General Information
Figure 7.1 — Stator Power Winding 3-PHASE ALTERNATORS ("DELTA" CONFIGURATION)
Connections - 3-phase, 346/600V (6 Lead)
The Stationary Emergency Generator is designed to supply
3-phase electrical loads. Electric power is produced in the alterna-
tor power windings. These windings were connected at the factory
S1 E1
to the main circuit breaker with a "Delta" configuration as shown
in Figures 7.5.
The rated voltage between circuit breaker terminals E1-E2, E1-E3
and E2-E3 is 208V.
INTERNAL
CONNECTIONS
The rated voltage between E1 or E3 and the neutral point 00 is
120V.
L-L
Figure 7.5 — Stator Power Winding
S6 S4
Connections - 3-phase, 120/240V (12 Lead)
NEUTRAL
S5
E2
E3 S3
S2 E2
L-N
E1 E
7-2
