Radiated disturbance emission test
Conducted disturbances emission test
Immunity to transient disturbances
conducted along supply lines test
Note: The Mini module (2038) and the Mini
display (2029) need the Hub module (2021)
in order to have the full transient immunity.
Epec Oy reserves all rights for improvements without prior notice
Epec Oy
Tiedekatu 6
FIN-60320 Seinäjoki
Epec CAN Module Family
2024 CONTROL MODULE
Postiosoite/Postal address
PL/P.O.Box 194
FIN-60101 Seinäjoki, Finland
2024G08,G18 / MAN000185
• Test method 2005/83/EC, ANNEXES VII and
VIII
Frequency
(MHz)
30 – 1000
30 – 1000
• Test method 2005/83/EC, ANNEX X
Port
24 V DC input
• Test method 2005/83/EC, ANNEX X
• Performance criterion:
Pulse
1
2a
2b
3a
3b
4
Pulse Pulse parameters
1 3/2000 μs, -600 V, 1000 pulses
1/50 μs, +100 V, 1000 pulses
2a
2b 20 V, 220 ms, 2 pulses
3a 5/100 ns, -200V, 60minutes
3b 5/100 ns, +150 V, 60minutes
4 100 ms -20,5(8,0) V, 20s -
16,5(12,0) V, 2 pulses
