3264AG- - 10E,DIMM168
Mfr.
code
50356
50356
50356
50356
0KB01
TK1943 441- - 2184- - 00
TK1943 441- - 2184- - 00
TK1943 441- - 2279- - 00
TK1943 441- - 2279- - 00
0KB01
S5769
6Y440
TDS7104 & TDS7054 Service Manual
Mfr. part number
CD- - 224E- - 903
CD- - 224E- - 903
CD- - W28E- - 93
CD- - W28E- - 93
211- - 1070- - 00
ORDER BY
DESCRIPTION
MC-4516CD646-A10
MT16LSDT3264AG- -
10EB1
