1 0F2123 1
2 0F2122 1
3 095613 1
4 051756 2
5 046526 44
6 049814 4
7 051735 8
8 0F2097 1
9 072879 1
10 097557B 1
11 0H3114 1
095970 1
095968 1
0E6866 1
12 070263 2
13 057019 2
14 026847 1
15 0H3113 1
095969 1
095967 1
0E6865 1
16 095966 1
17 095976 1
18 095971 1
19 096777 1
20 057019S 1
22 096379 1
23 048189 2
24 095979 1
25 021159 1
26 097557A 1
27 057163 1
28 0F6518 4
29 0F3201 1
30 020443 1
31 094666A 1
32 099828 8
33 099828A 8
34 026925 2
35 097557C 1
36 038591 1
37 025066 1
38 031578 6
052625 REF.
39 049814 10
40 0A1786 2.5cc
41 027175 .200 GAL
44 045772 10
45 052243 10
46 057642 2
47 0F6487 4
48 0F6355 1
49 0F6477 .050 GAL
50 0F6557 0.4cc
51 026924 1
GEAR CASE ENG. MACHINED
GEAR CASE ALT. MACHINED
SEAL OIL
SCREW HHC M10-1.5 X 20 G8.8
WASHER LOCK M10
SCREW HHC M10-1.5 X 25 G8.8
SCREW HHC M10-1.5 X 70 G8.8
GASKET 390 GEARBOX
SPACER .69 X 2.75 X .37 ST/ZNC
KEY 10 X 16 X 46
GEAR OUTPUT 1.65:1
GEAR OUT 390-50H 37T
GEAR OUT 390-60H 35T
GEAR OUTPUT 2:1 50HZ 390
SCREW HHC M16-2.0 X 35 G10.9
BALL BRG 65 X 120 X 23
BREATHER
GEAR INPUT 1.65: 1
GEAR INPT 390-50 25T
GEAR INPT 390-60 27T
GEAR INPUT 2:1 50HZ 390
SHAFT 390 INPUT GEAR
COLLAR HARDENED
SEAL OIL
SNAP RING INT 120MM
BEARING #6213 SEALED
PLATE INTRNL BRG RET
PIN DOWEL M8 X 24
PLATE BEARING THRST
SPACER STRESSPROOF
KEY 10 X 16 X 40
PLUG PIPE 3/8" MAGNETIC
SCREW HHFC M10-1.5 X 25 G10.9
COVER GEARBOX GUARD
COUPLING INNER DRAWN
COUPLING OUTER MACHN
DAMPER GB CPLR VIBRA
DAMPER GB CPLR VIBRA
PLUG STD PIPE 3/8 STEEL SQ HD
KEY 10 X 16 X 50
NIPPLE PIPE 3/8 NPT X 3-1/2
COUPLING FULL 3/8-18
SCREW HHC 3/8-16 X 1-1/2 G8
SCREW SHC M10-1.5 X 35 G12.9 (FORD ENGINES)
SCREW HHC M10-1.5 X 25 G8.8
RETAINING COMPOUND
LUBE GREASE SAE #90 80W90 (NOT SHOWN)
NUT HEX M10-1.5 G8 YEL CHR
SCREW HHC M10-1.5 X 60 G8.8
SCREW HHC M10-1.5 X 40 G10.9
WASHER FLAT M10 SEALING COPPER
GASKET SEAL PLATE 390 GB
ENHANCER GEAR OIL (NOT SHOWN)
THREADLOCK AND SEALANT
ELBOW 90D STREET 3/8
