- Page 1 SK-P464D/M556AI D-WDR / 700TVL Pipe Camera Application : Wall & Ceiling Mount USER GUIDE English 3B26142A...
-
Page 2: Safety Information
►Table of Contents Safety information◄ CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING Precautions TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of Features electric shock is present within this unit. - Page 3 ►Precautions Features◄ You can install the camera outdoor. Using 1/3" SONY Super HAD CCD Ⅱ (960H) Super Supreme Resolution(700TV-Line) Choose an ideal location for the camera, since a camera unit must be protected against moisture and vibration. Advanced D-WDR, 3D-DNR Day &...
- Page 4 ►What’s included & Dimension Features◄ What's included Structure specification MECHANICAL 93(W) x 94.2(H) x 101.7(D)mm Dimension ANCHOR 6x30, 4EA SCREW 4x35 TP1 PAN SUS, 4EA Approx. 900g Weight WRENCH 3mm L TYPE, 1EA ENVIRONMENT Aluminum Construction SUNVISOR BOLT, 1EA Extra video output cable IP 68 Ingress Protection for installation,...
-
Page 5: Installation
►Installation Installation◄ HOW TO INSTALL 1. Make a hole of Ø25mm in diameter for passing cable. 6. Face the direction of the camera to monitor. 2. Drill four holes on the wall or ceiling and insert the anchors. 7. Tighten the bolt to complete adjustment. 3. - Page 6 ►Assembly Connection◄ Assembly DC 12V ANCHOR 6x30, 4EA ORANGE(485A)-#28 RS485 WHITE(485B)-#28 VIDEO POWER SCREW Tp1 4x35, 4EA AC 24V / DC 12V BOLT SUNVISOR ORANGE(485A)-#28 RS485 WHITE(485B)-#28 VIDEO POWER 11 _ 700TVL Pipe Camera 700TVL Pipe Camera _ 12...
-
Page 7: Osd Menu Set Up
►OSD Menu Set up OSD Menu Set up◄ Main Set up OSD Menu Control and Set up The on-screen menu is operated with the control lever on the PCB. LENS • MANUAL • DC • VIDEO To call the on-screen menu, press the control lever straight downward. EXPOSURE •... -
Page 8: Menu Setup
►Menu Set up Menu Set up◄ LENS (MANUAL, DC, VIDEO) LENS (MANUAL, DC, VIDEO) Function of adjusting shutter speed and AGC. MAIN MENU EXPOSURE 1. LENS 1. SHUTTER AUTO 2. EXPOSURE 2. AGC MIDDLE 3. BACKLIGHT 3. SENSUP AUTO 4. WHITE BAL 4. -
Page 9: White Bal
►Menu Set up Menu Set up◄ BACKLIGHT WHITE BAL Function of adjusting shutter speed and AGC. Strong/large sources of light coming from behind the main subject (such as a person indoors that is in front of a window) cause the light meter to underexpose for the main subject MAIN MENU MAIN MENU... - Page 10 ►Menu Set up Menu Set up◄ DAY & NIGHT - Switching of day operation/ night operation SMART 3DNR (ON/OFF) When motion is detected, reduces the background noise, dragging and stretching of image in a low luminance environment. MAIN MENU 1. LENS MANUAL 2.
- Page 11 ►Menu Set up Menu Set up◄ F-DNR SMART 3DNR (ON/OFF) This function improves the screen view clear when it is foggy, dusty, and low light Multiple functions can be selected. environment. FUNCTION MAIN MENU 1. MOTION 1. LENS MANUAL 2. PRIVACY 2.
- Page 12 ►Menu Set up Menu Set up◄ FUNCTION SMART 3DNR (ON/OFF) 3. D-EFFECT : Additional digital function activated. 4-3. LENS SHADING : Compensates brightness of four lens’ corners. 3-1. D-ZOOM (ON/OFF) : X1~X32 DIGITAL ZOOM can be adjustable. a. LEVEL (0~60) : Adjust level a.
-
Page 13: Troubleshooting
►Menu Set up Troubleshooting◄ SK-P464D / M556AI Check if the camera and monitor’s powers are on. (Also, the voltage and polarity.) Check if the video-out terminal of the camera and the video-in terminal of the SK-P464D M556AI monitor are correctly connected. VIDEO Check if the iris of the lens is open. - Page 14 ►Memo Memo◄ 27 _ 700TVL Pipe Camera 700TVL Pipe Camera _ 28...
