DS201
User's Manual
Dear users,
Thank you for choosing FLY DS201
Please read this manual carefully before using the phone.
The Manufacturer reserves the ultimate right for the interpretation
of this manual.
The Manufacturer reserves the right for the changes in the
technical specification without advanced notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS201 and is the answer not in the manual?

Questions and answers

Related Manuals for FLY DS201

Summary of Contents for FLY DS201

  • Page 1 DS201 User’s Manual Dear users, Thank you for choosing FLY DS201 Please read this manual carefully before using the phone. The Manufacturer reserves the ultimate right for the interpretation of this manual. The Manufacturer reserves the right for the changes in the...

  • Page 2: Table Of Contents

    Table of Contents ………………………………………….1 TABLE OF CONTENTS 1 SPECIFICATION………………………………… 1.1 S ………………………………………………………. PECIFICATION 2 PHONE APPEARANCE AND KEYS…………… 2.1 K ………………………………………………… EYS SPECIFICATION 2.2 I ………………………………………………….……………… CONS 3 KEY FUNCTION………………………………….. 4 USER GUIDE……………………………………... 4.1 I …………………………………………. NSTALLING THE BATTERY 4.2 C ………………………………..…………...
  • Page 3 6.2 R ……………………………………….………….. ECEIVED CALLS ……………………………………..…….. ISSED CALLS 6.4 R …………………………………………………… EJECTED CALLS 6.5 D ……………………………………………..………… ELETED ALL ……………………………………………………….. CALL TIMERS ……………………………………………….…………. CALL COST 6.8 GPRS …………………………………….……………. COUNTER 7 PHONEBOOK…………………………..………. 8 FILE MANAGER………………………..………. 9 MULTIMEDIA………………………….……….. 9.1 C ………………………………………………..………….. AMERA 9.2 V …………………………………….…………...
  • Page 4 11.3 C ……………………………………………………….. ALENDAR 11.4 C ……………………………………………..………. ALCULATOR 11.5 T ………………………………………….…………. ORCH IGHT 1 2 F L Y B U Z Z … … … … … … … … . … … … . 12.1 S …………………………………………………………. OKOBAN 12.2 E ………..

  • Page 5: Table Of Contents

    Specification Specification Band: GSM 900/1800 Dual SIM cards, dual standby, single pass Phone Type: Bar phone Screen Size: 2.0 inches Battery Capacity: 1150 mAh Stand-by time: 300-400 hrs. (Network Dependent) Phonebook Storage: 100 Phone SMS storage: 50 Phone Appearance and Keys Keys specification Specification Keys...
  • Page 6 number from phonebook or call records. In idle mode, press the key to display the corresponding call logs. Press left and right navigation keys to show details. End key End the call. Long press to power on/off the mobile. Return to idle menu FM Key Start FM radio Navigation keys...

  • Page 7: Icons

    * key When dial a number, press to enter “*”. In idle mode, long press * key, cyclically shows “＋”, ”P”, ”W”. In input mode, enter punctuation. In idle mode, press left soft key then press * key to lock/unlock keypad. # key In idle mode, long press can switch to silent mode.

  • Page 8: Key Function

    The keypad is locked. The keypad is unlocked. Earphone The phone is inserted earphone. Alarm Set the alarm time and activate the function. Incoming call alert type: That is “Ring”. That is “Silent”. That is “Vib. only”. That is “indoor” That is “outdoor”.

  • Page 9: User Guide

    In idle mode, press ok OK Key Press briefly to menu ※ Note: (a) When the mobile have one valid SIM card, the SIM1/2 corresponding menu will not show. (b) Part of secondary menu and its submenu are not listed on the above.

  • Page 10: Inserting The Sim Card

    iii) Charging with phone off, the display says ‘Charging’ with charging indicator icon flash.* Inserting the SIM card The mobile support two SIM cards on-line at one time. The method of the two SIM cards of inserting or removing is same. ...

  • Page 11: Power On Or Off

    4.4.2 T-Flash card use The music and video file are saved in the T-Flash card. If you need operate with the files, the files must be saved in the card firstly. Power On or Off Make sure the battery is already inserted: Power On: Hold down end key until the phone-on image display.

  • Page 12: Answering A Call

    enroll to the system.  Quick making a call Enter [Menu]- [Phonebook], select Browse and find the required number; Enter [Menu]-[Call]-[Call history], select corresponding SIM card, select Missed calls, Dialed calls, Received calls list. Scroll the navigation keys to find the required number;...

  • Page 13: Call Waiting

    ※ Note：The speaker sound volume maybe loud, so please not use the speaker beside ear.※ Call Waiting You can answer an incoming call while you have a call in progress, if this service is supported by the network and you have set the Call Waiting menu option to activate.

  • Page 14: Call Log

    5.5.2 Making a Multiparty Call A multiparty call is a network service that allows up to six people (require network support) to take part simultaneously in a multiparty or conference call. For more information, contact your service provider. ※Note: Multiparty Call requires network support. ※ Call log In this menu, you can view the calls you missed, dialed and received, as well as the length of your calls.

  • Page 15: Call Timers

    call timers Display information details of SIM1/SIM2: Last call, Received calls, Dialed calls, and All calls. Press left soft key to "Reset". call cost You can view “total cost, max cost, price per unit. Reset cost GPRS counter Select SIM1 or SIM2 first, and press OK key to display information of Last sent, Last receive, Total sent, and Total receive.

  • Page 16: File Manager

    File manager For saving more information, the phone support memory card. The card can be installed at any time. Multimedia Camera With the phone camera feature, you can take picture at any time without carrying digital camera. Enter the menu, the display shows the preview image.

  • Page 17: Ideo Player

    Video player The menu supports play video file. When the file list is null, select the storage path first, and then select the video folder. There will update the video file list, select one file from the list, press left soft key to play. Press end key to exit and return list. Recorder You can record sound through the menu.

  • Page 18: 0 Messages

    Messages 10.1 Write message 10.1.1 Write SMS SMS is short message, this menu allows you to read, compose, send and receive text messages. Each message has limitation in length that is 162 English characters. If exceed the limitation, the message will be cut to many messages for sending. Screen icon that displays in standby mode refers to any new message just received and unviewed.

  • Page 19: Drafts

    10.4 Drafts Save edited SMS haven’t sent. 10.5 Sent box Store all the SMS successfully sent out. If you want the sent messages be saved automatically, please select [Message Options], then select [SMS settings→Save sent messages→Save]. Organizer 11.1 Alarm The phone can setup 3 alarm clocks (still effective while the phone is switch off), the default settings is off.

  • Page 20: Calendar

    ――Choose level: You can choose the level of the game. ― ― Help: you can view the operating instruction 12.2 Enjoy yahoo, facebook and twitter by your DS201 Pls note : GSM/GPRS charges are applicable 12.3 Smart Auto call record...

  • Page 21: Greeting

    memory card by default This feature will be activated initially, you can turn it off as per your desire 12.4 Greeting Change your greeting text content or turn it on/off from this setting Services Wireless Application Protocol, a kind of browse Internet webpage mode.

  • Page 22: Call Settings

    14.2 Call settings a. Dual SIM: Select SIM switch mode or Set the SIM card mode b. Network Selection : Auto and manual selection of preferred networks c. Call Divert: Different settings for call divert and Forwarding d. Call barred: Different settings for barring outgoing, incoming calls etc Call Waiting : activate or de activate Hide ID : Hide or show your ID...

  • Page 23: Display Settings

     Restore factory settings: enter the security code, the phone will restart and the menu setting will reset to their original values, the initial value is 0000. 14.4 Display settings You can set the following parameters:  Wallpaper settings: you can change the background of phone wallpaper.

  • Page 24: Connection Management

    Auto Keypad Lock: select On or Off Lock screen by end Key: Select On or Off Power on password: select and enter power on password here, it will be applicable whenever your phone will be switched 14.6 Connection management Enter into the menu; you can select re-search, network and mode method to get the network service.
  • Page 25  When failing to connect to network, the phone will keep searching base station that consumes much battery and Standby time reduces standby time. Move to an area too short with stronger signal strength or switch your phone off temporarily. ...

  • Page 26: 6 Limitations Of Warranty Coverage

    changed.  The operation is wrong.  The network providers do not support some functions the function, or you don’t apply the function. Limitations of Warranty Coverage The following conditions are not covered under limited Warranty: Warning: Please do not touch the speakers as it may get damaged. If damaged, it’s not covered Under Warranty.
  • Page 27 & no proof of purchase is provided. Product has been serviced or repaired by any other agent other than FLY Mobiles Pvt. Ltd Authorized Service Partner. Service Centre No.: For any query regarding your handset: Contact no: 1860 266 0106 Email id: flycare@flyphone.in...
