Kett PB-3103 Operating Manual

Grain&tapioca moisture tester
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Grain&Tapioca Moisture Tester PB-3103
Operating Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB-3103 and is the answer not in the manual?

Questions and answers

Related Manuals for Kett PB-3103

Summary of Contents for Kett PB-3103

  • Page 1 Grain&Tapioca Moisture Tester PB-3103 Operating Manual...

  • Page 3: Table Of Contents

    CONTENTS 1. Part Names ....................4 <Main Unit>..................... 4 <Switches> ..................... 5 <Accessories> ....................5 2. Specifications ....................6 3. Before Making Measurements ..............7 4. Sample Taking and Crushing ................ 8 A. Paddy, Milled Rice, Parboiled Rice, ParboiledPaddy, Tapioca Pellet ..9 B. Tapioca Flour ....................10 5. Measurements ....................

  • Page 4: Part Names

    1. Part Names <Main Unit> Measurement lever fixing magnet Fixes the measurement lever to prevent the lever from moving at carrying. Accessories comartment Stores the accessories ① to ⑥ (refer to the right page for the accessories). Disply Printer connector Measuring section (back) Measurement lever Power switch...

  • Page 5: Switches

    <Switches> <Accessories> Grain&Tapioca Moisture Tester PB-3103 Operating Manual ①Metal plate ②Sampledish ③Checker ④Measuring Spoon ⑤Crushing Handle ⑥Brush ⑦Spiral Brush ⑧ Batteries ⑨Power cord ⑩Operating manual (1.5 V Alkaline “D” size, x4) These accessories are stored in the accessories compartment on the This code is stored in the power cord top part of the main unit.

  • Page 6: Specifications

    2. Specifications Measurement Format : AC Resistance Format Applications : Paddy, Milled Rice, Parboiled Rice, Parboiled Paddy, Tapioca Pellet, Tapioca Flour Measurement Range : Paddy 11~35% Milled Rice 11~20% Parboiled Rice 6~22% Parboiled Paddy 6~30% Tapioca Pellet 6~30% Tapioca Flour 6~30% Accuracy : ±0.1%(manufacture), ±0.5%(drying method)

  • Page 7: Before Making Measurements

    1. Please use a AC220V power supply or Batteries (1.5 V Alkaline “D” size, x4) as the power supply for the PB-3103. If characters on the display are too dark or light, perform contrast adjustment (see page 12).

  • Page 8: Sample Taking And Crushing

    4. Sample Taking and Crushing The method of sample taking and crushing depends on the products. <Notes concerning taking of samples> • The sample amount must be one level of the supplied measurement spoon without fail. • When taking samples, extract por tions which are Jast a spoonfull believed to have moisture contents representative of the average for the entire quantity of cereal.

  • Page 9: Paddy, Milled Rice, Parboiled Rice, Parboiledpaddy, Tapioca Pellet

    A. Paddy, Milled Rice, Parboiled Rice, Parboiled Paddy, Tapioca Pellet 1. I n s e r t t h e s a m p l e d i s h i n to t h e s a m p l e p o r t 4. Turn the crushing handle to crush the sample. completely so that the front edge comes into contact with the back of the port.

  • Page 10: Tapioca Flour

    B. Tapioca Flour 1. Fill to the top of the supplied measurement spoon with the sample and level off the spoon. (Remove the excess sample using a pencil or the like.) 2. Spoon out the flour into the sample dish and shake it lightly to flatten the flour.

  • Page 11: Measurements

    5. Measurements 1. Insert the sample dish fully until the guide line is hid. 3. Moisture value and the number of measurements [Note] When measuring tapioca, place a metal plate onto it. is displayed on the screen. If the measurement lever is pushed down while the s a m p l e d i s h i s i n s e r t e d i n c o m p l e t e l y, t h e u p p e r electrode or sample dish may be damaged.

  • Page 12: Other Functions

    6. Other functions <Average moisture value> <Contrast adjustment> If characters on the display are too dark or light, Press the [AVERAGE] key in order to obtain the perform contrast adjustment. Press the [Contrast] average moisture value after making measurements key. "CONTRAST" is displayed on the screen. several times.

  • Page 13: Testing

    Use the supplied checker to check to make sure The electrical circuitry is functioning normally if a that the PB-3103’s electrical circuits are func-tioning numeric value of 14.9~15.1% is displayed at this time. normally. Press several times the [SELECT] key, I will match the "TEST"...

  • Page 14: Printer Output

    <Printer Output> Connecting the printer, VZ-330 (option), to the connector on the rear panel of the main unit with the cable supplied with the printer allows users to automatically print the measured results after measurement. [Note] Refer to the operating manual for the printer for how to set up the printer.

  • Page 15: Maintenance

    (round metal plate). Sample Dish <Storage> When using the sample After using the PB-3103, clean it well as described dish continuously, use above and then store it in a dry place where it will not the brush to remove any be exposed to direct sunlight.
  • Page 20 Caution ● It is strictly prohibited to transfer part or all of this manual without permission. ● The contents of this manual are subject to change without notice. ● The appearances, screens, etc. of the product and accessories displayed on this manual may differ from the actual ones, however, operations and functions are not affected. ● All efforts have been made to ensure the contents of this manual are accurate. However, if you notice any part to be unclear, incorrect, omitted, or the like in this manual, please contact us. ● Be aware that we are not liable for the effects resulting from opera- tions according to this manual regardless of the items above. 060166-01...
