  • Page 1: Air Conditioner

    OWNER’S MANUAL MANUEL DU PROPRIETAIRE BETRIEBSANLEITUNG MANUALE DEL PROPRIETARIO MANUAL DEL PROPIETARIO ΟΔΗΓΙΕΣ ΧΡΗΣΗΣ MANUAL DO UTILIZADOR РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ BRUKSANVISNING AIR CONDITIONER (SPLIT TYPE) Not accessible to the general public CLIMATISEUR (TYPE SEPARE) Vente interdite au grand public KLIMAGERÄT (SPLIT-TYP) Kein öffentlicher Zugang CONDIZIONATORE D’ARIA (TIPO SPLIT) Non accessibile a clienti generici...

  • Page 2: Table Of Contents

    CONTENTS/SOMMAIRE ENGLISH ACCESSORIES (SOLD SEPARATELY)........1 Thank you very much for purchasing TOSHIBA Air Conditioner. SAFETY PRECAUTIONS............... 1 Please read this owner's manual carefully before using your Air PARTS NAME ................4 Conditioner. PARTS NAME OF RECEIVER SECTION ........5 •...
  • Page 3 INHALT/INDICE DEUTSCH ZUBEHÖR (GESONDERT ERHÄLTLICH) ........1 Wir danken Ihnen, dass Sie sich für ein TOSHIBA Klimagerät SICHERHEITSVORKEHRUNGEN..........1 entschieden haben. TEILEBEZEICHNUNGEN .............. 4 Bitte lesen Sie, bevor Sie Ihr Klimagerät benutzen, diese TEILEBEZEICHNUNG DES EMPFÄNGERS ......... 5 Betriebsanleitung sorgfältig.
  • Page 4 ΕΛΛΗΝΙΚΑ ΠΑΡΕΛΚΟΜΕΝΑ (ΠΩΛΟΥΝΤΑΙ ΞΕΧΩΡΙΣΤΑ) ......1 Σας ευχαριστούμε πολύ που προτιμήσατε για την αγορά σας ένα ΠΡΟΦΥΛΑΞΕΙΣ ΑΣΦΑΛΕΙΑΣ............1 Κλιματιστικό TOSHIBA. ΟΝΟΜΑ ΤΜΗΜΑΤΩΝ ..............4 Παρακαλούμε διαβάστε προσεχτικά τις οδηγίες χρήσης πριν από τη ΟΝΟΜΑΣΙΑ ΤΜΗΜΑΤΩΝ ΤΟΥ ΔΕΚΤΗ ......... 5 χρήση...
  • Page 5 ACESSÓRIOS (VENDIDO SEPARADAMENTE)......1 Agradecemos o facto de ter adquirido este aparelho de ar PRECAUÇÕES DE SEGURANÇA..........1 condicionado da TOSHIBA. NOME DAS PARTES ..............4 Lei atentamente o presente manual do utilizador antes de utilizar o NOME DAS PEÇAS DA SECÇÃO RECEPTORA......5 aparelho de ar condicionado.
  • Page 6 INNEHÅLL SVENSKA TILLBEHÖR (SÄLJES SEPARAT) ..........1 Tack för att du ville köpa denna luftkonditioneringsapparat från FÖRSIKTIGHETSÅTGÄRDER SOM GÄLLER SÄKERHETEN..1 TOSHIBA. DELARNAS BENÄMNING ............. 4 Läs denna bruksanvisning noga innan du använder DELARNAS BENÄMNING I MOTTAGNINGSSEKTIONEN ... 5 luftkonditioneringsapparaten.

  • Page 7: Accessories (Sold Separately)

    ACCESSORIES (SOLD SEPARATELY) Remote controller Battery (two pcs.) Remote controller holder Standard 4-way cassette panel optional parts SAFETY PRECAUTIONS This appliance is not intended for use by person (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 8 MOVEMENT AND REPAIR WARNINGS • Do not attempt to move or repair the unit by yourself. Do not disassemble the unit. As there is high voltage inside the unit, you may receive an electric shock. This must be carried out by a qualified professional. •...
  • Page 9 • Remote control batteries - Insert with the polarity signs (+ and –) in the correction orientation. - Do not recharge. - Do not leave batteries in the remote control that have exceeded the recommended usage period displayed on the battery or that are used up.

  • Page 10: Parts Name

    PARTS NAME Indoor unit Earth screw Button Located in the electric Button to open/close the parts box suction grille Discharge louver of discharge port Change the direction of the air to be discharged according to cool/ heat mode. Suction inlet grille The air in the room is sucked in through this grille.

  • Page 11: Parts Name Of Receiver Section

    PARTS NAME OF RECEIVER SECTION Receiver section Display panel The operating conditions are shown below. a RESET button b OPERATION indicator (Green) The operation indicators flash rapidly (5 times per second) when a safety protection feature is activated. c TIMER indicator (Yellow) d Remote controller sensor RESET button If you misplace or loose the remote controller or the...

  • Page 12: Parts Name Of Remote Controller

    PARTS NAME OF REMOTE CONTROLLER a START/STOP button o TIMER button Push the button to start operation. Use this button to change the clock, to set the On and Off (A receiving beep is heard.) durations. Push the button again to stop operation. To forward the time, push the “TIMER ”...

  • Page 13: Names And Functions Of Indications On The Remote Controller

    NAMES AND FUNCTIONS OF INDICATIONS ON THE REMOTE CONTROLLER Display All indications, except for the clock indication, are displayed by pushing the START/STOP button. a Transmission mark This transmission mark indicates when the remote controller transmits a signal to the indoor unit. b Mode display Indicates the current operation mode.

  • Page 14: Preparation And Check Before Use

    PREPARATION AND CHECK BEFORE USE Loading the remote controller batteries. • Slide off the cover while a Remove the cover and insert the batteries. pushing the sides. b Push the RESET button. The clock display flashes. Adjust the clock. Place back the cover. •...

  • Page 15: Handling The Remote Controller

    HANDLING THE REMOTE CONTROLLER CAUTION • The air conditioner will not operate if curtains, doors or other materials are blocking the signals sent from the remote controller to the indoor unit. • Prevent any liquid from falling onto the remote controller. •...

  • Page 16: Automatic Operation

    AUTOMATIC OPERATION When you set the air conditioner in AUTO mode, it will automatically select either cooling, heating, or fan only operation depending on the outdoor temperature. (Refer to page 17.) In addition, fan speed is automatically controlled. Start a START/STOP button Push this button to start the air conditioner.

  • Page 17: Cooling/Heating/Fan Only Operation

    COOLING/HEATING/FAN ONLY OPERATION Start a START/STOP button Push this button to start the air conditioner. b Mode select button (MODE) Select Cool , Heat (For heat pump models), Fan only (For cooling only models) c Temperature button ( Set the desired temperature. When the air conditioner is in FAN ONLY operation, the temperature display is not displayed.

  • Page 18: High Power Operation

    HIGH POWER OPERATION High power (Hi POWER) • The High power (High power operation) mode automatically controls room temperature, operation mode so that the room is quickly cooled in summer and warmed in winter. (Refer to page 17.) Setting High power mode a Hi POWER button Push the Hi POWER button.

  • Page 19: Timer Operation

    TIMER OPERATION ON timer and OFF timer Setting Timer a ON/OFF TIMER button Push the ON or OFF TIMER buttons as required. • The previous timer setting is displayed and flashes at the same time as the ON/OFF TIMER display. b TIMER button Push the TIMER...
  • Page 20 Combined timer (Setting both ON and OFF timers simultaneously) OFF timer —> ON timer (Operation —> Stop —> Operation) This feature is useful when you want to stop the air conditioner after you go to sleep or away from home and to start it again in the morning when you wake up or you return home.

  • Page 21: Memory/Preset Operation

    MEMORY/PRESET OPERATION Store the frequently used operation setting by using the MEMO button for convenience. Start the air conditioner in the operation mode that you want the remote controller to memorize. Push the button as follows while the air conditioner is in operation. a MEMO button Push this button briefly to store the setting.

  • Page 22: Adjusting Air Flow Direction

    ADJUSTING AIR FLOW DIRECTION • Adjust the air flow direction properly. Failure to do so could cause discomfort and cause uneven distribution of room temperature. • When the air conditioner stops, the louver (adjustment plate of up/down air flow direction) directs upward automatically. •...

  • Page 23: How The Air Conditioner Works

    HOW THE AIR CONDITIONER WORKS Automatic Operation As shown in Figures 1 and 2, Automatic Operation mode selects the operation based on the room temperature data (Ta) when operation begins. Heat pump models Cooling only models Room temperature when operation begins Room temperature when operation begins or when selected again or when selected again...

  • Page 24: Hints For Economical Operation

    HINTS FOR ECONOMICAL OPERATION Maintain room temperature at a comfortable level Clean air filters The clogged/dirty air filter impairs the performance of the air Clean, please. conditioner. Gee, chilly Never open doors and windows more often than necessary To keep cool or warm air in the room, never open doors and windows more often than necessary.

  • Page 25: Maintenance

    MAINTENANCE Cleaning of the air filter WARNING Cleaning of the air filter and other parts of the air filter can involve dangerous work in high places, therefore ensure work is carried out by qualified service personnel. Do not attempt it yourself. NOTE For Air conditioning systems which are operated regularly, cleaning and maintenance of the indoor/outdoor units are strongly recommended.

  • Page 26: Air Conditioner Operation And Performance

    AIR CONDITIONER OPERATION AND PERFORMANCE 3 minutes protection function The outdoor unit will not operate for approximately 3 minutes after the air conditioner has been immediately restarted after being stop, or the power supply has been turned on. This is to protect the system. Power failure Power failure during operation stops the unit completely.

  • Page 27: Re-Installation

    RE-INSTALLATION DANGER Ask the dealer or an installation professional to re-install the air conditioner in a new location and to observe the following items. If the air conditioner is incorrectly installed yourself, it may cause a risk of an electric shock or a fire. Do not install the air conditioner in the following places •...
  • Page 28 Before you ask for servicing or repairs, check the following points. Inoperative • The main power switch is turned off. • The circuit breaker is activated to cut off power supply. • The main power fuse has blown. • No electrical current Does not cool well or heat well •...

  • Page 29: Trouble And Causes (Concerning Remote Controller)

    TROUBLE AND CAUSES (Concerning Remote Controller) Before you ask for servicing or repair work, check the following points: Setting Change is Impossible Symptoms Causes Description The fan speed can not be • Check whether the MODE indicated When the automatic mode is selected, changed.
