2009
Honda VTX1300R/T
VTX
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VTX1300T 2009 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Honda VTX1300T 2009

Summary of Contents for Honda VTX1300T 2009

  • Page 1 2009 Honda VTX1300R/T OWNER’S MANUAL...
  • Page 2 It’s full of facts, instructions, safety information, When you own a Honda, you’re part of a and helpful tips. To make it easy to use, worldwide family of satisfied customers the manual contains a detailed list of −...
  • Page 3 California to cause cancer and birth motorcycle best and is dedicated to your defects or other reproductive harm. complete satisfaction. Please report any change of address or ownership to your Honda dealer so we will be able to contact you concerning important product information. Introduction...
  • Page 4 A Few Words About Safety Your safety, and the safety of others, is very important. And operating this motorcycle safely is an important responsibility. To help you make informed decisions about safety, we have provided operating procedures and other information on labels and in this manual. This information alerts you to potential hazards that could hurt you or others.
  • Page 5 A Few Words About Safety You WILL be KILLED or SERIOUSLY HURT if you don’t follow instructions. You CAN be KILLED or SERIOUSLY HURT if you don’t follow instructions. You CAN be HURT if you don’t follow instructions. Safety Headings ––...
  • Page 6 Contents These pages give an overview of the Before Riding ........contents of your owner’s manual. The first The importance of wearing a helmet page of each section lists the topics and other protective gear, how to make covered in that section. sure you and your motorcycle are ready to ride, and important information about loading.
  • Page 7 ...... ID numbers, technical specifications, Why your motorcycle needs regular and other technical facts. maintenance, what you need to know before servicing your Honda, an owner maintenance schedule, and instructions Consumer Information ..... for specific maintenance and Information on warranties, emission adjustment items.

  • Page 9: Motorcycle Safety

    Motorcycle Safety This section presents some of the most Important Safety Information ....important information and Accessories & Modifications ....recommendations to help you ride your Safety Labels .......... motorcycle safely. Please take a few moments to read these pages. This section also includes information about the location of safety labels on your motorcycle.

  • Page 10: Motorcycle Safety

    Important Safety Information Your motorcycle can provide many years Always Wear a Helmet of service and pleasure if you take − It’s a proven fact: helmets significantly responsibility for your own safety and reduce the number and severity of head understand the challenges you can meet injuries.
  • Page 11 Important Safety Information Take Time to Learn & Practice Always pay attention to other vehicles Even if you have ridden other motorcycles, around you, and do not assume that other take time to become familiar with how drivers see you. Be prepared to stop this motorcycle works and handles.
  • Page 12 Important Safety Information Ride within Your Limits Keep Your Honda in Safe Condition Pushing limits is another major cause of It’s important to keep your motorcycle motorcycle accidents. Never ride beyond properly maintained and in safe riding your personal abilities or faster than condition.
  • Page 13 Improper accessories or installation, and use of non-Honda modifications can cause a crash in accessories. which you can be seriously hurt or Check with your Honda dealer for killed. assistance and always follow these guidelines: Follow all instructions in this Make sure the accessory does not owner’s manual regarding...
  • Page 14 Accessories & Modifications Do not install any fairing or windscreen Modifications unless it was designed and tested by Honda for your motorcycle. Some fairings or windscreens, even smaller We strongly advise you not to remove any ones, can cause unstable handling of original equipment or modify your your motorcycle.

  • Page 15: Safety Labels

    Safety labels on your motorcycle either warn you of potential hazards that could cause serious injury or they provide important safety information. Read these labels carefully and don’t remove them. If a label comes off or becomes hard to read, contact your Honda dealer for a replacement. Motorcycle Safety...
  • Page 16 Safety Labels 〈 For USA 〉 〈 For Canada 〉 Motorcycle Safety...

  • Page 17: Table Of Contents

    Instruments & Controls This section shows the location of all Operation Component Locations ... gauges, indicators, and controls you would Gauges & Indicators ....... normally use before or while riding your Controls & Features ........ motorcycle. Fuel Valve .......... Choke Knob ........

  • Page 18: Operation Component Locations

    Operation Component Locations VTX1300R engine stop switch front brake clutch lever lever headlight dimmer switch throttle grip turn signal switch horn button start button Instruments & Controls...
  • Page 19 Operation Component Locations VTX1300T engine stop switch front brake clutch lever lever headlight dimmer switch throttle grip turn signal switch horn button start button Instruments & Controls...
  • Page 20 Operation Component Locations VTX1300R steering lock rear brake pedal Instruments & Controls...
  • Page 21 Operation Component Locations VTX1300R helmet holder fuel valve choke knob ignition switch shift lever Instruments & Controls...
  • Page 22 Operation Component Locations VTX1300T steering lock saddlebag rear brake pedal Instruments & Controls...
  • Page 23 Operation Component Locations VTX1300T helmet holder fuel valve choke knob ignition switch shift lever saddlebag Instruments & Controls...

  • Page 24: Gauges & Indicators

    Gauges & Indicators The gauges and indicators on your (1) speedometer motorcycle keep you informed, alert you (2) odometer/tripmeter A & B display to possible problems, and make your (3) right turn signal indicator riding safer and more enjoyable. Refer to (4) low oil pressure indicator the gauges and indicators frequently.
  • Page 25 Gauges & Indicators Lamp Check If one of these indicators does not come on when it should, have your Honda dealer The low oil pressure indicator comes on check for problems. when you turn the ignition switch ON so you can check that it is working. The indicator remains on until after the engine is started.
  • Page 26 Gauges & Indicators speedometer Shows riding speed in miles (USA) or kilometers (Canada) per hour. odometer/tripmeter A & B display odometer Shows the total miles (USA) or kilometers (Canada) ridden (page tripmeter Shows the number of miles (USA) or kilometers A &...
  • Page 27 Gauges & Indicators high beam indicator Lights when the headlight is on high beam. (blue) neutral indicator (green) Lights when the transmission is in neutral. high coolant temperature Lights when the coolant is over the specified indicator (red) temperature. If the indicator comes on, pull safely to the side of the road.

  • Page 28: Controls & Features

    Controls & Features − OFF for parking, storing, or Fuel Valve transportation. − RES for extra fuel to get to a gas station LEFT SIDE for refueling. Automatic Fuel ON-OFF With the fuel valve set to ON (or RES), fuel flows to the carburetor only when the engine is being started or is running.

  • Page 29: Choke Knob

    Controls & Features Choke Knob LEFT SIDE (1) choke knob (A) fully ON (B) fully OFF The choke knob ( ) may be used when starting the engine. See page Instruments & Controls...

  • Page 30: Ignition Switch

    Controls & Features LEFT SIDE Ignition Switch The ignition switch ( ) is used for starting and stopping the engine (page ). The ignition key is also used to lock the steering for theft prevention (page Insert the key and turn it to the right for the ON position.

  • Page 31: Start Button

    Controls & Features Start Button Engine Stop Switch RIGHT HANDLEBAR The start button ( ) is used for starting the engine. Pushing the button in starts the engine. See Starting Procedure, page When the start button is pushed, the starter motor will crank the engine;...

  • Page 32: Headlight Dimmer Switch

    Controls & Features If your motorcycle is stopped with the Turn Signal Switch ignition switch ON and the engine stop switch OFF, the headlight and taillight will remain on, resulting in battery The turn signal switch ( ) is used to signal discharge.

  • Page 33: Horn Button

    Controls & Features To reset the tripmeter, push and hold the Horn Button button with the display in the tripmeter mode. The horn is used to alert other motorists. To operate, push the horn button ( ). Odometer/Tripmeter Select and Reset Button The display ( ) has two functions, odometer and tripmeter.
  • Page 34 Controls & Features (6) odometer (7) tripmeter A (8) tripmeter B (9) tripmeter reset Instruments & Controls...

  • Page 35: Before Riding

    Before Riding Before each ride, you need to make sure Are You Ready to Ride? ......you and your Honda are both ready to ride. Protective Apparel ......To help get you prepared, this section Rider Training ........discusses how to evaluate your riding Is Your Motorcycle Ready to Ride? ..

  • Page 36: Before Riding

    Are You Ready to Ride? Before you ride your motorcycle for the If you must carry an extra helmet while first time, we urge you to: riding, use a commercially available Read this owner’s manual. elastic cord, strap, or net to secure the Make sure you understand all the safety helmet to the seat.
  • Page 37 Are You Ready to Ride? Helmets and Eye Protection Your helmet is your most important piece Not wearing a helmet increases of riding gear because it offers the best protection against head injuries. A helmet the chance of serious injury or death in a crash.

  • Page 38: Rider Training

    Are You Ready to Ride? A motorcycle riding suit or jacket for We urge all riders to take a certified comfort as well as protection. course approved by the Motorcycle Safety Bright-colored and reflective clothing Foundation (MSF). New riders should can help make you more noticeable in start with the basic course, and even traffic.

  • Page 39: Is Your Motorcycle Ready To Ride

    Is Your Motorcycle Ready to Ride? Before each ride, it’s important to inspect Pre-ride Inspection your motorcycle and make sure any problem you find is corrected. A pre-ride inspection is a must, not only for safety, Check the following items before you get but because having a breakdown, or even on the motorcycle: a flat tire, can be a major inconvenience.
  • Page 40 Is Your Motorcycle Ready to Ride? Leaks, Walk around your motorcycle If you are carrying a passenger or cargo, Loose and look for anything that also check the following: Parts appears unusual, such as a leak or loose cable. Load Limits Make sure you do not exceed the load limits Lights...
  • Page 41 Pull the brake lever and press on the brake pedal to Remember, be sure to take care of any check that they operate problem you find, or have your Honda normally. dealer correct it before you ride. Indicators Turn the ignition on and...

  • Page 42: Load Limits & Guidelines

    However, exceeding the weight limit or carrying an unbalanced load can seriously Overloading or improper loading impair your motorcycle’s handling, braking, and stability. Non-Honda can cause a crash and you can be seriously hurt or killed. accessories, improper modifications, and...

  • Page 43: Load Limits

    Load Limits & Guidelines maximum cargo weight: Load Limits 40 lbs (18 kg) Following are the load limits for your VTX1300T only motorcycle: includes following maximum compartment weights: maximum weight capacity: each saddlebag 404 lbs (183 kg) 10 lbs (4.5 kg) 413 lbs (187 kg) (Canada only) includes the weight of the rider,...

  • Page 44: Loading Guidelines

    If you wish to carry more cargo, check with your Honda dealer for advice, and be sure to read the information regarding accessories on page Before Riding...
  • Page 45 Load Limits & Guidelines Follow these guidelines whenever you Do not attach large or heavy items (such carry a passenger or cargo: as a sleeping bag or tent) to the Check that both tires are properly handlebar, forks, or fender. inflated, and that pressure in the rear Make sure both saddlebags are securely tire is increased to suit the load...

  • Page 46: Cargo Compartment ( Type Only) T

    Cargo Compartment ( type only) Your motorcycle comes with dual To Open & Shut the Saddlebags saddlebags. Instructions on how to open and close the LEFT SIDE saddlebags follow. TO OPEN Saddlebags The saddlebags are for lightweight items. Cargo in the saddlebags should not exceed: 10 lbs (4.5 kg) However, regardless of compartment...
  • Page 47 Cargo Compartment ( type only) To open: To close: Unsnap the snaps ( ) at the top of the Lower the lid. saddlebag. Secure the snaps. Squeeze both sides of the latch ( ) in Insert the latch in the clasp. its clasp ( ) and pull out on the belt to free the latch.
  • Page 48 Before Riding...

  • Page 49: Basic Operation & Riding

    Basic Operation & Riding This section gives basic riding instructions, Safe Riding Precautions ......including how to start and stop your Starting & Stopping the Engine ..... engine, and how to use the throttle, clutch, Preparation .......... and brakes. It also provides important Starting Procedure ......

  • Page 50: Safe Riding Precautions

    Safe Riding Precautions Before riding your motorcycle for the first time, please review the Motorcycle Saf ety section beginning on page 1, and the Bef ore Riding section beginning on page Even if you have ridden other motorcycles, take time to become familiar with how this motorcycle works and handles.

  • Page 51: Starting & Stopping The Engine

    Starting & Stopping the Engine Always follow the proper starting clutch lever pulled in. After starting with procedure described below. the side stand down, the engine will stop if the transmission is put in gear before For your safety, avoid starting or operating raising the side stand.

  • Page 52: Starting Procedure

    Starting & Stopping the Engine The low oil pressure indicator should go Starting Procedure off a few seconds after the engine starts. If the low oil pressure indicator lights during operation, stop the engine To restart a warm engine, follow the immediately and check the engine oil level.
  • Page 53 Starting & Stopping the Engine Pull the choke knob ( ) out all the way High Air Temperature to fully ON ( ), if the engine is cold. 35°C (95°F) or above Start the engine, leaving the throttle Do not use the choke. closed.

  • Page 54: Flooded Engine

    Starting & Stopping the Engine Continue warming up the engine until it Flooded Engine runs smoothly and responds to the throttle when the choke knob is at fully OFF ( ). If the engine fails to start after repeated attempts, it may be flooded with excess fuel.

  • Page 55: How To Stop The Engine

    Starting & Stopping the Engine If the engine starts, quickly close the If your motorcycle is stopped with the throttle, then open it slightly if idling is engine stop switch OFF and the ignition unstable. switch ON, the headlight and taillight If the engine does not start, wait 10 will remain on, resulting in battery seconds, then follow the...

  • Page 56: Shifting Gears

    Shifting Gears As a general rule, shift while moving in a straight line. HEEL Close the throttle and pull the clutch lever in completely before shifting. Improper shifting may damage the shifting pattern engine, transmission, and drive train. Learn to recognize the engagement Your motorcycle has five forward gears point as you release the clutch lever.
  • Page 57 Shifting Gears Avoid downshifting to help slow your Shif ting Up: motorcycle when engine rpm is high. From 1st to 2nd: 12 mph (20 km/h) Downshifting when engine speed is From 2nd to 3rd: 19 mph (30 km/h) near its allowable maximum may over- From 3rd to 4th: 25 mph (40 km/h) rev the engine and cause possible...

  • Page 58: Braking

    Braking Your motorcycle is equipped with disc Gradually increase braking as you feel the braking systems which are hydraulically brakes slowing your speed. The increase activated. Operating the brake lever in engine compression from downshifting applies the front disc brake. Depressing will help slow your motorcycle.
  • Page 59 Braking When possible, reduce your speed or your safety, exercise extreme caution complete braking before entering a turn. when braking, accelerating or turning. Avoid braking or closing the throttle quickly while turning. Either action may When descending a long, steep grade, cause one or both wheels to slip and use engine compression braking by reduce your control of your motorcycle.

  • Page 60: Parking

    Parking Look for a level parking area. If you Use the side stand to support the can’t park on a paved surface, make motorcycle while parked. sure the ground surface is firm, To lower the side stand, use your foot especially under the side stand.
  • Page 61 Parking Use the steering lock ( ), which locks the handlebar in place. Turn the handlebar all the way to the left. Insert the ignition key ( ) in the lock and turn it 180 degrees clockwise. Remove the key. RIGHT FRONT (1) steering lock (2) ignition key...
  • Page 62 Parking Use the helmet holder ( ) to secure your helmet with your motorcycle: Riding with a helmet attached to Insert the ignition key ( ) and turn it counterclockwise to unlock the the holder can interfere with the rear wheel or suspension and holder.

  • Page 63: Theft-Prevention Tips

    Parking If you decide to use an anti-theft device, Theft-prevention Tips select one of good quality and be sure to follow the manufacturer’s instructions. Park your motorcycle in a locked Keep your owner’s manual, current garage whenever possible. If a garage registration, and insurance information isn’t available, park in a concealed area with your motorcycle.

  • Page 64: Riding With A Passenger Or Cargo

    Riding with a Passenger or Cargo Your motorcycle is designed to carry you Before riding with a passenger, make sure and one passenger. Whenever you add a your passenger is wearing the proper passenger or cargo, you must be careful protective apparel (page not to exceed the total load limits for this vehicle (...

  • Page 65: Servicing Your Honda

    You’ll also find important safety ‘‘certified’’ to EPA standards. precautions, information on fuels and oils, and tips for keeping your Honda looking Bef ore You Service Your Honda great. The Importance of Maintenance ....

  • Page 66: Service Preparations Maintenance Component Locations

    Servicing Your Honda Service Preparations Engine Maintenance Component Locations ..Throttle ..........Side Cover Removal ....... Clutch System ........Storage Compartment ......Engine Idle Speed ....... Tool Kit ........... Spark Plugs ......... Owner’s Manual Storage ......Chassis Seat Removal ..........
  • Page 67 Servicing Your Honda The following table summarizes the three types of inspections and servicing recommendations for your motorcycle. Both the pre-ride inspection and the scheduled maintenance at the recommended intervals are necessary to assure safe and dependable performance. The periodic checks provide additional confidence in your motorcycle’s performance.
  • Page 68 Maintenance Schedule in this section. If your motorcycle overturns or is involved in a crash, be sure your Honda dealer inspects all major parts, even if you are able to make some of the repairs yourself.

  • Page 69: Maintenance Safety

    Other tasks that are more difficult and require special tools are best performed by professionals. Wheel removal should Failure to properly follow normally be handled only by a Honda technician or other qualified mechanic. maintenance instructions and precautions can cause you to be Instructions are included in this manual only to assist in emergency service.

  • Page 70: Important Safety Information

    Burns from hot motorcycle parts. clean parts. Keep cigarettes, sparks, and the engine and exhaust system cool flames away from all fuel-related parts. before touching. Injury from moving parts. Do not run the engine unless instructed to do so. Servicing Your Honda...
  • Page 71 Maintenance Safety Remember that your Honda dealer knows your motorcycle best and is fully equipped to maintain and repair it. To ensure the best quality and reliability, use only new Honda Genuine Parts or their equivalents for repair and replacement. If you have the...

  • Page 72: Periodic Maintenance

    It’s a good idea to perform this maintenance any time you clean your motorcycle. Check the odometer reading and perform any scheduled maintenance checks that are needed (page ). Remember, more frequent checks may be needed for riding in severe conditions. Servicing Your Honda...
  • Page 73 Freeplay Check the freeplay of the clutch lever (page ) and throttle grip (page Fuses Make sure you have a full supply of spare fuses. Nuts & Bolts Check the major fasteners and tighten as needed. Servicing Your Honda...

  • Page 74: Maintenance Schedule

    We recommend that you have your Honda dealer perform these The service intervals in this Maintenance tasks unless you have advanced Schedule are based on average riding mechanical skills and the required tools conditions.
  • Page 75 If you do not feel capable of performing a Each item on the maintenance schedule given task or need assistance, remember requires some mechanical knowledge. that your Honda dealer knows your Certain items (particularly those marked ＊ ＊＊ motorcycle best and is fully equipped to ) may require more technical maintain and repair it.
  • Page 76 Service more frequently if the motorcycle is ridden often at full throttle or in the rain. Replace every 2 years, or at indicated odometer interval, whichever comes first. Replacement requires mechanical skill. California type only. Servicing Your Honda...
  • Page 77 − SYSTEM ＊ EVAPORATIVE EMISSION − CONTROL SYSTEM Should be serviced by your Honda dealer, unless you have the proper tools and service data and are ＊ mechanically qualified. Refer to the official Honda Service Manual (page Servicing Your Honda...
  • Page 78 BEARINGS ＊ Should be serviced by your Honda dealer, unless you have the proper tools and service data and are mechanically qualified. Refer to the official Honda Service Manual (page In the interest of safety, we recommend these items be serviced only by your Honda dealer.

  • Page 79: Maintenance Record

    Use the space under Notes to record anything you want to remind yourself about or mention to your dealer. Miles (km) Odometer Date Performed By: Notes (1,000) 4,000 (6,400) 8,000 (12,800) 12,000 (19,200) 16,000 (25,600) 20,000 (32,000) Servicing Your Honda...
  • Page 80 Maintenance Record Miles (km) Odometer Date Performed By: Notes 24,000 (38,400) 28,000 (44,800) 32,000 (51,200) 36,000 (57,600) 40,000 (64,000) 44,000 (70,400) 48,000 (76,800) 52,000 (83,200) 56,000 (89,600) 60,000 (96,000) 64,000 (102,400) 68,000 (108,800) Servicing Your Honda...

  • Page 81: Servicing Your Honda

    Maintenance Component Locations VTX1300R front brake fluid reservoir throttle grip clutch lever front brake lever fuel fill cap Servicing Your Honda...
  • Page 82 Maintenance Component Locations VTX1300T front brake fluid reservoir throttle grip clutch lever front brake lever fuel fill cap Servicing Your Honda...
  • Page 83 (engine idle speed) fuse box rear suspension spring rear brake pre-load adjuster fluid reservoir rear brake rear brake caliper pedal air cleaner crankcase breather tube engine oil filter engine oil drain bolts front brake caliper Servicing Your Honda...
  • Page 84 Maintenance Component Locations VTX1300R storage compartment tool kit owner’s manual rear suspension spring pre-load adjuster coolant reserve tank choke knob spark plugs engine oil filler final drive gear final drive gear cap/dipstick oil drain bolt oil filler cap Servicing Your Honda...
  • Page 85 (engine idle speed) front brake caliper rear brake caliper engine oil engine oil air cleaner filter drain bolt rear brake pedal crankcase breather tube rear brake fluid reservoir Servicing Your Honda...
  • Page 86 Maintenance Component Locations VTX1300T storage compartment tool kit rear suspension spring owner’s manual pre-load adjuster coolant reserve tank choke knob final drive gear engine oil filler cap/dipstick oil filler cap spark plug final drive gear oil drain bolt Servicing Your Honda...

  • Page 87: Side Cover Removal

    Left Side Cover Installation Align the recesses ( ) with the tabs. Position the cover so the prong is aligned with the frame grommet. Push the prong in. (1) left side cover (3) frame grommet (2) prong (4) recesses Servicing Your Honda...
  • Page 88 Right Side Cover Installation Align the recesses ( ) with the tabs. Position the cover so the prong is aligned with the frame grommet. Push the prong in. (3) grommet (1) right side cover (2) prong (4) recesses Servicing Your Honda...

  • Page 89: Storage Compartment

    Insert the ignition key ( ) and turn it clockwise. Open the storage compartment lid. To close the storage compartment, close (1) storage compartment the storage compartment lid. Turn the (2) ignition key ignition key counterclockwise and remove it. Install the left side cover (page Servicing Your Honda...

  • Page 90: Tool Kit

    The tool kit ( ) is stored in the storage LEFT SIDE compartment ( ) (page ) behind the left side cover (page An optional, larger tool kit may be available. Check with your Honda dealer’s parts department. (1) tool kit (2) storage compartment Servicing Your Honda...

  • Page 91: Owner's Manual Storage

    ( ) in the storage compartment ( ) (page ) behind the left side cover (page Be careful not to flood this area when washing your motorcycle. (1) plastic storage bag (2) storage compartment Servicing Your Honda...

  • Page 92: Seat Removal

    Install the rear seat. Install the seat strap, bolts A, and bolt B. (1) cap (5) rear seat Install the cap. (2) seat strap (6) bolts C (3) bolts A (7) front seat (4) bolt B (8) tab Servicing Your Honda...

  • Page 93: Fuel

    The use of leaded gas will damage the for concern. catalytic converters. If pinging or spark knock occurs at a steady engine speed under normal load, change brands of gasoline. If pinging or spark knock persists, consult your Honda dealer. Servicing Your Honda...
  • Page 94 (1) ignition key (3) filler neck (2) fuel fill cap position after refueling to avoid running out of fuel with no reserve. Insert the ignition key ( ) in the fuel fill cap ( ) and turn it clockwise. Servicing Your Honda...
  • Page 95 Turn the fuel valve ON (if it was set on RES). Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel. Stop the engine and keep heat, sparks and flame away. Handle fuel only outdoors. Wipe up spills immediately. Servicing Your Honda...

  • Page 96: Engine Oil & Filter

    Changing oil helps get rid of dirt and deposits in the engine. Operating the engine with old or dirty oil can damage your engine. Running the engine with insufficient oil can cause serious damage to the engine and transmission. Servicing Your Honda...
  • Page 97 Engine Oil & Filter Oil Recommendation ＊ suggested oil Pro Honda GN4 4-stroke oil (USA SG or higher & Canada), or Honda 4-stroke oil classification except oils (Canada only), or an equivalent labeled as energy motorcycle oil. conserving on the ＊...
  • Page 98 Do not use API SH or higher oils displaying a circular API ‘‘energy conserving’’ service label on the container. They may affect lubrication and clutch performance. NOT RECOMMENDED Do not use non-detergent, vegetable, or castor based racing oils. Servicing Your Honda...
  • Page 99 There are two classes: MA and MB. Oil conforming to the standard is labeled on the oil container. For example, the following label shows the MA classification. (1) code number of the sales company of the oil (2) oil classification Servicing Your Honda...
  • Page 100 Remove the oil filler cap/dipstick ( ) and wipe it clean. Hold the motorcycle in an upright position. Insert the oil filler cap/dipstick until it seats, but don’t screw it in. (1) oil filler cap/dipstick (2) upper level mark (3) lower level mark Servicing Your Honda...
  • Page 101 ( ) –– add the specific performance requirements. Use a recommended oil until it reaches the new Honda Genuine oil filter or a filter of upper level mark. (Do not overfill.) equal quality specified for your model. Reinstall the oil filler cap/dipstick.
  • Page 102 ( ). (page ). If you do not have the skills or the tools, see your Honda dealer. RIGHT FRONT, UNDER ENGINE Drain the Engine Oil: Park the motorcycle on its side stand on a firm, level surface.
  • Page 103 (4) oil filter Improper disposal of drained f luids is Apply a thin coat of engine oil to the harmf ul to the environment. rubber seal ( ) of a new oil filter. (5) rubber seal (cont’d) Servicing Your Honda...
  • Page 104 If a torque wrench is not used for Install the drain bolts and tighten them installation, see your Honda dealer as soon to the specified torque: as possible to verify proper assembly. 22 lbf·ft (30 N·m , 3.1 kgf·m)

  • Page 105: Coolant

    Using tap water may cause engine Coolant Recommendation damage. Use Pro Honda HP coolant or an The factory provides a 50/50 solution of equivalent high quality ethylene glycol antifreeze and water in this motorcycle.
  • Page 106 Increasing the concentration of antifreeze is not recommended because it decreases cooling system performance. Higher concentrations of antifreeze (up to 60%) should only be used to provide additional protection against freezing. Check the cooling system frequently during freezing weather. Servicing Your Honda...
  • Page 107 LEFT CENTER LEFT SIDE If the reserve tank is empty, or if coolant loss is excessive, check for leaks and see your Honda dealer for repair. Remove the left side cover (page Remove the reserve tank cap ( ). Always add coolant to the reserve tank.
  • Page 108 Saf ety Precautions on page the engine is hot can cause the coolant to spray out, seriously Coolant should be replaced by your Honda scalding you. dealer, unless you have the proper tools and service data and are mechanically Always let the engine and radiator qualified.

  • Page 109: Air Cleaner

    Your Honda dealer can help you determine the correct service interval for Improper or lack of proper air cleaner your riding conditions.
  • Page 110 Reinstall the washers and make sure the bolts are tightened securely to the (1) bolts (4) air cleaner specified torque: 2.6 lbf·ft (3.5 N·m , 0.4 kgf·m) (2) washers (5) air cleaner case (3) air cleaner housing cover Servicing Your Honda...

  • Page 111: Crankcase Breather

    (1) crankcase breather tube plug Place a drain pan under the crankcase breather tube plug ( ). Remove the plug to drain the deposits in the tube. Reinstall the crankcase breather tube plug. Servicing Your Honda...

  • Page 112: Final Drive Oil

    Saf ety Precautions on page edge of the opening. Install the oil filler cap and tighten to LEFT REAR the specified torque: 9 lbf·ft (12 N·m , 1.2 kgf·m) (1) oil filler cap (2) oil filler hole Servicing Your Honda...
  • Page 113 15 lbf·ft (20 N·m , 2.0 kgf·m) (2) oil filler cap (3) sealing washer (4) oil filler inspection hole Change the oil with the final drive at normal operating temperature to assure complete and rapid draining. (cont’d) Servicing Your Honda...
  • Page 114 Make sure the final drive oil level is at the lower edge of the oil filler inspection hole ( ). Install the oil filler cap and tighten to the specified torque: 9 lbf·ft (12 N·m , 1.2 kgf·m) Servicing Your Honda...

  • Page 115: Throttle

    Tighten the lock nut and return the throttle cable boot securely over the (1) throttle cable boot adjuster. (2) adjuster (3) lock nut Servicing Your Honda...

  • Page 116: Throttle Inspection

    Check that the throttle assembly is positioned properly and the securing bolts are tight. Check for smooth rotation of the throttle from fully open to fully closed in all steering positions. If there is a problem, see your Honda dealer. Servicing Your Honda...

  • Page 117: Clutch System

    Proper freeplay adjustment allows a smooth, gradual Refer to Saf ety Precautions on page engagement when shifting gears. LEFT HANDLEBAR Improper freeplay adjustment can cause premature clutch wear. (1) clutch lever (cont’d) Servicing Your Honda...
  • Page 118 ( ) increase freeplay ＋ ( ) decrease freeplay − Loosen the upper lock nut ( ). Turn the upper clutch cable adjuster ( ) to obtain the specified freeplay. Tighten the upper lock nut and check the freeplay again. Servicing Your Honda...
  • Page 119 LEFT SIDE Tighten the lower lock nut and check the adjustment. − − ＋ ＋ (4) lower lock nut (5) lower adjusting nut ( ) increase freeplay ＋ ( ) decrease freeplay − (cont’d) Servicing Your Honda...
  • Page 120 Lubricate the clutch cable with a clutch friction discs may be worn. See commercially available cable lubricant your Honda dealer or refer to the official to prevent premature wear and Honda Service Manual (page corrosion.

  • Page 121: Engine Idle Speed

    Engine Idle Speed The best way to assure proper carburetion Idle Speed Adjustment is to see your Honda dealer for regularly scheduled servicing, including carburetor adjustment. Refer to Saf ety Precautions on page RIGHT SIDE Remember, idle speed adjustment is not a ‘‘cure-all’’...
  • Page 122 Place your motorcycle on its side stand on a firm, level surface. Connect a tachometer to the engine. Shift into neutral. Start the engine. Adjust idle speed with the throttle stop screw ( ). Idle speed (in neutral): ± 100 rpm Servicing Your Honda...

  • Page 123: Spark Plugs

    XU20EPR-U (DENSO) spark plug DCPR7E (NGK) extended XU22EPR-U (DENSO) high speed riding Use only the recommended type of spark plugs in the recommended heat range. Using spark plugs with an improper heat range can cause engine damage. Servicing Your Honda...
  • Page 124 Disconnect the spark plug caps ( ). Take care to avoid damaging the spark RIGHT SIDE plug wire when disconnecting the caps. Using a spark plug wrench, remove the spark plugs. (1) overhead cover (2) spark plug caps Servicing Your Honda...
  • Page 125 ( ) carefully. The gap should be: 0.031 0.035 in (0.80 0.90 mm) − − (4) spark plug gap (5) side electrode With the plug washers attached, thread the spark plugs in by hand to prevent cross-threading. (cont’d) Servicing Your Honda...
  • Page 126 Next, tighten the plug again: 1/8 turn after it seats. Improperly tightened spark plugs can damage the engine. If a plug is too loose, a piston may be damaged. If a plug is too tight, the threads may be damaged. Servicing Your Honda...

  • Page 127: Suspension

    Higher spring pre-load traction and comfort are maintained as the provides a firmer ride and is wheels ride over road surfaces. recommended for heavy loads, rough road conditions, and faster, more challenging riding. Servicing Your Honda...
  • Page 128 To adjust, use an appropriate pin spanner or see your Honda dealer. Do not attempt to disassemble, service, or dispose of the damper; see your Honda dealer. The instructions found in this owner’s manual are limited to adjustments of the shock assembly only.
  • Page 129 5 to 1 may damage the shock absorber. Position 1: for a light load and smooth road conditions. Position 2: standard position. Positions 3 to 5: for when the motorcycle is more heavily loaded. (Also increase spring pre-load for stiffer rear suspension.) Servicing Your Honda...

  • Page 130: Brakes

    Brakes The hydraulic braking systems on your air in the brake system. See your Honda motorcycle dissipate the heat generated by dealer to have the air bled from the system. the friction of the brake pads on the brake Brake Fluid Recommendation discs as the wheels are slowed.
  • Page 131 If it comes in contact with your If your inspection indicates a low fluid skin, wash with clean water and, if level, have your Honda dealer add the necessary, call a doctor. recommended brake fluid. RIGHT HANDLEBAR...
  • Page 132 Check the fluid level. Front : It should be above the LOWER level mark ( ). Rear : It should be between the UPPER ( ) and LOWER level ( ) marks. Servicing Your Honda...
  • Page 133 (page RIGHT REAR Check the cutouts ( ) in each pad. If either pad is worn to the cutout, replace both pads as a set. See your Honda dealer for this service. (1) cutouts Servicing Your Honda...

  • Page 134: Tires

    Overinflated tires make inflation and maintenance. your motorcycle ride harshly, are more prone to damage from road hazards, and wear unevenly. The following pages give detailed information on how and when to check Servicing Your Honda...
  • Page 135 Tubeless tires have some degree of self- underinflated. sealing ability if they are punctured. However, because leakage is often very slow, you should look closely for punctures whenever a tire is not fully inflated. (cont’d) Servicing Your Honda...
  • Page 136 200 lbs (90 kg) of ＊ added weight Nails or other foreign objects embedded in the side of the tire or tread. ＊ includes the weight of the rider, Excessive tread wear. passenger, all cargo & all accessories Servicing Your Honda...
  • Page 137 0.06 in (1.5 mm) 0.08 in (2.0 mm) rear Tread Wear If the wear indicators are visible, replace the tire immediately as it is no longer safe. (1) wear indicator (2) wear indicator location mark Servicing Your Honda...
  • Page 138 5 years old. It is also recommended that all tires be removed from service after 10 years from the date of manufacture, regardless of their condition or state of wear. Servicing Your Honda...
  • Page 139 Week damaged. As discussed below, a tire that is repaired, either temporarily or TIRE LABELING EXAMPLE permanently, will have lower speed and performance limits than a new or undamaged tire. (1) tire identification number (TIN) (cont’d) Servicing Your Honda...
  • Page 140 If you have a tire professionally repaired at a non-Honda facility, we recommend that you have the work checked by your Honda dealer. Servicing Your Honda...

  • Page 141: Tire Replacement

    Always use the size and type of tires recommended in this owner’s braking, durability, and comfort. manual. When replacing, use the original equipment tires or equivalent tires of the same size, construction, speed rating, and load range as the originals. (cont’d) Servicing Your Honda...
  • Page 142 Whenever you replace a tire, remember: to rapidly deflate. Have the wheel balanced after the tire is installed. Have the tire replaced by your Honda dealer if possible. If you have a tire professionally replaced at a non-Honda facility, we recommend that you have the work checked by your Honda dealer.

  • Page 143: Side Stand

    The engine should stop as you lower the (1) side stand spring side stand. If the engine doesn’t stop, see your Honda dealer for service. Check that the side stand assembly is working properly. If the side stand is stiff or squeaky, clean the pivot area and lubricate the pivot bolt with clean grease.

  • Page 144: Battery

    Battery posts, terminals and accessories on your motorcycle or do not related accessories contain lead and lead ride frequently, we recommend that you compounds. Wash your hands after charge the battery frequently (see Battery handling. Charging, page Servicing Your Honda...
  • Page 145 You will get the best storage results from Wear protective clothing and a removing the battery and slow (trickle) charging it every 30 days (see Battery face shield, or have a skilled mechanic do the battery Charging, page maintenance. Servicing Your Honda...
  • Page 146 Remove the battery cover ( ) by removing the screws ( ). UNDER SEAT (3) battery cover − (4) negative ( ) terminal lead (5) positive ( ) terminal lead ＋ (1) ICM (2) screws (6) battery Servicing Your Honda...
  • Page 147 Clean the battery box after removing the battery for storage. Dry the battery box and, if paint is missing, re-paint the area. Slow charge the battery (see following section) once every 30 days. Servicing Your Honda...
  • Page 148 An automotive charger can overheat a motorcycle battery and cause permanent damage. (1) ‘‘trickle’’ charger Be sure to read the information that came with your battery charger and follow the instructions on the battery. Improper charging may damage the battery. Servicing Your Honda...

  • Page 149: Appearance Care

    Appearance Care Frequent cleaning and polishing will keep Avoid products that contain harsh your Honda looking newer longer. detergents or chemical solvents that Frequent cleaning also identifies you as an could damage the metal, paint, and owner who values your motorcycle. A plastic on your motorcycle.
  • Page 150 (fuel, oil, coolant, and pressure washers (like those at coin- brake fluid). operated car washes) can damage certain parts of your motorcycle. High pressure water (or air) can damage certain parts of your motorcycle. Servicing Your Honda...
  • Page 151 Wash your motorcycle with a sponge or a soft towel. As you wash, check for heavy grime. If necessary, use a mild cleaner/degreaser to remove the grime. (cont’d) Servicing Your Honda...
  • Page 152 This will help dry the brakes and restore normal braking performance. If the inside of the headlight lens appears clouded immediately after washing, it should clear after a few minutes of riding. Servicing Your Honda...
  • Page 153 To avoid possible scratching or other the windscreen and screen garnish. They damage, use only water and a sof t cloth will damage the plastic. or sponge to clean the windscreen. Servicing Your Honda...
  • Page 154 After drying, apply a high- of the leather cleaner. After cleaning, quality leather conditioner. apply a high-quality leather conditioner (neatsfoot oil, mink oil, etc.) to help protect the bags against weather exposure. Servicing Your Honda...
  • Page 155 Appearance Care Spray Cleaning Your Motorcycle Refer to Saf ety Precautions on page Avoid using spray cleaner products on the tires or suspension components. Suggestions for using spray cleaner(s) follow: (cont’d) Servicing Your Honda...
  • Page 156 If necessary, rub with a sponge. Rinse and dry. Apply a spray cleaner/polish and wipe with a non-abrasive cloth. Dull, corroded chrome or Apply a high quality chrome/aluminum aluminum. polish and wipe with a non-abrasive cloth. Servicing Your Honda...
  • Page 157 Use a wet sponge and mild detergent. Avoid stiff brushes, steel wool, or cleaners containing abrasives or chemical compounds. After washing, rinse with plenty of water and dry with a clean cloth. If the paint is chipped, apply touch-up paint. Servicing Your Honda...
  • Page 158 If a surface on your motorcycle is chipped or scratched, your Honda dealer has touch- up paint to match your motorcycle’s color. Be sure to use your motorcycle’s color code (page ) when you buy touch-up paint.

  • Page 159: Tips

    Tips Here’s a few helpful tips on how to store Storing Your Honda ......152 and transport your Honda, and how to be Transporting Your Motorcycle ..an environmentally responsible You & the Environment ..... motorcycle owner. Tips...

  • Page 160: Storing Your Honda

    Change the engine oil and filter to the Honda Motorcycle Winter Storage (page Guide, available from your Honda dealer Make sure the cooling system is filled (USA only). with a 50/50% antifreeze solution (page We suggest you perform the following Fill the fuel tank.
  • Page 161 Storing Your Honda Drain the carburetor into an approved To prevent rusting in the cylinders, gasoline container and dispose of it in perform the following: an approved manner (page Remove the spark plug caps from the If storage will last longer than one spark plugs.
  • Page 162 Storing Your Honda With the engine stop switch in the Store your motorcycle in an unheated RUN position, press the start button area, free of dampness, away from several times to crank the engine and sunlight, with a minimum of daily distribute the oil.
  • Page 163 –– change the engine oil (page If your motorcycle has been stored for more than two months –– ask your Honda dealer to drain and replace the fuel. Charge the battery (page ) as required. Install the battery.

  • Page 164: Transporting Your Motorcycle

    Transporting Your Motorcycle If your motorcycle needs to be transported, it should be carried on a motorcycle trailer, or a truck or trailer with a flatbed area. Do not tow your motorcycle, as towing can seriously damage the transmission. When contacting a towing or transporting service, be sure to ask if they have a flatbed area, a loading ramp or power ramp to safely lift the motorcycle, and...

  • Page 165: You & The Environment

    You & the Environment Owning and riding a motorcycle can be Recycle Wastes. It’s illegal and enjoyable, but you must do your part to thoughtless to put used engine oil in the protect nature. trash, down a drain, or on the ground. Used oil, gasoline, coolant, and Following are tips on how you can be an cleaning solvents contain poisons that...
  • Page 166 Tips...

  • Page 167: Taking Care Of The Unexpected

    Taking Care of the Unexpected This section discusses the more common General Guidelines ......problems that can occur with your If Your Engine Quits or motorcycle while you’re riding. It tells Won’t Start ......... you how to evaluate each problem and If You Have a Flat Tire ......

  • Page 168: General Guidelines

    Taking Care of the Unexpected Should you ever have a problem while General Guidelines riding, please follow these guidelines: Always put personal safety first. Keeping your motorcycle well-maintained Take time to assess the situation and is the best way to reduce the possibility of your options before deciding what to do.

  • Page 169: If Your Engine Quits Or Won't Start

    If you have a problem starting the but the engine won’t start symptom. − engine or experience poor engine performance the following information − may help you. If you can’t correct the problem, see your Honda dealer. Taking Care of the Unexpected...
  • Page 170 (or dead) battery Charge the battery (page ). If charging doesn’t help, see your Honda dealer. If all possible causes are negative, the starter faulty starter motor motor may be faulty. See your Honda dealer. Taking Care of the Unexpected...
  • Page 171 F looded Engine (page loose or unconnected spark Install the spark plug caps securely. If the engine plug caps still won’t start, see your Honda dealer. loose battery cables Tighten the battery terminal bolts. weak battery Charge the battery (page ).
  • Page 172 Engine starts, but runs poorly. POSSIBLE CAUSE WHAT TO DO idles roughly, too fast, stalls Check engine idle adjustment (page ). If the problem persists, see your Honda dealer. overheating Check the high coolant temperature indicator. Refer to If Y our Engine Overheats, page low oil pressure Check the low oil pressure indicator.
  • Page 173 If applicable, switch to the recommended octane load gasoline (page ) or change your brand of gasoline. If the problem persists, see your Honda dealer. afterfires (backfires) May damage catalytic converters. See your Honda dealer. pre-ignition (runs on after May damage catalytic converters.

  • Page 174: If You Have A Flat Tire

    If a tire has a major puncture or a cut in the tread or sidewall, or the bead has come loose from the rim, there is probably not much you can do except have your motorcycle transported to a Honda dealer Taking Care of the Unexpected...
  • Page 175 If You Have a Flat Tire repaired. Stop frequently and check the air pressure. If the tire is losing pressure, it Riding your motorcycle with a may be unsafe to continue riding. As the temporary tire repair can be risky. tire gets low, it will affect the handling of If the temporary repair fails, you your motorcycle (especially with a...
  • Page 176 If You Have a Flat Tire Inflate the tire: Tubeless tires have Types of Temporary Repairs some self-sealing ability if they are punctured and the result is usually just a The following types of temporary repairs slow leak. If this is the case, you can try generally require a source of air to inflate inflating the tire to see if it will hold air the tire.
  • Page 177 If You Have a Flat Tire Should You Repair or Replace a Tire? We strongly recommend that you replace, not permanently repair, any tire that is punctured or damaged, even if the tire has only a minor puncture. For a full discussion of repairs and replacement, see page Taking Care of the Unexpected...
  • Page 178 Refer to Saf ety Precautions on page We recommend wheel removal be done only by your Honda dealer or another qualified mechanic. Do not attempt to remove the wheel on your own. Wheel removal requires mechanical skill and professional tools.
  • Page 179 If You Have a Flat Tire Remove the fixing bolts ( ) and Remove the front axle bolt ( ), and remove the right brake caliper assembly then loosen the right and left axle pinch ( ) from the fork leg ( ). bolts ( ).
  • Page 180 If this occurs, the axle shaft with the recessed surface ( ) brake system will require service. See of the fork leg. your Honda dealer for this service. LEFT FRONT (5) axle pinch bolts (6) front axle shaft...
  • Page 181 If You Have a Flat Tire Tighten the axle pinch bolts on the left If the clearances between each surface fork leg to the specified torque: of the brake disc and the brake bracket 16 lbf·ft (22 N·m , 2.2 kgf·m) ( ) (not the brake pads) are Tighten the front axle bolt to the symmetrical, follow next step.
  • Page 182 Tighten the axle pinch bolts on the right If a torque wrench was not used for fork leg to the specified torque: installation, see your Honda dealer as soon 16 lbf·ft (22 N·m , 2.2 kgf·m) as possible to verify proper assembly.
  • Page 183 Refer to Saf ety Precautions on page We recommend wheel removal be done only by your Honda dealer or another qualified mechanic. Do not attempt to remove the wheel on your own. Wheel removal requires mechanical skill and professional tools.
  • Page 184 If You Have a Flat Tire RIGHT REAR Remove the wheel and side collar, keeping the muffler on right side. To avoid damage to the brake hose during removal, support the caliper assembly so that it doesn’t hang from the hose. Do not twist the brake hose. Avoid getting grease, oil, or dirt on the disc or pad surfaces.
  • Page 185 The result will be a coated with molybdenum disulfide paste loss of brake fluid. If this occurs, the (USA only: Pro Honda Moly 60 Paste, or brake system will require service. equivalent). See your Honda dealer for this Install the side collar and position the service.
  • Page 186 Tighten the rear axle nut to the If a torque wrench was not used for specified torque: installation, see your Honda dealer as 81 lbf·ft (110 N·m , 11.2 kgf·m) soon as possible to verify proper Install the muffler bracket bolts and assembly.

  • Page 187: If Your Engine Overheats

    If Your Engine Overheats Normally, the temperature of the coolant in the cooling system will rise to a level about midway between cold and boiling. Continuing to ride with an overheated Hot weather may cause the temperature to engine can cause serious engine damage. rise higher than normal.
  • Page 188 If Your Engine Overheats Check the radiator fan. ride. The engine needs repair. Transport If the fan is not working, turn the your motorcycle to a Honda dealer engine off. Open the fuse box (page (page ) and check the radiator fan If the temperature drops to normal, fuse.

  • Page 189: If The Low Oil Pressure Indicator Lights

    If the indicator goes off and there is no leak –– resume riding. If there is a leak –– do not ride the motorcycle until the leak is repaired by a Honda dealer. Taking Care of the Unexpected...

  • Page 190: If A Fuse Blows

    If a Fuse Blows All of the electrical circuits on your The main fuse and spare are located on motorcycle have fuses to protect them the starter magnetic switch behind the from damage caused by excess current right side cover. flow (short circuit or overload).
  • Page 191 If a Fuse Blows RIGHT SIDE Main Fuse Access: To access the main fuse ( ), remove the right side cover (page Disconnect the wire connector ( ) of the starter magnetic switch ( ). Pull the main fuse out. If it is blown ( ), install the spare main fuse ( ).
  • Page 192 If a Fuse Blows CIRCUIT FUSE Circuit Fuse Access: Open the fuse box cover ( RIGHT SIDE (8) blown fuse If you do not have a replacement fuse with the proper rating for the circuit, install one with a lower rating. (6) fuse box cover (7) spare fuses To check or replace a circuit fuse, pull...
  • Page 193 If the replacement fuse of the same rating burns out in a short time, there is probably a serious electrical problem on your motorcycle. Leave the blown fuse in that circuit and have your motorcycle checked by your Honda dealer. Taking Care of the Unexpected...

  • Page 194: If You Crash

    Also, be sure person or vehicle is involved in the crash. to have your Honda dealer check the frame and suspension after any serious If you decide that you are capable of crash.

  • Page 195: If You Lose Your Key

    If you don’t know your key duplicate key made. number, call the dealer where you purchased your Honda. They may have it A lost key won’t be a problem if you take listed in their records. If they don’t, preventative action.

  • Page 196: If Your Battery Is Low (Or Dead)

    Bump starting is also not recommended. If you can’t charge the battery or it appears unable to hold a charge, contact your Honda dealer. Taking Care of the Unexpected...

  • Page 197: Technical Information

    Technical Information This section contains dimensions, Vehicle Identification ......capacities, and other technical data, plus Specifications ........information on government requirements Break-in Guidelines ......and how to break-in your motorcycle. High Altitude Carburetor Adjustment and Other Parts Replacement ........Emission Control Systems ....

  • Page 198: Vehicle Identification

    Vehicle Identification The VIN (vehicle identification number) Serial Numbers is stamped on the right side of steering head and also appears on the Safety The VIN and engine serial number are Certification Label attached to the left required when you register your side of the down tube.
  • Page 199 Vehicle Identification RIGHT SIDE The engine number ( ) is stamped on the top of the crankcase. LEFT SIDE (2) VIN (3) engine number Technical Information...
  • Page 200 Vehicle Identification LEFT SIDE Color Label & Code The color label ( ) is attached to the frame behind the left side cover. Remove the left side cover (page ) to check the label. The color code is helpful when ordering replacement parts.

  • Page 201: Specifications

    Specifications Dimensions 101.4 in (2,575 mm) overall length 37.8 in (960 mm) overall width 44.3 in (1,125 mm) overall height 65.7 in (1,670 mm) wheelbase 5.1 in (130 mm) ground clearance Technical Information...
  • Page 202 API service label, SAE 10W-30, JASO T 903 standard MA, Pro Honda GN4 4-stroke oil (USA & Canada) or Honda 4- stroke oil (Canada only), or an equivalent motorcycle oil after draining: 4.1 US oz (120 cm )
  • Page 203 Specifications Capacities Operator and one passenger passenger capacity maximum weight USA: 404 lbs (183 kg) capacity Canada: 413 lbs (187 kg) rider, passenger, all cargo and accessories Engine Specifications displacement 80.0 cu-in (1,312 cm ) bore & stroke 3.52 × 4.11 in (89.5 ×...
  • Page 204 Specifications Power Transmission 1.935 primary reduction 0.944 secondary reduction 2.818 final reduction gear ratio, 1st 1.900 1.231 0.912 0.778 0.697 final drive shaft Technical Information...
  • Page 205 Specifications Chassis & Suspension 32°00’ caster trail 5.7 in (144 mm) tire size, front 140/80 17M/C 69H − DUNLOP D404F tire size, rear 170/80 15M/C 77H − DUNLOP K555J bias-ply, tubeless tire type tire pressure, front 33 psi (225 kPa , 2.25 kgf/cm ) (cold) tire pressure, rear 33 psi (225 kPa , 2.25 kgf/cm )
  • Page 206 Specifications Lights 12V 60/55W − headlight brake/tail light 12V 21/5W − 12V 5W − license light turn signal lights 12V 21/5W − (front) 12V 21W − (rear) Fuses main fuse 20A, 10A other fuses Technical Information...
  • Page 207 Specifications Torque Specifications 22 lbf·ft (30 N·m , 3.1 kgf·m) engine oil drain bolt engine oil filter 19 lbf·ft (26 N·m , 2.7 kgf·m) 2.6 lbf·ft (3.5 N·m , 0.4 kgf·m) air cleaner housing cover bolts final drive oil drain 15 lbf·ft (20 N·m , 2.0 kgf·m) bolt 9 lbf·ft (12 N·m , 1.2 kgf·m)

  • Page 208: Break-In Guidelines

    Break-in Guidelines Help assure your motorcycle’s future reliability and performance by paying extra attention to how you ride during the first 300 miles (500 km). During this period, avoid full-throttle starts and rapid acceleration. Technical Information...

  • Page 209: High Altitude Carburetor Adjustment And Other Parts Replacement

    To compensate, you can have the carburetor adjusted and other parts replaced for high altitude riding. See your Honda dealer. However, the carburetor and other parts must be returned to standard factory specifications before riding again at lower altitudes (below 5,000 feet, 1,500 m).

  • Page 210: Emission Control Systems

    Emission Control Systems Exhaust Emission Requirements The Vehicle Emission Control The U.S. Environmental Protection Information label ( ) ( ) is attached on Agency (EPA), the California Air the left side of the swingarm. Resources Board (CARB), and LEFT SIDE Environment Canada (EC) require that your motorcycle comply with applicable exhaust emissions standards during its...
  • Page 211 Compliance with the terms of the Distributor’s Warranties for Honda Honda Motor Co., Ltd. utilizes various Motorcycle Emission Control Systems is systems to reduce carbon monoxide, necessary in order to keep the emissions oxides of nitrogen and hydrocarbons.
  • Page 212 Emission Control Systems Secondary Air Injection System Exhaust Emission Control System The exhaust emission control system The secondary air injection system includes a secondary air supply system, introduces filtered air into the exhaust and two oxidation catalytic converters. gases in the exhaust port. The secondary air injection system helps improve No adjustment to these systems should be emission control performance.
  • Page 213 Emission Control Systems Evaporative Emission Control System Crankcase Emission Control System (California only) The engine is equipped with a closed This motorcycle complies with the crankcase system to prevent discharging requirements of the California Air crankcase emissions into the atmosphere. Resources Board (CARB) evaporative Blow-by gas is returned to the combustion emission regulations.
  • Page 214 If you are aware of any of the following CONTROL SYSTEM IS PROHIBITED: symptoms, have the vehicle inspected and U. S. federal law prohibits, or Canadian repaired by your authorized Honda provincial laws may prohibit the following motorcycle dealer. acts or the causing thereof: ( ) The...
  • Page 215 Emission Control Systems AMONG THOSE ACTS PRESUMED Fuel Permeation Emission Control TO CONSTITUTE TAMPERING ARE System THE FOLLOWING ACTS: This vehicle complies with the Fuel Removal of, or puncturing the muffler, Permeation Emission Control regulations baffles, header pipes or any other of the U.S.

  • Page 216: Catalytic Converters

    Park your motorcycle away from gasses without affecting the metals. high grasses, dry leaves, or other flammables. Catalytic converters act on HC and CO. Replacement parts must be original Honda parts or equivalents. Technical Information...
  • Page 217 Catalytic Converters Defective catalytic converters contribute Keep the engine in good running to air pollution, and can impair your condition. engine’s performance. Follow these A poorly running engine can cause the guidelines to protect your motorcycle’s catalytic converter to overheat causing catalytic converters.

  • Page 218: Oxygenated Fuels

    Oxygenated Fuels Some conventional gasolines are being The following are the EPA-approved blended with alcohol or an ether percentages of oxygenates: compound. These gasolines are collectively referred to as oxygenated ETHANOL (ethyl or grain alcohol) 10% fuels. To meet clean air standards, some by Volume areas of the United States and Canada use You may use gasoline containing up to...
  • Page 219 Oxygenated Fuels METHANOL (methyl or wood alcohol) Fuel system damage or performance 5% by Volume problems resulting from the use of an You may use gasoline containing oxygenated fuel containing more than the methanol containing up to 5% methanol percentages of oxygenates mentioned by volume as long as it also contains above are not covered under warranty.
  • Page 220 Technical Information...

  • Page 221: Consumer Information

    Consumer Information This section contains information on your Authorized Manuals ......warranty and how to get an official Honda Warranty Coverage ......Service Manual. Warranty Service ........ Contacting Honda ....... Your Honda Dealer ......The Honda Rider’s Club (USA only) .........

  • Page 222: Authorized Manuals

    Authorized Manuals The Service Manual used by your authorized Honda dealer is available from Helm, Inc. (USA only, Canada: See your Honda dealer to order authorized manuals.) Also available but not necessary to service your model is the Honda Common Service Manual which explains theory of operation and basic service information for various systems common to all Honda motorcycles, motor scooters and ATVs.
  • Page 223 By completing this form you can order the materials desired. You can pay by check or money order, or charge to your credit card. Mail to Helm, Inc. at the address shown on the back of this order form (USA only). Canada: See your Honda dealer to order authorized manuals. Publication Item Description Qty.
  • Page 224 NOTE: Dealers and Companies please provide dealer or company name, and also the name of the person to whose attention the shipment should be sent. Customer Name Attention Street address/P. O. BOX Apartment Number City State Zip Code Daytime Telephone Number Check or money order enclosed payable to Helm Inc.

  • Page 225: Warranty Coverage

    Please read the Warranties Booklet given Almost all of your warranty coverage can to you by your Honda dealer at the time of be extended through the Honda Protection purchase. Be sure to keep your Honda Plan (USA only).

  • Page 226: Warranty Service

    If you aren’t satisfied with your your motorcycle, call the service dealer’s handling of the situation, we department of your Honda dealer. Make suggest you discuss your problem with the an appointment for an inspection and appropriate member of the dealership’s diagnosis.

  • Page 227: Contacting Honda

    If you wish to comment on your We will likely ask your Honda dealer to experiences with your Honda or with your respond, or possibly acknowledge your dealer, please send your comments to the comments directly.

  • Page 228: Your Honda Dealer

    Once you purchase your new Honda, get and products available from the parts familiar with the organization of your department. Honda dealer so you can utilize the full range of services available. The sales department offers the Honda Protection Plan to extend almost all of The service department is there to perform your warranty coverage (USA only).

  • Page 229: The Honda Rider's Club (Usa Only)

    The Honda Rider’s Club (USA only) You may be eligible for a Honda Rider’s Club of America (HRCA) membership with the purchase of your new Honda. You can log on to the HRCA Clubhouse website for details at www.hrca.honda. com.

  • Page 230: Reporting Safety Defects (Usa Only)

    However, NHTSA cannot become involved in individual problems between you, your dealer, or American Honda Motor Co., Inc. Consumer Information...
  • Page 231 Consumer Information...

  • Page 232: Table Of Contents

    Table of Contents The following presents the contents of Odometer/Tripmeter each section of your owner’s manual. Select and Reset Button ......MOTORCYCLE SAFETY ....BEFORE RIDING ........ Are You Ready to Ride? ......Important Safety Information ....Accessories & Modifications ....
  • Page 233 Seat Removal .......... Parking ............ Theft-prevention Tips ......Riding with a Passenger or Cargo ..SERVICING YOUR HONDA .... Bef ore You Service Your Honda The Importance of Maintenance .... Maintenance Safety ........ Important Safety Information .... Periodic Maintenance ......(cont’d) Maintenance Schedule ......
  • Page 234 Table of Contents SERVICING YOUR HONDA (cont’d) Chassis Suspension .......... Service Procedures Brakes ..........Fluids & Filters Tires ............ Fuel ............Side Stand ........... Engine Oil & Filter ......... Coolant ............ Electrical Air Cleaner ......... Battery ..........Crankcase Breather ......
  • Page 235 Contacting Honda ....... If You Crash ........Your Honda Dealer ......If You Lose Your Key ....... The Honda Rider’s Club If Your Battery Is Low (or Dead) ..(USA only) ......... Reporting Safety Defects TECHNICAL INFORMATION ..(USA only) .........

  • Page 236: Index

    ........25 accessories ..........air cleaner ..........101 air pressure, tires ........126 American Honda, contacting ....219 capacity, fuel ......... . 86 apparel, protective ........28 carburetor, altitude adjustment .... . 201 appearance care ........

  • Page 237: Index

    Index component locations, indicators and controls ...... . 10 maintenance ........73 consumer information ......213 emission control systems ..... . 202 coolant ............ . 97 engine, crankcase breather ....... . 103 flooded ..........46 customer service ........
  • Page 238 . 20 contacting ......... 219 fuses ............182 dealer ..........220 Rider’s Club ........221 Honda service manual ......214 horn button ..........25 gap, spark plug ........117 gasohol ..........210 gasoline ..........
  • Page 239 Index identification, vehicle ......190 labels, safety ..........idle speed, engine ........ . 113 limit, weight ..........35 ignition cut-off system, side stand ..43 load limits ..........35 ignition switch ........22 loading guidelines ........
  • Page 240 Index maintenance, neutral indicator ........ . 16,19 component locations ......73 numbers, serial ........190 importance ......... . 60 periodic ..........64 record ..........71 safety ........... 61 odometer ........16,18,25 schedule ..........66 oil, manual, authorized ......
  • Page 241 ......222 pre-ride inspection ........31 rider training ........3, 30 problems, unexpected ......159 Rider’s Club, Honda ......221 protective apparel ........28 riding, basic operation ........41 clothing ..........
  • Page 242 Index spark plugs ..........115 specifications ........193 speedometer ........16, 18 safety, stand, side ..........135 important precautions ......62 start button ..........23 labels ............ starting, reporting defects ....... 222 engine ..........
  • Page 243 Index theft-prevention tips ....... 55 valve, fuel ..........20 throttle, vehicle identification no. (VIN) ... 190 lever ..........107 stop screw ......... 113 tire identification no. (TIN) ..130,131 tires, warranty, air pressure ........
  • Page 244 Memo...

  • Page 245: Quick Reference

    Honda. You’ll also find space to record important notes. The engine of your Honda can be the most expensive component to repair. Proper maintenance, especially the use of the recommended fluids and filters, prevents premature wear and damage.
  • Page 246 Quick Reference Engine No. Ignition Key No. Color Label Owner’s Name Address City/State Phone Dealer’s Name Address City/State Phone Service Mgr. Quick Reference...
  • Page 247 API Service Classification SG or higher except oils labeled as energy conserving on the circular API service label, SAE 10W-30, JASO T 903 standard MA, Pro Honda GN4 4-stroke oil or equivalent 404 lbs (183 kg) Maximum 413 lbs (187 kg)
  • Page 248 Spark Plugs DCPR7E (NGK) or XU22EPR-U (DENSO) high speed riding: Coolant ethylene glycol antifreeze (silicate-free) for aluminum engines in 50/50 solution with Pro Honda HP Coolant or an equivalent distilled water main: Fuses other: 20A, 10A Final Drive Oil Hypoid Gear Oil SAE 80...
  • Page 249 Quick Reference These symbols are used in Controls & Features section: SYMBOL COMPONENT SEE PAGE choke knob START button − engine stop switch − engine stop switch − headlight dimmer switch − headlight dimmer switch turn signal switch horn button Quick Reference...
