- Page 1 User Manual LSUM 048R6C 0166F EA DC...
-
Page 2: Table Of Contents
User Manual CONTENT 1. Overview …………………………………… 04 2. Unpacking …………………………………. 3. Safety ………………………………………. 4. Identification of features ………………... 06 5. Module to module connection …………. 6. Output terminal connection …………….. 08 7. Output connector ……………………….. 8. Mounting …………………………………..12 9. Maintenance …….……………………….. 10. -
Page 3: Overview
LSUM 048R6C 0166F EA DC 1. Overview The LS 48.6V / 166F Ultracapacitor Module has high energy and low ESR to meet energy storage and power delivery requirements. The cells used in the module have 2.7 V maximum voltage rating and are connected in series to get higher operating voltage of modules. -
Page 4: Unpacking
User Manual LSUM 048R6C 0166F EA DC 2. Unpacking Inspect the shipping carton for signs of damage prior to unpacking the module. Damage to the shipping carton or module should be reported to the carrier immediately. Remove the module from the shipping carton and retain the shipping materials until the unit has been inspected and is determined to be operational. -
Page 5: Identification Of Features
User Manual LSUM 048R6C 0166F EA DC 4. Identification of features - Product Image <Fig. 1> Product Image 5/18... -
Page 6: Module To Module Connection
User Manual LSUM 048R6C 0166F EA DC 5. Module to module connection - There are series and parallel connection for High power <Fig. 2> Series Connection of Modules <Fig. 3> Parallel Connection of Modules. 6/18... -
Page 7: Output Terminal Connection
LSUM 048R6C 0166F EA DC 6. Output terminal connection The LS 48.6V / 166F Ultracapacitor Modules are designed to connect directly to a ring or a bus bar. The positive and negative terminals have each hole for the screw. The positive terminal threaded size is M8 and negative terminal is M10. Wave washers are required to ensure long term, reliable connections. -
Page 8: Output Connector
User Manual LSUM 048R6C 0166F EA DC 7. Output connector - The output of connector is tabulated below. DC01/DC04 DC02/DC03/DC05/DC06/DC07 Pin # Wire color Max. Pin out Signal Pin out Signal current TEMP Pin1 or Pin2 Over High-inactive White Not used... - Page 9 User Manual LSUM 048R6C 0166F EA DC XPXT -Pin 1, 4 is connected with a NTC thermistor for temperature monitoring. According to temperature variation in the module, the resistance of the thermistor is determined. The resistance measured through the thermistor relates to temperature according to the DK Sensor 10K@ 25℃...
- Page 10 User Manual LSUM 048R6C 0166F EA DC APOT265 / APOT230 / APOT250 - Pin 1 is connected with monitoring connector output signals receiver circuit’s ground. The output signals are isolated from the capacitor voltage and from chassis ground. -When a cell in the module goes into over voltage condition, pin 2 has alarm signal. When every cell voltage is not over voltage state, the output of Pin 2 is high.
-
Page 11: Mounting
User Manual LSUM 048R6C 0166F EA DC 8. Mounting The modules should not be mounted in locations where they are directly exposed to the environment. - <Fig. 6> shows the mounting positions of the module. <Fig. 6> Mounting Positions 11/18... -
Page 12: Maintenance
User Manual LSUM 048R6C 0166F EA DC 9. Maintenance Power Rating The rated voltage of the module is max 48.6V. If the applied voltage is over 48.6V, charging the module should be stopped. And the allowable low voltage level of the module depends on the user’s requirements, but full discharging to 0V does not... -
Page 13: Contact Information
User Manual LSUM 048R6C 0166F EA DC 10. Contact Information LS Ultracapacitor LS Mtron 6F, LS Mtron Hi-Tech Center, 39, LS-Ro, 116beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 431-831, Korea Tel. +82-31-8045-9579 Fax. +82-31-8045-9544 E-mail. ultracapacitor@lsmtron.com 13/18... -
Page 14: Appendix I
User Manual LSUM 048R6C 0166F EA DC Appendix I 14/18... - Page 15 User Manual LSUM 048R6C 0166F EA DC 15/18...
- Page 16 User Manual LSUM 048R6C 0166F EA DC 16/18...
-
Page 17: Appendix I I
User Manual LSUM 048R6C 0166F EA DC Appendix II Drawing 17/18...
