JVC KD-AR470 Service Manual

Cd receiver
Hide thumbs

Advertisement

Table of Contents
SERVICE MANUAL
11
2005
MA232
KD-AR470,KD-G420,KD-G521,
KD-G524,KD-G525,KD-G527
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
1
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
CD RECEIVER
KD-AR470
KD-G521
KD-G525

TABLE OF CONTENTS

COPYRIGHT © 2005 Victor Company of Japan, Limited
Area suffix
J ------------- Northern America
Area suffix
E ------------- Southern Europe
EX ------------ Northern Europe
EY ------------- Eastern Europe
EU ------------------------- Turkey
KD-G524
Area suffix
UI ---------------------------- India
KD-G527
KD-G525
Area suffix
UT ------------------------- Taiwan
UH ---------------------- Thailand
UN --------------------- Indonesia
U -------------------- Other Areas
KD-G527
Area suffix
EE -------- Russian Federation
2005/11
