For Australia/New Zealand:
Child restraints
Information
In accordance with ADR 34/01, provisions
have been made to allow installation of a child
restraint at each rear seating position.
The anchoring hooks which belong to the up‐
per restraining strap of the child restraint - AS
1754, can be applied immediately to the rele‐
vant mounting.
Please refer strictly to the installation instruc‐
tions supplied with the child restraint system.
Each seating position is fitted with a head rest.
WARNING
Child restraint anchorages are designed
to withstand only those loads imposed by cor‐
rectly fitted child restraints. Under no circum‐
stances are they to be used for adult seat
belts, harnesses or for attaching other items or
equipment to the vehicle. After using the child
restraints, the anchor fittings may need to be
folded down.◀
Mounting points
The symbol shows the mounting point
for the upper retaining strap.
There are three mounting points for child re‐
straint systems with an upper retaining strap.
Online Edition for Part no. 01 40 2 964 279 - VI/15
Carrying children in safety
Guiding the retaining strap
WARNING
If the upper retaining strap is used incor‐
rectly with the child restraint system, the pro‐
tective effect may be reduced. Danger of in‐
jury. Make sure that the upper retaining strap is
not routed to the upper attachment strap over
sharp edges, and that it is not twisted.◀
1 Direction of travel
2 Head restraint
3 Hook for the upper retaining strap
4 Mounting point
5 Seat backrest
6 Upper retaining strap
Attaching the upper retaining strap to
the mounting point
1. Raise head restraint if necessary.
2. On the rear seat: Guide the upper seat belt
on the brackets of the head restraint.
3. Guide the holding belt between the back‐
rest and luggage cover.
4. Engage the hook of the retaining strap in
the mounting point.
5. Pull the restraining strap firmly down.
6. Push head restraint down if necessary and
engage.
