Panasonic KX-TS550LXB Service Manual

Integrated.
Hide thumbs

Advertisement

Please file and use this supplement manual together with the service manual mentioned below.
CONTENTS
KX-TS550LXB
KX-TS550LXW
Integrated Telephone System
Black Version
White Version
(for Latin America)
Page
2
3.2. SCHEMATIC DIAGRAM (Changed from original section
2
3
3.3. Main (Component View) (Changed from original section
3
20.1. Main (Component View))
4
6
6
© 2006 Panasonic Communications Co., Ltd. All
rights
distribution is a violation of law.
ORDER NO. KM40607177SE
Telephone Equipment
reserved.
Unauthorized
Page
7
9
10
copying
and
Previous page
Next page

Advertisement

Table of Contents

   Related Manuals for Panasonic KX-TS550LXB

   Summary of Contents for Panasonic KX-TS550LXB

  • Page 1: Table Of Contents

    3 CORRECTION section 20.2. Main (Flow Solder Side View)) 3.1. CABINET AND ELECTRICAL PARTS LOCATION (Changed from original section 14 CABINET AND ELECTRICAL PARTS LOCATION) © 2006 Panasonic Communications Co., Ltd. All rights reserved. Unauthorized copying distribution is a violation of law.

  • Page 2: Changes (for Rohs)

    KX-TS550LXB / KX-TS550LXW 1 CHANGES (for RoHS) 1.1. SUBJECT...

  • Page 3: Replacement Parts List

    KX-TS550LXB / KX-TS550LXW 2 REPLACEMENT PARTS LIST 2.1. REFERENCE CHART...

  • Page 4: Original And New Parts Comparison Lists

    KX-TS550LXB / KX-TS550LXW 2.2. ORIGINAL AND NEW PARTS COMPARISON LISTS Change of the Suffix Code • Base Unit Serial No.Label tells you the suffix code as follows...
  • Page 5 KX-TS550LXB / KX-TS550LXW (for KX-TS550LXB/KX-TS550LXW) Ref No. Part No. Part Name & Descriptions Pcs/ Remarks Notes Suffix Original (Old) BASE UNIT ------ C1CA00000254 A to B 2SA1625 B1ACGP000007 Transistor (Si) 2SD1819A ------ Transistor (Si) A to B ------ B1CEGF000004 Transistor (Si)

  • Page 6: Correction

    KX-TS550LXB / KX-TS550LXW 3 CORRECTION 3.1. CABINET AND ELECTRICAL PARTS LOCATION (Changed from original section 14 CABINET AND ELECTRICAL PARTS LOCATION)

  • Page 7: Schematic Diagram

    KX-TS550LXB / KX-TS550LXW 3.2. SCHEMATIC DIAGRAM (Changed from original section 19 SCHEMATIC DIAGRAM) RING POS1 1.8M 500V680P 3.3M JACK1 S1-2 500V680P 250V1 High Ringer R102 Red+ Black- R103 10K R104 NC RINGER CIRCUIT 100K 16V10 0.068 JACK3 (10) (11) 0.068...

  • Page 8: Schematic Diagram

    KX-TS550LXB / KX-TS550LXW FLT2 16V10 1 LS 2 MFL 3 R0 4 VDD 5 AGND 50V1 FLT1 6 STB JP11 7 CI 6.8K JP12 8 M0 JP13 9 LLC VS.VSS 10 HS/DP 11 OSC 12 MODE 13 C4 14 C3...

  • Page 9: Main (component View)

    3.3. Main (Component View) (Changed from original section 20.1. Main (Component View)) JACK3 E C B E C B C102 JP29 E C B E C B G D S FLT2 FLT1 2 3 4 5 6 7 8 9 10 11 12 YELLOW JP11 JP12...

  • Page 10: Main (flow Solder Side View) (changed From Original Section 20.2. Main (flow Solder Side View))

    3.4. Main (Flow Solder Side View) (Changed from original section 20.2. Main (Flow Solder Side View)) for Flash* for PULSE* for TONE* for Ringer** FLT2 RINGER1 BLACK...
  • Page 11 KX-TS550LXB / KX-TS550LXW KXTS550LXB KXTS550LXW...
