SETUP
PACKAGE CONTENTS:
CycleBoard Electric Vehicle
Battery Charger
2 Allen wrenches
Quick Start Guide
INSTRUCTIONS:
Your CycleBoard has been pre-assembled and only requires a few steps to prepare it to ride:
1.
After opening the box, inspect the contents for any damage that may have occurred during shipping.
If anything has been damaged, contact us for replacement or repair.
2.
The Hand brake lever and throttle (Fig 1 and Fig 2) are adjusted downward for shipping. Adjust the
throttle and hand brake lever to your desired location, then tighten the screws using the 2 included
Allen wrenches.
3.
Using the height adjustment handle and thumb screw (Fig 3), adjust the handle bars to your desired
height. Fully tighten the thumb screw and clamp so that the handlebars cannot rotate while riding.
(Note: It should be very tight)
Note: The maximum handle height will be limited by the brake cable, do not attempt to force the handle
higher than the brake cable will allow. When lowering the handle height, pull the excess brake cable and
wiring out to prevent it from crimping inside the upper handle.
4.
Fully charge your battery before riding for the first time. The light on your charger will change from
red to green when the battery is fully charged.
5.
Check the hand brake on the left handlebar to ensure it is functioning properly. If any adjustment is
required, use the adjustment knob (Fig 4) where the brake cable connects to the hand brake lever.
6.
The self centering springs in the front of the CycleBoard may initially make squeaking and clicking
sounds when steering but will stop after a short break in period. Shown in Fig 5.
FIG 1. HAND BRAKE LEVER
FIG 2. THROTTLE
FIG 3. HEIGHT ADJUSTMENT
FIG 4. ADJUSTMENT KNOB
FIG 5. SPRINGS
Page 7
