Epec 2024 Technical Document page 29

Conducted radio-frequency common mode
immunity test
Radiated radio-frequency electromagnetic
field immunity test
Electrical fast transient (EFT/B) immunity
test
CFR 47 Part 15, Subpart B, Class A and B
Code of federal requlations (cfr) title 47 telecommunication, part15 radio frequency devices,
subpart b unintentional radiators
Class a intended for use in industrial/commercial environments
Class b intended for use in residential/small office environments
Radiated emissions
Note: The Color display (2040) needs extra
facilities in order to have the class B
covered.
Epec Oy reserves all rights for improvements without prior notice
Epec Oy
Tiedekatu 6
FIN-60320 Seinäjoki
Epec CAN Module Family
2024 CONTROL MODULE
Postiosoite/Postal address
PL/P.O.Box 194
FIN-60101 Seinäjoki, Finland
2024G08,G18 / MAN000185
• Test method EN 61000-4-6 (1996)
• Performance criterion A
Specification
Frequency range
0,150-80 MHz
Modulation
AM80% 1 kHz
Sweep step 1%,
time/step 3s
• Test method EN 61000-4-3
• Performance criterion A
Specification
Frequency range
80-2700 MHz
Modulation
AM80% 1 kHz
Sweep step 1%,
time/step 3s
• Test method EN 61000-4-4 (1995)
• Performance criterion B
Test pulse
5(Tr)/50(Th) ns,
repetition
frequency
5 kHz, duration
1 minute
• Test method ANSI C63.4 and EN55022
Frequency
Class
(MHz)
A 30 – 1000
B 30 – 1000
Puhelin/Phone Fax
+358-(0)20-7608 111 +358-(0)20-7608 110
29 / 34
07.10.2010
Port Test level
DC input
10 Vemf
port
Signal
10 Vemf
ports
Range Test
(MHz) level
80-1000 20 V/m
1000-2700 3 V/m
Port Test level
DC input
± 2,0 kVp
port
Signal
± 2,0 kVp
ports
Limit value
(dBμV)
40/47 (QP)
30/37 (QP)
