Cycleboard ROVER Quick Start Manual

CYCLEBOARD |
QUICK START GUIDE
Please go to cycleboard.com and download the complete owner's manual.
PLEASE READ THE OWNERS MANUAL AND ALL SAFETY AND WARNING LABELS THOROUGHLY BEFORE ATTEMPTING TO OPERATE THE CYCLEBOARD.
FOLDING / UNFOLDING HANDLE
The CycleBoard comes with the handle folded down in the shipping box.
TO UNFOLD:
1
Pick up the CycleBoard by
the handle to lift out of box
TO FOLD:
Reverse the steps above:
1. Loosen the clamp lever by rotating it forward.
2. Press the release tab downward.
3. Lower the handle until it locks in the down position
4. Once the handle locks in the down position, tighten the clamp lever by rotating it backwards
Note: If the release tab is difficult to press, gently shift the handle forwards and backwards while pressing the release tab.
Note: The "Clamp Lever" is SPRING LOADED to allow the user to position the lever to their desired location. To rotate the clamp lever forward or backward
WITHOUT tightening or loosening it. Pull the clamp lever to the left away from the base of the handle to engage the spring and disengage the teeth
SETUP
PACKAGE CONTENTS:
CycleBoard Electric Vehicle
2 Front Wheels
2 Front Wheel Bolts
Battery Charger
3 Allen wrenches
Quick Start Guide
4 finger nuts (for hinging deck)
INSTRUCTIONS:
Your CycleBoard has been pre-assembled and only requires a few steps to prepare it to ride:
1. After opening the box, inspect the contents for any damage that may have occurred during shipping. If anything has been damaged,
contact us for replacement or repair.
2. The Hand brake lever and throttle (Fig 1 and Fig 2) are adjusted downward for shipping. Adjust the throttle and hand brake lever to your
desired location, then tighten the screws using the included Allen wrenches.
3. Fully charge your battery before riding for the first time. The light on your charger will change from red to green when the battery is fully
charged.
4. Check the hand brake on the left handlebar to ensure it is functioning properly.
5. The self centering springs in the front of the CycleBoard may initially make squeaking and clicking sounds when steering but will stop
after a short break in period. Shown in Fig 3.
LCD Display Functions:
1. Long press the center button (power) to turn on/off Power to the display.
2. Short press the top button to increase the speed mode from 1-5.
3. Short press the bottom button to decrease the speed mode from 1-5.
4. After the display is powered on, short press the center button to toggle through the options for odometer, trip, error code and time.
5. After the display is powered on, long press the top button to turn the tail-light on/off..
Note: Always wait 10 minutes after charging your battery before riding.
Note: Always wait 15 minutes after riding before re-charging your
battery.
ROVER
2
Loosen clamp lever by rotating
it forward. Then press the
release tab downward to raise
handle to upright position.
CLAMP LEVER
RELEASE TAB
FIG. 1 - HAND BRAKE LEVER
Note: Always unplug your battery charger after the battery has finished charging.
Note: Charge your battery at least once per month if not in use for best battery care.
3
TIGHTEN
LOOSEN
ALWAYS WEAR A HELMET AND APPROPRIATE SAFETY GEAR
FIG. 2 - THROTTLE
After handle locks in place,
tighten the clamp lever on the
left side by rotating it clockwise
until it is "very" tight
FIG. 3 - SPRINGS
