KR8000 Mobility Scooters Owner's Manual
ATTENTION
Please read the content of
your owner's manual before
operating the scooter
FULLY CHARGE THE BATTERIES AT
LEAST ONCE A WEEK AS FAILURE TO
DO SO WILL PERMANENTLY AND
SIGNIFICANTLY DAMAGE THE
BATTERIES. THIS IS ESSENTIAL
REGARDLES OF THE SCOOTERS USE.
1 |
P a g e
KR8000 Mobility Scooter
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KR8000 and is the answer not in the manual?

Questions and answers

Related Manuals for KOMFI-RIDER KR8000

Summary of Contents for KOMFI-RIDER KR8000

  • Page 1 KR8000 Mobility Scooters Owner’s Manual ATTENTION Please read the content of your owner’s manual before operating the scooter FULLY CHARGE THE BATTERIES AT LEAST ONCE A WEEK AS FAILURE TO DO SO WILL PERMANENTLY AND SIGNIFICANTLY DAMAGE THE BATTERIES. THIS IS ESSENTIAL REGARDLES OF THE SCOOTERS USE.

  • Page 2: Table Of Contents

    KR8000 Mobility Scooters Owner’s Manual TABLE OF CONTENT Safety Notices ........................3 Electromagnetic Interference (EMI).................5 Electromagnetic Interference (EMI) From Radio Wave Sources ........5 Powered Scooter Electromagnetic Interference (EMI) ............6 Parts...........................7 Operation...........................8 Control Panel ........................8 Power Switch ........................8 High/Low Speed Switch on Power Switch……………………………………………………..8 Forward &...
  • Page 3 KR8000 Mobility Scooters Owner’s Manual INTRODUCTION Congratulations on the purchase of your new KR8000 Mobility Scooter! The advanced, functional compact and highly maneuverable design ensures many years of enhanced trouble-free mobility. Correct use improves your mobility and quality of life.

  • Page 4: Safety Notices

    KR8000 Mobility Scooters Owner’s Manual SAFETY 2.1 SAFETY PRECAUTIONS ■ Lock your seat into place and remove the key before you get on or off your scooter. ■ Lock the seat into position before you operate your scooter. ■ Do not operate your scooter with the seat in the reclined position (if so equipped).
  • Page 5 KR8000 Mobility Scooters Owner’s Manual The One-Rehab scooter is limited to one passenger Do not carry any passengers on your scooter (including children). Do not use this scooter to carry or transport goods. REGULAR USE OF YOUR SCOOTER Please carry out daily inspections. Refer to the “Inspection & Maintenance” section of this manual for inspection procedures.

  • Page 6: Electromagnetic Interference (Emi)

    KR8000 Mobility Scooters Owner’s Manual ELECTROMAGNETIC INTERFERENCE (EMI) This portion of the manual will provide the user with basic information about the problems with (electromagnetic interference), protective measures used either lessen possibility of exposure or to minimize the degree of exposure; this section also shows some conditions that unexpected or erratic movements may cause.
  • Page 7 KR8000 Mobility Scooters Owner’s Manual NOTE: Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM Radios. TV sets, CD player, and cassette players, and small appliances, such as electric shavers and hair dryers, are not likely to cause EMI problems to your mobility scooter.

  • Page 8: Control Panel

    KR8000 Mobility Scooters Owner’s Manual KR8000 PARTS Control Panel Rearview Mirror Front Indicator Basket Headlight Front Bumper Seat Swivel seat lever seat release lever Tiller Adjustment Knob 10. Taillight 11. Rear Indicator 12. Anti-tip Wheels P a g e...

  • Page 9: Power Switch

    KR8000 Mobility Scooters Owner’s Manual OPERATION CONTROL PANEL Headlight/Rear Light Button Hazard Light Button Battery Indicator Indicator Button Horn Button Throttle Lever Key Switch with High Low Function Clock Speed Dial POWER SWITCH Turn the key switch to power ON or OFF To turn the machine from High or Low Speed first Turn the key to the OFF position and then turn the key to either the LOW or HIGH position as required.

  • Page 10: Braking & Stopping

    KR8000 Mobility Scooters Owner’s Manual REDUCE TURNING SPEED SENSOR As a safety feature this scooter incorporates a sensor which slows the speed of the scooter when turning. We would recommend for your own safety, that this sensor is connected at all times and if in doubt, you should stop using the scooter immediately and contact your local scooter dealer.

  • Page 11: Battery Gauge

    KR8000 Mobility Scooters Owner’s Manual BATTERY GAUGE When the key is switched “ON”, the battery gauge will display the battery power capacity by indicating red, yellow and green areas respectively. The green area indicates a full charge from the battery. Red area indicates low power.

  • Page 12: Drive Mode

    KR8000 Mobility Scooters Owner’s Manual FREEWHEEL LEAVER Push the freewheel lever on the scooter down and the scooter will be driven by the motor. Pull the freewheel lever up and the scooter will be in “freewheel” mode and be able to be pushed by hand.

  • Page 13: Charging The Batteries

    KR8000 Mobility Scooters Owner’s Manual BATTERIES & CHARGING Your scooter use tow long-lasting 12-volt deep-cycle batteries that are sealed and maintenance free.  Fully charge the batteries prior to using the scooter for the first time.  FULLY CHARGE THE BATTEREIES AT LEAST ONCE A WEEK AS FAILURE TO DO SO WILL PERMANENTLY AND SIGNIFICANTLY DAMAGE THE BATTERIES.
  • Page 14 KR8000 Mobility Scooters Owner’s Manual How can I get maximum range or distance per charge? ■ Always fully charge your scooter’s batteries prior to your daily use. ■ Maintain the correct air pressure in your scooters tyres at all times.
  • Page 15 KR8000 Mobility Scooters Owner’s Manual The following steps will maximise the batteries` life and efficiency: 1. Fully recharge any new battery prior to its initial use. This charging cycle brings the battery to about 88% of its peak performance level.

  • Page 16: Inspection & Maintenance

    KR8000 Mobility Scooters Owner’s Manual INSPECTION & MAINTENANCE DAILY CHECKING Check the following items before driving. If you find anything abnormal contact your scooter dealer for further inspection before using it. Item What to Look For Handle Bar Is it tight?
  • Page 17 KR8000 Mobility Scooters Owner’s Manual Fuse There are two fuses on your scooter. One is located inside the control panel. The other is near the main wire of the controller. If the power is switch ON and the battery indicator does not light up, check the fuse (as indicated below).

  • Page 18: Troubleshooting

    KR8000 Mobility Scooters Owner’s Manual TROUBLESHOOTING If you have any problems with your scooter this table is a guide to help you in getting your scooter operating. If you are unable to get your scooter operating, please contact your mobility dealer.
  • Page 19 KR8000 Mobility Scooters Owner’s Manual The diagnostic flash codes for your scooter are designed to help you perform basic troubleshooting quickly and easily. A diagnostic flash code flashes from the diagnostic light in the event one of the conditions listed below develops.

  • Page 20: Specifications

    KR8000 Mobility Scooters Owner’s Manual SPECIFICATIONS Model KR 8000 136.5KG (21.5 Stone.) Max. Weight Capacity Maximum Speed 8 mph Estimated Range 32km (20 miles) Maximum Grade/Incline 12° 59" (1500mm) Turning Radius Ground Clearance 3” Overall Dimensions Length 46.25” (1175mm) Width 22.25”...

  • Page 21: Limited Warranty

    KR8000 Mobility Scooters Owner’s Manual WARRANTY WARRANTY POLICY: LIMITED WARRANTY. IMPORTANT NOTICE – TO ENSURE THIS WARRANTY IS VALIDATED IF HAS TO BE COMPLETED AND RETURNED TO ONE REHAB WITHIN 14 DAYS OF PURCHASE 10.1 TWO-YEAR LIMITED WARRANTY Two years on all structural frame components; fork, seat post, and frame.
  • Page 22 KR8000 Mobility Scooters Owner’s Manual 10.4 WARRANTY EXCLUSIONS 1. ABS plastic shrouds and footrest covers (wear items are not warranted) 3. Tyres and Anti-tip Wheels (wear items are not warranted) 4. Upholstery and seating (wear items are not warranted) 5. Motor Brushes 6.
  • Page 23 KR8000 Mobility Scooters Owner’s Manual Important This warranty is void if the original scooter serial number tag is removed or altered. To validate the warranty this form must be filled online (where applicable) or posted to One Rehab (Unit 1, Fernwood Estate, Shillinglee Road, Chiddingfold, GU8 4SX within 14 days of purchasing the scooter.
  • Page 24 KR8000 Mobility Scooters Owner’s Manual WARRANTY REGISTRATION KR8000 Mobility Scooter Please Print Mandatory information – this must be completed and returned to validate the warranty. Model Serial Number Date Purchased Owner Name Address City County Postcode Signature Telephone Dealer Name Dealer Phone Optional Information –...
