2.8.2 BACKUP BATTERY CONNECTION
If it is decided to equip the unit with a 6V gel cell type emergency backup battery, connect it to the
two-position BAT screw terminal connection. See the Specification section 1.4 for a recommended
battery type. OBSERVE THE POLARITY!

3 - OPERATION

3.1 Turn on Procedure

Supply primary power to the unit.

3.2 Indicator Light Interpretation

Table 9 – Indicator Light Interpretation
Indicator INDCTR
Color
ID Switch
POWER AMBER N/A
TD GREEN DN
RD GREEN DN
RTS GREEN DN
CTS GREEN DN
TDE GREEN DN
RDE GREEN DN
TX1 GREEN UP
RX1 GREEN UP
TX2 GREEN UP
RX2 GREEN UP
RX1
GREEN UP
Priority
RX2
GREEN UP
Priority
FAULT RED N/A
HI CHG AMBER N/A
BERT GREEN N/A
Function
This indicator is steadily ON in the presence of primary DC or AC
power. If your unit has an optional battery, this indicator will blink
while being powered by the battery (discharge mode).
Indicates data input to the DATA I/O Port.
Indicates data output from the DATA I/O Port.
Indicates a true RTS input to Pin 4 of the RS232 connector when
on.
Indicates a true CTS output from Pin 5 of the RS232 connector,
when on.
Indicates data input to Pin 2 of the Expansion Port.
Indicates data output from Pin 3 of the Expansion Port
Indicates data being transmitted via the TX1 optical port.
Indicates data being received by the RX1 optical port
Indicates data being transmitted via the TX2 optical port.
Indicate data being received by the RX2 optical port.
When on, indicates that the RX1 optical input port is currently
selected by the Priority Select circuitry.
When on, indicates that the RX2 optical input port is currently
selected by the Priority Select circuitry.
Indicates an electrical anti-streaming timeout, except when the
unit is in Master Fault Tolerant mode. In MFT mode, it indicates a
break in one of the rings.
When this light is on, the battery charger is operating at or near
its 150 mA max. current. This will occur when a battery is being
freshly charged after a power outage when the battery is nearly
totally discharged.
Indicates that it is properly receiving a "BERT" signal transmitted
by another unit (usually the master).
