Teac SR-3DAB Owner's Manual

Hi-fi table radio / cd for ipod / iphone
Hide thumbs
Table of Contents

Advertisement

Quick Links

77-20SR00300020
SR-3DAB
Hi-Fi Table Radio / CD for iPod / iPhone
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR-3DAB and is the answer not in the manual?

Questions and answers

Patrick Meehan
January 26, 2025

The standby/on button is stuck out of position. I can only switch on and off with the remote contrtol

0
1 comments:
Mr. Anderson
May 14, 2025

To fix a stuck standby/on button on a Teac SR-3DAB, try the following steps:

1. Unplug the unit: Disconnect it from the power point to turn it off fully, since it only goes into standby otherwise.

2. Check for physical obstruction: Inspect the standby/on button for dirt or debris and clean it gently if needed.

3. Use the remote control: If the button is unresponsive, try using the remote control to operate the power function.

4. Power cycle: Leave the unit unplugged for 1–2 hours to allow it to reset, especially if condensation or temperature change may have affected it.

If the issue continues, the button mechanism may be damaged and require repair.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Teac SR-3DAB

Summary of Contents for Teac SR-3DAB

  • Page 1 77-20SR00300020 SR-3DAB Hi-Fi Table Radio / CD for iPod / iPhone OWNER’S MANUAL...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, 3) Heed all warnings. D O N O T R E M O V E C O V E R ( O R B A C K ) . N O U S E R - SERVICEABLE PARTS INSIDE.
  • Page 3 • I F Y O U A R E E X P E R I E N C I N G P R O B L E M S W I T H T H I S MPEG Layer-3 audio coding technology licensed from Fraunhofer PRODUCT, CONTACT TEAC FOR A SERVICE REFERRAL. DO IIS and Thomson.

  • Page 4: Table Of Contents

    Contents Before Using the Unit Read this before operation Thank you for choosing TEAC. Read this manual carefully to get the best performance from this unit. • Depending on the electromagnetic waves used by a television broadcast, if a TV is turned on near this unit while Important Safety Instructions .

  • Page 5: Battery Precautions

    Battery Precautions Remote Control Unit • Be sure to insert the batteries with correct positive “+” and The included remote control unit allows the unit to be operated negative “ - ” polarities. from a distance. When using the remote control, point it towards the remote •...

  • Page 6: Discs

    CD standard may not play back correctly in this player. If you use such discs in this unit, TEAC Corporation and its • Never use a stabilizer. Using commercially available CD subsidiaries cannot be responsible for any consequences stabilizers with this unit will damage the mechanisms and or guarantee the quality of reproduction.

  • Page 7: Connections

    Connections (1) CAUTION: • Turn off the power (set to standby) before making connections. • Read the instructions of each device you intend to use with this unit. • Be sure to connect each plug securely. To prevent hum and noise, do not bundle the connection cords. AC wall socket VIDEO...

  • Page 8: Emergency Switch

    Connections (2) Emergency Switch DC IN Connect the provided AC adapter to this jack. Then connect If the disc cannot be ejected, remove the disc by following procedure. the AC adapter's plug to the AC wall socket. 1 During the unit is on, push the emergency switch on the rear •...

  • Page 9: Identifying The Parts (Main Unit)

    Identifying the Parts (Main Unit) Speakers (Stereo) MP3 MODE During playback of MP3 disc or USB / SD memory card, use this button to display the current ID3 Tag STANDBY / ON ( ) Use this button to turn the unit on or put it in standby. MEMORY / CLOCK ADJ In tuner mode, use this button to store preset channels into VOLUME...

  • Page 10: Identifying The Parts (Remote Control Unit)

    Identifying the Parts Identifying the Parts (Main Unit) (Remote Control Unit) SHUFFLE ( ) / RDS / INFO In CD, USB / SD or iPod mode, use this button to start shuffle playback. In FM mode, use this button to select an RDS mode. In DAB mode, use this button to choose the type of information displayed.

  • Page 11: Setting The Clock

    Turn the MULTI JOG to set the current minute, and then press the CLOCK ADJ button. Compatible iPod / iPhone Software If your iPod / iPhone will not work with the SR-3DAB or with the remote control unit, a software update might solve the problem.

  • Page 12: Basic Operation

    • The unit turns on with the source that was last selected. • If an iPod / iPhone that is in playback mode is inserted into the Dock, the SR-3DAB will automatically turn on and start Use the DIMMER button to set the brightness to one of four iPod / iPhone playback.

  • Page 13: Listening To Cd/Mp3

    Printed label face Press the Play/Pause button (y/J) to start playback. When you insert disc in each function, the SR-3DAB will switch the function to "CD" and starts playback automatically. • Do not push the disc forcibly. • Do not insert more than one disc.

  • Page 14: Listening To Mp3(Usb/Sd)

    Listening to MP3(USB/SD) When a USB/SD memory card is loaded • Do not use a high-capacity USB (SDHC) hard disc with this unit. Press the FUNCTION button to select "USB" or "SD". total number of total files folders Press the Play/Pause button (y/J) to start playback.
  • Page 15 To display MP3 information To suspend playback temporarily (pause mode) During playback of an MP3 disc/USB/SD memory card, press the MP3 button. The information about the current track is Press the Play/Pause button (G /J ) during playback. displayed as follows: Playback stops at the current position.

  • Page 16: Programmed Playback

    Programmed Playback Press the Skip button (.or/) repeatedly to select a track or turn the MULTI JOG knob to select a file of MP3 disc or USB / SD memory card, then press the MEMORY button. Up to 32 tracks can be programmed in the desired order. Press the FUNCTION button to select “CD”.
  • Page 17 To check the programmed order To overwrite the program In the stop mode, press the MEMORY button repeatedly until the program number to be changed appears on the display. Select a new track number using the Skip button (.or/) or turn the MULTI JOG knob and then press the MEMORY button.

  • Page 18: Repeat Playback

    Repeat Playback Shuffle Playback Repeat Shuffle buttom Every time the REPEAT button is pressed, the mode is changed as follows: The tracks can be played randomly. Press the SHUFFLE button When a CD is loaded: during playback or when in the stop mode. “SHUFFLE” will then light up in the display.

  • Page 19: Ipod/Iphone

    • Make sure to use a suitable Dock Adapter (page 11). • The battery of an iPod / iPhone will be recharged until it is full whenever the iPod / iPhone is docked and the SR-3DAB is connected to AC power.
  • Page 20 Listening to an iPod or iPhone (2) Search for a part of a track Returning to the previous menu Hold down more than 2sec. Press the MENU button. This button has the same functions as its iPod/iPhone counterpart. During playback, hold down a Search but ton (. or /) for more than 2 seconds to search a song.
  • Page 21 Activating the repeat mode Activating the shuffle mode During playback, press the SHUFFLE button to change the During playback, press the REPEAT button to change the shuffle mode. repeat mode. Each time the SHUFFLE button is pressed, the iPod SHUFFLE Each time the REPEAT button is pressed, the iPod REPEAT setting changes as follows: setting changes as follows:...

  • Page 22: Listening To The Dab

    Listening to the DAB When the unit is switched to DAB mode for the first time, the When you find the channel, press the SELECT button. automatic tuning process will start and create a channel list. (Autoscan local: 10A to 13F) •...

  • Page 23: Setting The Dab Display

    The CT data is supplied by the DAB station and should always be accurate. When you set the DAB CT mode to on, the clock setting of the SR-3DAB will be adjusted automatically according to this data. Therefore, if you tune in a DAB station...

  • Page 24: Signal Strength Display

    Signal strength display Channel and frequency This displays the channel and frequency of the currently playing You can check the signal strength of the current station. broadcast. Bitrate In DAB mode, press the SELECT button. The bitrate and sound mode of the broadcast currently being received is displayed.

  • Page 25: Using The Dab Menu

    Using the DAB Menu (1) Station order You can select the order in which stations are listed. There are four orders: Favourite, Alphanumeric, Active and Prune. In DAB menu mode, select “Station order” In DAB mode, use the DAB menu to access various Press the SELECT button.

  • Page 26: Manual Tune

    Using the DAB Menu (2) Manual tune Local scan (Auto scan) This option allows you to manually tune in a channel and The unit will scan the DAB bands between 10A to 13F and add view a continuously updated display of the strength of the the channels found to the channel list.
  • Page 27 DRC value Turn the MULTI JOG to select the desired level of DRC and then press the SELECT button. Use this option to set the Dynamic Range Control (DRC) value to be applied to received broadcasts. DRC is used to reduce the range between high and low volumes of audio and is sometimes applied at the broadcast source.

  • Page 28: Preset Tuning (Dab)

    Preset Tuning (DAB) How to select a preset station You can programme 30 DAB channel presets. Select a DAB station you want to store (page 22). Select a preset channel to store the station using the PRESET buttons ( In DAB mode, press the PRESET buttons ( ) repeatedly until the desired preset station is found.

  • Page 29: Listening To The Fm Radio

    Listening to the FM Radio FM MODE button Press the FUNCTION button to select “FM”. Pressing this button alternates between Stereo mode and Mono mode. • If you select "DAB", press the BAND button to change to "FM". Stereo FM stereo broadcasts are received in stereo and "ST" indicator Select the station you want to listen to.

  • Page 30: Preset Tuning (Fm)

    Preset Tuning (FM) Saving presets automatically You can programme 30 FM channel presets. Saving presets manually Tune in a station you want to store (page 29). Select a preset for storing the station using the Hold down more than 2sec. PRESET buttons ( Press and hold the AUTO SCAN button for more than 2 seconds.

  • Page 31: Rds (Radio Data System)

    RDS (Radio Data System) The Radio Data System (RDS) is a broadcasting service that allows RT (Radio Text) stations to send additional information along with the regular When you select RT, the news of stations composed of up to radio programme signal. 64 symbols will be displayed.

  • Page 32: Listening To An External Source

    SR-3DAB. • Turning the volume of the connected device up too high might cause the sound from your SR-3DAB to be distorted. In this case, reduce the volume of the device until the distortion stops and then adjust the volume level of the SR-3DAB to a comfortable listening level.

  • Page 33: Sleep

    Sleep Timer (1) Sleep timer Wake up timer You can set the sleep timer so that the unit turns itself off after a You can set the unit to turn on and off at specific times. You can specified amount of time. set two separate timers with ALARM 1 and ALARM 2.
  • Page 34 Timer (2) Turn the MULTI JOG to set the minute, and then Turn the MULTI JOG to set the volume, and then press the ALARM 1 button. press the ALARM 1 button. The time when the timer will turn on has been set. The volume for timer operation can be adjusted from 10 to “OFF TIME”...

  • Page 35: Using The Snooze Function

    • If the wake up timer reaches the off time while the and the OFF TIME is shown snooze function is activated, the snooze function will be automatically cancelled and the SR-3DAB will remain in Wake up timer is turned off. standby mode.

  • Page 36: Troubleshooting

    Troubleshooting DAB tuner If you have problems with your system, read this page and try to solve the problem yourself before calling your dealer or a TEAC No sound. service Center. Ensure that the unit has been able to locate a DAB station.

  • Page 37: Specifications

    Specifications TUNER Standard Accessories F M Frequency Range....87.5 MHz to 108 MHz Remote Control Unit (RC-1236)× 1 Battery (CR2025) for Remote Control Unit × 1 DAB Frequency Range.
  • Page 38 7733 Telegraph Road, Montebello, California 90640 Phone: (323) 726-0303 TEAC CANADA LTD. 5939 Wallace Street, Mississauga, Ontario L4Z 1Z8, Canada Phone: (905) 890-8008 TEAC MEXICO, S.A. De C.V Río Churubusco 364, Colonia Del Carmen, Delegación Coyoacán, CP 04100, México DF, México Phone:(5255)5010-6000 TEAC UK LIMITED Unit 19 &...
