InstallatIon and
owner's InstrUCtIons
GS Baseline Series
Wall-Mounted Goal Systems

table of Contents

Safety Instructions ............................................... 2
Goal Specifications .............................................. 3
Parts List - GS72, GS60 & GS54 ........................ 4
Frame Attachment ................................................ 5
Backboard Attachment ......................................... 5
Rim Attachment ................................................... 6
Ready to Play ....................................................... 7
Warranties.............................................Back Cover

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GS72 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Goalsetter Systems GS72

Summary of Contents for Goalsetter Systems GS72

  • Page 1: Table Of Contents

    Contents Safety Instructions ..........2 Goal Specifications ..........3 Determine Installation Specifications ....3 Parts List – GS72, GS60 & GS54 ......4 Frame Attachment ..........5 Backboard Attachment ......... 5 Rim Attachment ........... 6 Ready to Play ............7...

  • Page 2: Safety Instructions

    Your goal may have product this type of activity. improvements and options not yet contained in this manual. Goalsetter Systems, Inc. reserves the right to make changes at any radius of the goal location. time without notice or obligation.

  • Page 3: Goal Specifications

    — — — Playing Surface IMPORTANT Goalsetter Systems, Inc. cannot assume liability for the installation Systems recommends ® consulting a professional architect or contractor to determine a safe wall anchoring system to match the wall construction being used in your application.

  • Page 4: Parts List - Gs72, Gs60 & Gs54

    Parts List - GS72, GS60 & GS54 Baseline 2 Backboard DESCRIPTION Assembly Frame — — — — — — Hardware 4 places Rim and Net Assembly Bolt, Flat Washer, / " or / " Nut, / "-16 UNC Frame Rim & Net Assembly &...

  • Page 5: Frame Attachment

    Frame Attachment WARNING Two or three people in good physical condition and capable of " lifting at least 90-100 lbs. (40-45 kg) each are recommended for safe installation and assembly. Step 1: Unpack frame. Determine where to place frame on mounting surface.

  • Page 6: Rim Attachment

    Rim Attachment NOTE: Your warranty card is located TIME OUT TIP: behind protective sheeting. You MUST fill out and return this card to activate your warranty. Step 1: Unpack rim. Remove any cardboard edge protectors and protective sheeting from backboard. IMPORTANT loose, make sure to have them seated properly when tighten- ing rim bolts.

  • Page 7: Ready To Play

    IF RUST OR CORROSION HAS PENETRATED ANY COMPONENT, DO NOT ALLOW PLAY ON THE GOAL AND REPLACE PARTS IMMEDIATELY. use parts provided by Goalsetter Systems, Inc. Use of other parts (a) may cause the goal system to fail, (b) could result in death, serious injury or property damage, and (c) will void the warranty.

  • Page 8: Warranties

    YOU MUST FILL OUT AND systems. MAIL IN THIS CARD IN ORDER TO HAVE A VALID WARRANTY. alteration of product and any other events beyond the control of Goalsetter Systems, Inc. You may also fill out a warranty registration online at www.goalsetter.com.
