Panasonic KX-TS500LX1B Service Manual

Subject : Adding KX-TS500LX1B, KX-TS500LX1W to the KX-TS500LX Series.
Note: All other information is the same as KX-TS500LX Service Manual (Order No.
KM40309208C3). You can download and refer the Service Manual on TSN Server.
Please file and use this supplement manual together with the service manual for Model No.
KX-TS500LXB, KX-TS500LXW Order No. KM40309208C3.

TABLE OF CONTENTS

1 CABINET AND ELECTRICAL PARTS LOCATION ------ 2
2 ACCESSORY AND PACKING MATERIAL ----------------- 3
3 REPLACEMENT PARTS LIST--------------------------------- 4
3.1. Base unit----------------------------------------------------- 4
3.1.1. Cabinet and Electrical Parts ----------------------- 4
3.1.2. Main P.C Boards Parts ------------------------------ 4
3.1.3. Operational P.C.Board Part ------------------------ 5
3.1.4. Accessories and Packing Material --------------- 5
3.1.5. Screws--------------------------------------------------- 5
Model No.
Integrated Telephone System
B: Black Version
W: White Version
(for Latin America)
PAGE
© Panasonic System Networks Co., Ltd. 2015
Unauthorized copying and distribution is a violation
of law.
ORDER NO. KM41508908SE
Telephone Equipment
KX-TS500LX1B
KX-TS500LX1W
PAGE
