A Dorel Company
MERIWOOD
INDUSTRIES
THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
Please Recycle
Recicle Por Favor
TM
29986 13091
4
0
Spanish translations are located in the center of this manual.
Se localizan las traducciones españolas en el centro de este
manual.
1309026WP
DO NOT RETURN PRODUCT TO THE STORE
STOP
Individual stores do not stock parts.
Date of Purchase
___ / ___ / ___
If a part is missing or damaged, visit our website or call our toll-free
customer service line. We will gladly ship your replacement parts
FREE of charge.
Need Parts or Assistance?
WWW.AMERIWOOD.COM/PARTS
or call toll free:
1-800-489-3351
For prompt, reliable service please have your assembly manual ready.
Recommended # of people needed for assembly: 1
(however it is always better to have an extra hand.)
Estimated assembly time is 1 hour1.
B341309026WP 02

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1309026WP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ameriwood 1309026WP

  • Page 1 A Dorel Company MERIWOOD 1309026WP INDUSTRIES 29986 13091 DO NOT RETURN PRODUCT TO THE STORE STOP Individual stores do not stock parts. Date of Purchase ___ / ___ / ___ If a part is missing or damaged, visit our website or call our toll-free customer service line.
  • Page 3 Parts - Piezas 2 side rails top rail 31309026090 31309026070 fixed shelf cima 31309026050 31309026030 left panel right panel bottom 3 adjustable shelves 2 bottom rails door 31309026010 31309026020 31309026040 31309026060 31309026080 31309026100 This piece is paperboard comstruction. It is not made from wood, but is required for the assembly of your unit.
  • Page 4 Parts - Piezas cam cover tack glide wood dowel stop pin shelf support #A243056 #A43200 #A21700 #A89020 #A80250 Qty: 4 Qty: 4 Qty: 4 Qty: 1 Qty: 12 knob hinge 7/8" bolt wire management clip 5/8" screw #A65640 #A52370 #A81000 #A17400 #A11170 Qty: 1...
  • Page 5 This illustration shows how the CAM fastening system works. Esta ilustración muestra el sistema de fijación de leva y como funciona. A22510 (x13) A22510 (x13) A22500 (x13) A22500 (x13) cam bolt cam bolt cam lock cam lock Tighten to fully seat. Do not over tighten.
  • Page 6 Proper orientation of CAM LOCK Posición correcta de la cerradura de leva. B341309026WP0 2 6 /19...
  • Page 7 18 b 18 a 7/16" Approx. 18 a 18 b Proper orientation of CAM LOCK Posición correcta de la cerradura de leva. B341309026WP0 2 7 /19...
  • Page 8 LOCK UNLOCK APRETAR DESAPRETAR Finished Edge Borde Acabado Finished Edge Borde Acabado B341309026WP0 2 8 /19...
  • Page 9 LOCK UNLOCK APRETAR DESAPRETAR Safety bracket (18a) along the back edge of the top (C). If the back edge of the bottom (D) is not flush with the back edge of panels (A&B), remove bottom (D) and rotate 180 degrees and re-attach. B341309026WP0 2 9 /19...
  • Page 10 WARNING Please make sure that the Back Panel is attached securely. All nails must be driven into the parts straight, centered and tightened firmly. Failure to do so could cause instability, product collapse, and/or serious injury. ADVERTENCIA Por favor asegúrese que el Panel Trasero se atan firmemente.
  • Page 11 Proper orientation of CAM LOCK Posición correcta de la cerradura de leva. Finished Edge Borde Acabado Finished Edge Borde Acabado Screw cam bolts (2) straight into holes. Atornille los pernos de la leva (2) derecho en los agujeros en los pies (K&L). x 10 x 16 x 10...
  • Page 12 LOCK UNLOCK APRETAR DESAPRETAR Assemble parts as shown. Monte las piezas como se muestra. Assembled component. Componente ensamblado. B341309026WP0 2 12 /19...
  • Page 13 Using ten screws (16), attach the component from step 7 to the bottom (D) as shown. After attaching, nail a tack glide (7) into the center of the feet (K&L) as shown. x 10 B341309026WP0 2 13 /19...
  • Page 14 Loosen screw to seperate hinge plate from hinge. Afloje el tornillo para separar la placa de la bisagra de la bisagra. B341309026WP0 2 14 /19...
  • Page 15 Insert the shelf support (5) into the holes as shown and set the adjustable shelves (F) in place. Determine which side you want your door to hinge from and attach hinge plate (14) as shown. On the opposite side of your cabinet, attach the door stop (9) with screw (10) as shown onto shelf (E).
  • Page 16 Slide the hinge onto the hinge plate as shown and tighten screw "C" as shown. B341309026WP0 2 16 /19...
  • Page 17: Ajuste De La Puerta

    Loosen screw A Loosen screw C Loosen screw C Adjust door. Turn screw B to Adjust door. Tighten screw A move door. Tighten screw C Tighten screw C *side view Suelte el tornillo A Acomode la puerta. Suelte el tornillo C Suelte el tornillo C Ajuste el tornillo A Dé...
  • Page 18 hole agujero stud montante 18 d wallboard muro 18 c 18 c Note: The top (C) is removed in order to see the safety bracket attachment. DO NOT remove the top (C). Nota: La parte superior (C) se remueve para ver el accesorio del soporte de seguridad. No remueva la parte superior (C).
  • Page 19 Visit our website for any assistance you should need or call our toll free Weight Limits: number: Capacidad de Carga: WWW.AMERIWOOD.COM 1-800-489-3351 Clean the product with your favorite furniture polish and a soft cloth. DO NOT USE harsh chemicals or abrasive cleaners.
  • Page 20 Certificate of Conformity 1. This certificate applies to the Ameriwood Industries Inc. product identified by this instruction manual. 2. This certificate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303). 3. This product is distributed by: Ameriwood Industries Inc.
