Instruction Manual
R-4int
F M
I N T E R N E T R a d i o w i t h D o c k i n g f o r i P o d ®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R-4int and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teac R-4int

Summary of Contents for Teac R-4int

  • Page 1 Instruction Manual R-4int I N T E R N E T R a d i o w i t h D o c k i n g f o r i P o d ®...
  • Page 2 Safety Information 9. Do not defeat the safety purpose of the polarized or grounding - type plug. a polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.

  • Page 3: Fcc Information

    FCC Information FCC part 15.19 This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC part 15.21 Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 4 Safety Precautions To achieve the utmost in enjoyment and performance, and in order to become familiar with its features, please read this manual carefully before attempting to operate the unit, this will assure you years of faithful, trouble free performance and listening pleasure. Important Notes •...

  • Page 5: Safety Instructions

    Safety Instructions Some Do’s And Don’ts On the Safe Use Of Equipment This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured. DO read the operating instructions before you attempt to use the equipment.

  • Page 6: Table Of Contents

    Contents Safety Information Safety Precautions Safety Instructions Package Content Internet Radio Quick start Guide What you need before you can use your Internet Radio ............3 Controls Overview (a) ......................4 Controls Overview (b) ......................5 Setup Wizard ........................6 How to select a station through Podcasts ............15 How to get Access code ..................15 How to add station to ‘My favourites’..............16 How to add station to ‘My Added Stations’...
  • Page 7 Contents page...

  • Page 8: Safety Information

    Package Content Main unit adapter Instruction Manual...

  • Page 9: Internet Radio Quick Start Guide

    Internet Radio Quick start Guide What you need before you can use your Internet Radio ☺ Thanks for your buying! Before you use it, you need to know followings: LAN Setting: • Make sure the internet environment is ready and the network settings is available for LAN (ADSL or Cable Modems is highly recommended).

  • Page 10: Safety Precautions

    Controls Overview (a) Unit Front Overview Control Internet iPod mode Press to turn on/off Radio Press to convert among Internet, Music player, FM, iPod and AUX IN mode in MODE/MENU turn. Press and hold to enter menu options. BACK Press to return to previous menu page INFO Press to Display Queue information Press to decrease volume level...

  • Page 11: Controls Overview (B)

    Controls Overview (b) Unit Top Overview Remote Control Overview Standby/on button ALARM 1, ALARM 2 button MODE button iPod mode, press to play/pause iPod mode, press to repeat iPod mode, Press Press previous or next track scroll up or down MENU button SNOOZE button SELECT button...

  • Page 12: Setup Wizard

    Setup Wizard Step 1 - Power up Radio 1. Connect to your Internet Radio adapter and ensure the power LED is lighting up. In use, Radio can be switched on or off by press button. For initial use, it will ask you ‘Setup wizard’. Step 2 –...
  • Page 13 4. Turn to your prefer ‘Daylight saving’ status, and then press SELECT to confirm. 5. Turn to your local ‘Wlan region’, and then press SELECT to confirm. 6. Turn to your prefer ‘SSID’, press SELECT to confirm. Radio will save it in memory. Note: In some cases radio may find more than one network.
  • Page 14 Turn to cycle through the alpha-numeric character list, press SELECT to select an appointed character. Note: WEP/WPA pass codes are case-sensitive. If you make a mistake while entering your password, select ‘ ’ icon to delete a character. Note: a.> for , its full name is Backspace.

  • Page 15: Access Wireless Network

    Access wireless network 1. After successfully ‘setup wizard’, it will show you as below, . Or, in use, you can by press and hold MODE/MENU. 10. While cursor point to < Internet radio >, press SELECT. While cursor point to < Station list >, press SELECT to confirm.

  • Page 16: Choosing A Station

    Choosing a station After your radio has successfully connected to network, you are ready to select a station. 1. Turn to < Station list >, and then press SELECT to confirm. 2. Turn to < Stations >, and then press SELECT to confirm. 3.
  • Page 17 a. Turn to < Genre >, press SELECT to confirm. b. Turn to your selecting type of content, press SELECT to confirm. Turn until the display shows the station you want, press SELECT to confirm. Note: a. Some radio stations do not broadcast 24 hours per day, and some stations are not always on-line. b.

  • Page 18: Connecting To Wired Network

    Connecting to wired network Step 1 – Choose LAN Setting Note: a. make sure LAN cable connecting to LAN socket already. 1. Press and hold MODE/MENU to goes into ‘Main Menu’, and then turn to < System setup >, press SELECT to confirm. 2.
  • Page 19 Step 2 – Enter Internet Radio mode 1. Press BACK repeatedly to goes into this mode. Or, press MODE/MENU repeatedly until <Internet Radio> is showing up, stop pressing. Note: Press MODE/MENU, you can view Internet Radio, Music player, FM and iPod, AUX mode in turn. Step3 –...
  • Page 20 How to shift to wireless network Step 1 – Choose WLAN Setting 1. Refer ‘choose LAN setting’, which u can find at page 12, turn to < Wireless >, press SELECT to confirm. 2. While cursor point to < DHCP enable >, press SELECT to confirm. 3.

  • Page 21: How To Select A Station Through Podcasts

    How to select a station through Podcasts 1. After your radio has successfully connected to network, turn to < Podcasts >. 2. Press SELECT to confirm, and then turn to your favorite option. 3. Press SELECT to confirm, and then step by step to your purpose program. How to get Access code 1.

  • Page 22: How To Add Station To 'My Favourites

    How to add station to ‘My favourites’ ☺ 1. visit website: http://www.wifiradio-frontier.com ☺ 2. Click on the register link. ☺ 3. Create account login, you need an Access Code to complete it, which refer to page 15. Note: For next your visiting this website as a member, please remember your registered ‘Email address’...

  • Page 23: How To Add Station To 'My Added Stations

    How to add station to ‘My Added Stations’ ☺ 1. Visit website: http://www.wifiradio-frontier.com ☺ 2. Login as a member(at previous page, you registered). ☺ 3. You will able to take advatage of the various additional features and services offered by the Frontier internet Radio Portal.

  • Page 24: Changing The Station Information

    Changing the Station Information It is possible to view the information that is displaying on the second line of the display when listening Internet program. To view more information, you can press INFO repeatedly. 1. Description of Station This is scrolling text information supplied by the Internet station. It may comprise information on music titles or details of the programme which is provided by the broadcaster.

  • Page 25: Music Player Mode

    Music player Mode Note: To play this order, read appendix at first, which at following pages is highly recommending! A. PLAY SHARED MEDIA 1. Press MODE/MENU repeatedly until < Music player > is showing up. turn Note: Or, enter < Main menu >, and then <...

  • Page 26: Fm Mode

    FM Mode A. GENERAL OPERATION Press MODE/MENU repeatedly until < FM Radio > is showing up. For initial use, it will start at the beginning of the FM frequency range (87.50MHz). Otherwise, the last listened FM station will be selected. Note: to enter this mode, you may also press BACK to go back to ‘Main menu’, and then turn SELECT to <...
  • Page 27 C. AUDIO SETTING FM mode, at any step by press BACK to enter, and then turn to < Audio setting >, press SELECT to confirm. Turn to select ‘YES’ or ‘NO’, and then press SELECT to confirm.

  • Page 28: Ipod Mode

    iPod Mode You can play the music files stored on your iPod through the stereo speakers. Docking your iPod 1. Insert the Dock Adapter that fits your iPod model. The adaptor No. is marked at the back or side of each dock adapter. Apple’s adapter no.

  • Page 29: Aux In Mode

    AUX IN Mode 1. Press MODE/MENU repeatedly until < AUX in > is showing up. Note: Or enter ‘MAIN MENU’, and then turn to < AUX in >, press SELECT to confirm. 2. Through a cable connection, your radio can be transformed into a high quality digital audio speaker system.

  • Page 30: General Operation

    General Operation Return to Main Menu Simply press and hold MODE/MENU button, and then turn to < Main menu >. Alternatively, you can move back to radio’s top-line < Main menu >, at any time by pressing the BACK button. Setting Equaliser Note: set it can be change your radio timbre.

  • Page 31: Changing The Station Information

    Changing the Station Information It is possible to view the information that is displayed on the second line of the display when listening Internet Radio program. To view more information, you can press INFO repeatedly. Note: for this function, ‘AUX in mode’ is out of service.

  • Page 32: Setting Station Presets

    Setting Station Presets Your Radio can store 10 Internet and 10 FM stations preset, To preset current station: 1. Press and hold one of PRESET buttons 1-10 on remote control, until it say: Selecting a Preset station To select a stored station: 1.

  • Page 33: Setting Clock

    Setting Clock 1. It can be activated from < Main menu > < System settings > < Time/Date > < Set Time/Date >. 2. Press SELECT to confirm, and then turn to set date, press SELECT to confirm, using the same method to set month, year, hour and minutes.
  • Page 34 Set hour format Turn to < Set format >, press SELECT to confirm. 2. Turn to your selecting one, press SELECT to confirm. Set timezone 1. Turn to < Set Timezone >, press SELECT to confirm. 2. Turn to your location timezone, press SELECT to confirm. Until now, the setting clock is perfect!

  • Page 35: Daylight Savings

    Daylight savings 1. It can be activated from < Main menu > < System settings > < Time/Date > < Daylight savings >, press SELECT to confirm. 2. Turn to ‘ON’, press SELECT to confirm.

  • Page 36: Setting Alarm

    Setting Alarm Note: Setting Alarm, make sure Setting Time at first. 1. Press ALARM 1 or ALARM 2 on remote control directly to enter. Alternatively, enter < Main menu > < Alarms >, press SELECT to confirm. 2. Turn to the one you want setting, press SELECT once more. 3.
  • Page 37 5. Press SELECT to confirm, turn to < Mode: Internet radio > press SELECT to confirm, and then turn to your purpose one. Note: Alternatively, you may also turn to < Preset: Last listened > to choice alarm sound. 6. Press SELECT to confirm, and then turn to <...
  • Page 38 The display will show ‘Alarm Saved’ for 3 seconds, Alarm icon appeared. To check alarms status, press to enter standby mode. When alarm is coming, press any button to deactivate it, if you touch SNOOZE/SLEEP, which located at top of unit, will stop it between 5-30 minutes, interval time is 5 minutes per step. Note: While in SNOOZE function, the relative alarm should be twinkling, and shows how long it will be elapsed.

  • Page 39: Sleep Function

    Sleep Function 1. Directly press SLEEP on remote control. Alternatively, press and hold MODE/MENU to < Main menu > < Sleep >, press SELECT to confirm. 2. Turn to define the sleep period which between 0 – 60 minutes. 3. When your purpose period is appeared, simply stop turning Note: a.

  • Page 40: System Settings

    System settings Network setup Note: a. Use this if you take the Internet Radio to another building where you want to use it. b. Enable you to scan again for connection to another wireless network, or to manually configure the network parameters.

  • Page 41: Factory Reset

    Factory reset Note: running this will completely erase your radio’s memory, clearing all WEP/WPA codes and user settings. This will effectively return to its default factory settings. It can be activated from < Main menu > < System settings > <...

  • Page 42: Software Updates

    Software Updates It can be activated from < Main menu > < System settings > < Software update >, press SELECT to confirm. 2. Turn to < Auto- check setting >, press SELECT, and then turn to < YES >. 3.

  • Page 43: How To Enter Setup Wizard

    How to enter Setup wizard It can be activated from < Main menu > < System settings > < Setup wizard >, press SELECT to confirm. 2. Then step by step to set it. SW Version and Radio ID 1. It can be activated from < Main menu > <...

  • Page 44: Setting Backlight

    Setting Backlight A. Setting Power-On level 1. It can be activated from < Main menu > < System settings > < Backlight >, and then press SELECT to confirm. 2. While cursor point to ‘Power-On level’, press SELECT to confirm. 3.

  • Page 45: Appendix

    Appendix Step 1: Set Up Media Sharing in WMP 11 After you download and install Windows Media Player 11 for Windows XP and connect your Radio to the network, you need to set up media sharing so that you can share music with your Radio. The following steps describe how to set up media sharing in Windows Media Player 11.

  • Page 46: Step 2: Play Music On The Internet Radio

    3. Check the “share my media to” box. In the list, click your Radio *, click Allow, the selected device will now show a green tick and then click OK. If your device does not appear in the list of devices, perform the following steps; a.

  • Page 47: Set Up Media Sharing In Mac Os

    Set Up Media Sharing in MAC OS Using the Radio with a MAC will require Windows File Sharing. MAC OS 9 and earlier versions of the OS will need extra software to use Windows File Sharing, but MAC OS X 10.2 and later versions have Windows File Sharing built into the OS.

  • Page 48: Troubleshooting

    Troubleshooting If you experience any trouble with your wireless Internet Radio, then you may find it useful to visit the help section on our webpage: http://www.wifiRadio-frontier.com If you have trouble connecting the Radio to your wireless network, these steps may help to resolve the problem: 1.

  • Page 49: Specification

    Specification ITEMS DESCRIPTION ® Specifications: FM/INTERNET Radio with Docking for iPod Audio Output: 10Wrms X 2 (FM) 87.50 – 108.00 MHz Frequency Ranges: LCD Display: High resolution display Power Requirements: AC Power Input: 100-240VAC, 50-60HZ (for use, please refer rear panel silk-screen) Speaker: 8 ohm Dimension:...
