NETGEAR D3600 Installation Manual

Installation
D3600/D3610 Wireless N600 DSL Modem Router
D6000/D6010 Wireless AC750 DSL Modem Router

Package Contents

Modem router
Phone cable Ethernet cable
You can connect the modem router either
to a DSL service or to a cable or fiber
modem. Choose one connection method
only. Do not use both.
Connect the Modem
Router to a DSL Service
1. Connect the modem router to
the Internet.
a. Install an ADSL microfilter
between the phone line and the
phone.
b. Use a phone cable to connect the
microfilter to the gray DSL port
on the modem router.
For additional information about
ADSL microfilter
connecting to a DSL service, see the
(varies by region)
other side of this installation guide.
2. Power on the modem router.
Connect the power adapter to the
modem router and plug it into an
electrical outlet.
Wait for the Power LED
green.
3. Connect a computer.
Use an Ethernet cable to connect
your computer to any yellow
Ethernet port on the modem router.
You can also use WiFi to connect.
To connect with WiFi, use the WiFi
Power adapter
network name and password on the
(varies by region)
product label.
4. Log in to the modem router.
Launch a web browser.
NETGEAR genie displays.
If you do not see genie:
In the address field of the web
browser, enter www.routerlogin.
net. When prompted, enter admin
for the user name and password for
the password.
DSL Internet
ADSL microfilter
Cable or fiber Internet
Phone cable to DSL port
Ethernet cable
to light
to Ethernet
port next to
DSL port
Cable or fiber modem
Connect the Modem 2. Power on the modem router.
Router to a Cable or Fiber
Connect the power adapter to the
modem router and plug it into an
Modem
electrical outlet.
1. Connect the modem router to
Wait for the Power LED
the Internet.
green.
Use an Ethernet cable to connect the
3. Connect a computer.
cable or fiber modem to the yellow
Use an Ethernet cable to connect
Ethernet port next to the gray DSL
your computer to any yellow
port on the modem router. (Do not
Ethernet port on the modem router.
use another Ethernet port fort this
connection.)
You can also use WiFi to connect.
To connect with WiFi, use the WiFi
network name and password on the
product label.
4. Log in to the modem router.
Launch a web browser. NETGEAR
genie displays.
If you do not see genie:
In the address field of the web
browser, enter www.routerlogin.
net. When prompted, enter admin
for the user name and password for
the password.
5. In genie, change the default
connection method.
a. Select BASIC > xDSL from the
Modem router
NETGEAR genie menu.
b. From the Physical WAN Type
menu, select Ethernet WAN.
Power adapter
c. Click the Apply button.
to light
