3.5.3b Displaying Multiple Text Windows
The procedures for displaying one or more process parameters in a single Text Display window may be repeated to
open multiple Text Display windows. To do so, proceed as follows:
1. To open another Text Display window and display the desired process parameter(s) in the new window, repeat the
steps in PanaView Display.
2. Arrange the multiple Text Display windows as desired via the Window menu (see the PanaView User's Manual).

3.5.4 Pausing Measurement

On occasion, it might become necessary for the XGM868i to stop taking measurements. Through PanaView, you can
direct the XGM868i to pause measurements without cutting off power from the meter.
1. From the meter tree in the New Meter Browser, click on the XGM868i entry.
2. Expand the Edit Functions option, and double-click on the Pause Measurement entry. A window opens similar to
Figure 21.
3. To pause current measurements, double-click on the Stop measurement option. The window closes, and the
XGM868i stops taking measurements.
4. To restart measurement, double-click on the Pause Measurement entry, and then on the Measure flow option. The
XGM868i resumes flow measurement.
DigitalFlow™ XGM868i Startup Guide
Figure 21: The Pause Measurement Window
Chapter 3. Operation
53
