Barnett Engineering ProTalk LINK Operating Manual

Modular alarm reporting system
Hide thumbs
Table of Contents

Advertisement

Quick Links

June 2016
Rev. 3.02
#215, 7710 – 5
th
Street SE
Calgary, Alberta, Canada
T2H 2L9
Operating Manual
Hardware
Phone: (403) 255-9544
Fax: (403) 259-2343
www.barnett-engg.com
E-mail: sales@barnett-engg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProTalk LINK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Barnett Engineering ProTalk LINK

Summary of Contents for Barnett Engineering ProTalk LINK

  • Page 1 Operating Manual Hardware June 2016 Rev. 3.02 #215, 7710 – 5 Street SE Phone: (403) 255-9544 Calgary, Alberta, Canada Fax: (403) 259-2343 T2H 2L9 www.barnett-engg.com E-mail: sales@barnett-engg.com...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS ................3 1. INTRODUCTION .................. 1 2. INSTALLATION OVERVIEW............. 2 3. M1 INSTALLATION ................6 4. A1 INSTALLATION ................10 5. D1 INSTALLATION ................13 6. P1 INSTALLATION ................16 7. P2 INSTALLATION ................21 8. T1 INSTALLATION ................24 9.

  • Page 5: Introduction

    The ProTalk Link modules plug together to build up the system you want. Every system has one Main module and one or more expander modules. Throughout the manual, the modules are referred to in short form in this way: the B1285-M1 is an M1 module, the B1285-W1 is a W1 and so on.

  • Page 6: Installation Overview

    I/O functionality. The first expander module is plugged into the Main module, then the next expander into the first expander and so on. The ProTalk Link System accepts a maximum of 16 modules (B1285-M1 module + a maximum of 15 expander modules).

  • Page 7: Table Of Contents

    INSTALLATION OVERVIEW PAGE 3 EXPANDER MODULE MAIN MODULE Step 1: Position the expander module over the main module so the connectors line up then slide the parts together. EXPANDER MODULE MAIN MODULE Step 2: Fasten the two modules together with bolts through the joiner plates on each side.
  • Page 8 PAGE 4 INSTALLATION OVERVIEW TOP VIEW FRONT VIEW Figure 3 Module Dimensions Figure 3 shows the dimensions for both Main and expander modules. The Main module does not have the connector on the bottom nor an address switch; it is always address 0.
  • Page 9 INSTALLATION OVERVIEW PAGE 5 ProTalk   ProTalk   ProTalk    ProTalk  Figure 4 ProTalk LINK in a NEMA enclosure Figure 4 shows the ProTalk LINK, with three expanders, when it is mounted in a NEMA enclosure.

  • Page 10: M1 Installation

    PAGE 6 M1 INSTALLATION 3. M1 INSTALLATION STATUS ALARM OUTPUT GROUP OUTPUT 1 OUTPUT 2 PROGRAM B1285-M1 Figure 5 M1 Module Front Panel The M1 module controls all of the alarm reporting operations. An exception exists following a system failure when the communication modules change to autonomous mode and perform a basic callout (to announce the system failure).
  • Page 11 M1 INSTALLATION PAGE 7 Figure 6 ACK and PFAIL Input Circuit Power Fail Input If a power failure status is available from the external power supply, it can be connected between the PFAIL input and ground and then used to generate an alarm. The power fail signal must be a relay contact or open collector;...
  • Page 12 PAGE 8 M1 INSTALLATION The USB port performs the same function as the DB9 port. When a cable is plugged into this port, the DB9 port is not operational. The TEL port accepts a safety approved Touch-Tone telephone and is used to record the voice messages, interrogate points, acknowledge alarms and enter control codes.
  • Page 13 M1 INSTALLATION PAGE 9 RX/TX  Green when a message is sent to an expander on the internal communications bus.  Red if the message has to be resent due to a communications error  Green/Red flash during PC communications Tone ...

  • Page 14: A1 Installation

    PAGE 10 A1 INSTALLATION 4. A1 INSTALLATION STATUS ALARM CURRENT INPUT VOLTAGE INPUT B1285-A1 Figure 9 A1 Module Front Panel This module provides a total of 16 analog inputs; 8 using 4-20 mA current loop signals and 8 using single ended voltage inputs. The voltage inputs can be configured for +5, +10 or +30 VDC full scale.
  • Page 15 A1 INSTALLATION PAGE 11 Figure 11 A1 Current Input Circuit Voltage Inputs Voltage inputs are configured by the programming application to match the full scale range of the analog input voltage; +5, +10 or +30 VDC. If a voltage greater than the programmed maximum is applied, the result will be a full scale reading and an over voltage error can be generated.
  • Page 16 PAGE 12 A1 INSTALLATION  Normal operations  Green on receipt of valid message from the main module  Yellow if the message from the main module has a checksum error. This indicator times out after 400 msec Over  Flashing Red when a voltage input is over range ...

  • Page 17: D1 Installation

    D1 INSTALLATION PAGE 13 5. D1 INSTALLATION STATUS ALARM INPUT CLEAR B1285-D1 Figure 13 D1 Module Front Panel The D1 module provides a total of 16 digital inputs that can be independently programmed to operate as one of five different types: ...
  • Page 18 PAGE 14 D1 INSTALLATION Connections Connection points for the inputs are shown in Figure 14. Figure 14 D1 Front Panel - Connections The circuit for the inputs is shown in Figure 15. Figure 15 D1 Input Circuit Indicators The indicators are grouped into 2 sections: 1) Status ...
  • Page 19 D1 INSTALLATION PAGE 15  Green when any clear input is active  Off when all clear inputs are idle 2) Alarm Sixteen, one for each input  Flashing Red when the associated input is in the alarm state  Yellow when there is an error with an input connection ...

  • Page 20: P1 Installation

    PAGE 16 P1 INSTALLATION 6. P1 INSTALLATION STATUS COMM ALARM BLOCK 11 12 ETHERNET RS232 RS485 LINK B1285-P1 Figure 16 P1 Module - Front Panel The P1 module provides connectivity between the Link system and a PLC. Communications between the P1 module and the PLC can be done using one of the available ports: the RS232 serial port, the RS485 serial port or, for Modbus systems, the Ethernet port.
  • Page 21 P1 INSTALLATION PAGE 17 RS485 The RS485 port performs the same function as the RS232 port. Either this port or the RS232 port is selected in the configuration; both do not operate at the same time. ETHERNET Ethernet connectivity with the Link system is available through this port.
  • Page 22 PAGE 18 P1 INSTALLATION Communications Error Codes Modbus Error Codes success illegal function illegal data address illegal data value failure in associated device acknowledge long command "busy, rejected message" NAK - negative acknowledge memory parity error not enough characters CRC error no response Data Highway and DH-485 Error Codes success...
  • Page 23 P1 INSTALLATION PAGE 19 processor is in program mode compatibility mode file missing or communication zone problem remote node cannot buffer command remote node problem due to download cannot execute command due to active IPBs a field has an illegal value less levels specified in address than minimum for any address more levels specified in address than system supports symbol not found...
  • Page 24 PAGE 20 P1 INSTALLATION not enough characters CRC error no response...

  • Page 25: P2 Installation

    P2 INSTALLATION PAGE 21 7. P2 INSTALLATION Figure 188 P2 Module - Front Panel The P2 module provides connectivity between the Link system and a PLC. Communications between the P2 module and the PLC can be done using any the available ports: the RS232 serial port, the RS485 serial port or the PLC Network Ethernet port.
  • Page 26 PAGE 22 P2 INSTALLATION through this port for remote monitoring and emails can be transmitted through this port to a remote server. PLC ETHERNET These two connectors are used for local PLC network connection. Both connectors are bridged internally so the network can be wired through either connector or wired in a daisy-chain configuration in one and out the other.
  • Page 27 P2 INSTALLATION PAGE 23  Blink Green when an EtherNet/IP message is exchanged RS232 Modbus RTU Master  Solid Red – no response  Solid Green – valid response  Solid Yellow – invalid response Modbus RTU Slave  Solid Red – no response ...

  • Page 28: T1 Installation

    PAGE 24 T1 INSTALLATION 8. T1 INSTALLATION STATUS ALARM OUTPUT INPUT OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 RADIO TELCO B1285-T1 Figure 20 T1 Module Front Panel The T1 module provides callout capability on a telephone line and/or a mobile radio port.
  • Page 29 T1 INSTALLATION PAGE 25 Relay Outputs Each of the 4 relays can be configured during programming to provide remote control outputs that are operated by DTMF codes. Figure 22 T1 Input Circuit Telco RJ11 This is the port that connects to a conventional telephone line and is used by the T1 module to place calls and announce alarm messages.
  • Page 30 PAGE 26 T1 INSTALLATION Indicators The indicators are grouped into 3 sections: 1) Status  Flashing Red during startup before a database is received from the main module  Green during normal operations RX/TX  Green on receipt of valid message from the main module ...
  • Page 31 T1 INSTALLATION PAGE 27 3) Output Four, one for each output  Red when the relay is in the on state  Yellow if the relay has failed  Off otherwise...

  • Page 32: W1 Installation

    Touch-Tone set locally or by calling into the module. This module can also be used to transfer a database to the ProTalk Link if the internal cell phone is registered with a data plan through the wireless carrier.
  • Page 33 W1 INSTALLATION PAGE 29 Inputs The eight digital inputs operate with a dry relay contact or open collector to ground as shown in Figure 25. In the open state the input is pulled high internally and in the ground state it is pulled to ground. Figure 25 W1 Input Circuit Relay Outputs Each of the 4 relays can be configured during programming to provide...
  • Page 34 PAGE 30 W1 INSTALLATION  Yellow if the message from the main module has a checksum error. This indicator times out after 400 msec Tone  Green when a tone is being received  Red when a tone is being transmitted ...
  • Page 35 W1 INSTALLATION PAGE 31 SIM Card Installation The B1285-W1 utilizes an embedded GSM cell phone module to make calls. To operate on a wireless network, a valid SIM card (Subscriber Identity Module) must be obtained from your carrier and installed in this module.
  • Page 36 PAGE 32 W1 INSTALLATION Figure 27 Rear View of Modem Module...

  • Page 37: W2 Installation

    A limited amount of programming can also be done using a safety approved Touch-Tone telephone locally or by calling into the module. This module can be used to transfer a database to the ProTalk Link if the internal cell phone is registered with a data plan through the wireless carrier.
  • Page 38 PAGE 34 W2 INSTALLATION Inputs The eight digital inputs operate with a dry relay contact or open collector to ground as shown in Figure 30. In the open state the input is pulled high internally and in the ground state it is pulled to ground. Figure 30 W2 Input Circuit Relay Outputs Each of the 4 relays can be configured during programming to provide...
  • Page 39 W2 INSTALLATION PAGE 35 RX/TX  Green on receipt of valid message from the main module  Yellow if the message from the main module has a checksum error. This indicator times out after 400 msec Tone  Green when a tone is being received ...
  • Page 40 Identification Number) and MDN (Mobile Directory Number) must be obtained from your carrier and programmed into the unit. For programming instructions, refer to Wireless Module Programming in the Handset Programming section or to the ProTalk Link PC software and associated help files.

  • Page 41: W3 Installation

    Touch-Tone set locally or by calling into the module. This module can also be used to transfer a database to the ProTalk Link if the internal cell phone is registered with a data plan through the wireless carrier.
  • Page 42 PAGE 38 W3 INSTALLATION Inputs The eight digital inputs operate with a dry relay contact or open collector to ground as shown in Figure 34. In the open state the input is pulled high internally and in the ground state it is pulled to ground. Figure 34 W3 Input Circuit Relay Outputs Each of the 4 relays can be configured during programming to provide...
  • Page 43 W3 INSTALLATION PAGE 39  Green on receipt of valid message from the main module  Yellow if the message from the main module has a checksum error. This indicator times out after 400 msec Tone  Green when a tone is being received ...
  • Page 44 PAGE 40 W3 INSTALLATION SIM Card Installation The B1285-W3 utilizes an embedded HSPA cell phone module to make calls. To operate on a wireless network, a valid SIM card (Subscriber Identity Module) must be obtained from your carrier and installed in this module.

  • Page 45: Specifications

    SPECIFICATIONS PAGE 41 12. SPECIFICATIONS 12.1 Common module specifications Physical: 8.9 wide x 2.42 high x 4.32 deep Steel, powder coated matte black Mounting ears for panel installation Environmental: -40C to + 60C, 95% humidity, non-condensing Power: +10 VDC to +30 VDC Expander output: DB15 female (top of case to additional expander modules) Expander input: DB15 male (bottom of case to previous expander...
  • Page 46 PAGE 42 SPECIFICATIONS 12.2 Detailed module specifications 12.2.1 M1 Module This module is responsible for the operation of the Link system - consult the Programming section of this manual or the Help section of the LINK.EXE PC application for details on how the M1 module operates. Digital Inputs: 2 total, dedicated as power fail and acknowledge inputs Input Levels: open / ground closure...
  • Page 47 SPECIFICATIONS PAGE 43 Power Failure: Connected to external power fail signal and can be programmed as a digital alarm with ground closure operation. Relay Outputs: Each of the two relays can be programmed to indicate one of these status conditions: New alarm exists Any alarm exists Acknowledge received...
  • Page 48 PAGE 44 SPECIFICATIONS Programmable features Input Calibration: Full scale (current inputs): 20 mA only Full scale (voltage inputs): +5, +10 or +30 VDC Decimal maximum +9999 Decimal minimum -9999 Hysteresis 1% to 25% Delay Time: Millisecond scale 10 to 65530 msec. in 10 msec. steps. Second scale 1 to 65535 seconds.
  • Page 49 SPECIFICATIONS PAGE 45 12.2.4 P1 Module Communications Ports: RS232 (DTE) DB9 or RS485 (2 wire terminal block), selectable Ethernet Programmable Features Major/Minor Alarms: Each of these can be either a major or minor alarm: Ethernet link failure - when the link is lost due to a network disruption or disconnected cable.
  • Page 50 PAGE 46 SPECIFICATIONS Unit ID Each block, consisting of 16 points, is assigned a Unit ID which is the address of the PLC. In slave mode all of the Unit ID values will be the same, changing this value in any block 0 will change all blocks.
  • Page 51 SPECIFICATIONS PAGE 47 19200 38400 57600 115200 PLC Ethernet Network: IP address: set by system administrator Subnet mask: set by system administrator Default gateway: set by system administrator Modbus/TCP Port Number: set by system administrator Email/Web Server Ethernet Network: IP address: set by system administrator Subnet mask: set by system administrator...
  • Page 52 PAGE 48 SPECIFICATIONS Start Address Each block requires a value that represents the starting address of 16 sequential PLC registers. In master mode this address will be the register location in the PLC. In slave mode, the Start Address is automatically assigned starting with 1 in the first location in block 0 then in ascending order through the 32 blocks.
  • Page 53 SPECIFICATIONS PAGE 49 No dial tone - when there is no dial tone because the telco line is not connected or the port has been damaged PTT Warmup: The interval between when the PTT signal is asserted to activate the radio transmitter and the beginning of the message.
  • Page 54 PAGE 50 SPECIFICATIONS Relay Failure - when the contact position does not match the coil setting. Roaming - indicates abnormal phone behavior since the Link is presumably installed at a fixed location. Unknown Cell Status - failure to obtain network connection so there can be no callout actions.
  • Page 55 SPECIFICATIONS PAGE 51 Programmable Features Major/Minor Alarms: Each of these can be either a major or minor alarm: Relay Failure - when the contact position does not match the coil setting Roaming - indicates abnormal phone behavior since the Link is presumably installed at a fixed location Low RSSI - insufficient signal strength to reliably operate the cell phone 11.2.9 W3 Module...
  • Page 56 PAGE 52 SPECIFICATIONS server: Required to use the SMTP server. For Rogers in Canada the default is "internet.com".
  • Page 57 SPECIFICATIONS PAGE 53 12.3 Common alarm specifications Alarm Name: Alarm name contains up to 16 characters to describe the alarm. The name is not used in voice announcements, but is used for messages sent by email, SMS text, in the Monitor operation (that can be accessed by connecting to the main module with this application), or through the internet if a PLC module is in the system.
  • Page 58 PAGE 54 SPECIFICATIONS 12.4 Detailed alarm specifications 12.4.1 Hardware digital alarm types Function: Sets the type of functions that the input will perform and can be one of these 5 types: 1) Digital Input - standard digital alarm 2) Watchdog - alarms unless refreshed Watchdog Timer 2 time scales are available for the watchdog timer Second scale, 66535 seconds maximum...
  • Page 59 SPECIFICATIONS PAGE 55 Millisecond scale 10 to 65530 msec. in 10 msec. steps. Second scale 1 to 65535 seconds. Independent on and off delay settings for each input. Debounce Off Time: Working in reverse to the Debounce On Time, if the input is in alarm and goes to the idle state it must remain there for the Debounce Off time before it is considered to be idle.
  • Page 60 PAGE 56 SPECIFICATIONS Hysteresis is used to determine when the input reading returns to normal after it is in an alarm condition. The value shown here is a percentage of the decimal range (maximum - minimum). For the maximum set point the hysteresis value is subtracted from that set point and for the minimum set point it is added to that set point.
  • Page 61 SPECIFICATIONS PAGE 57 alarm. If the value drops within the set point before the timer has expired, the timer is cleared and no action occurs. 2 time scales are available for the delay timer. Millisecond scale 10 to 65530 msec. in 10 msec. steps. Second scale 1 to 65535 seconds.
  • Page 62 PAGE 58 SPECIFICATIONS Slave Mode 1 – 65535 An alarm occurs if the time Timeout: interval specified in Timeout is exceeded. The timer is restarted when a valid poll is received Scale: 2 time scales are available, seconds or minutes Master Mode Poll Fail Count:...
  • Page 63 SPECIFICATIONS PAGE 59 Units: Totalizers use the same 3 unit controls that are provided for analog alarms to supply the descriptive phrase that is appended to the reading. See section 10.2.3 3) Commwatch - Analog commwatch alarms operate in a similar fashion to a digital commwatch.

  • Page 64: Handset Programming

    PAGE 60 HANDSET PROGRAMMING 13. HANDSET PROGRAMMING The Link is capable of recording voice messages and limited programming using a safety approved Touch-Tone telephone, either locally through the programming port or remotely through a T1, W1, or W2 expander module. In place of the Enter key or carriage return that you would use to enter data from a keyboard, the Link interprets the digits ** as the Enter command.
  • Page 65 HANDSET PROGRAMMING PAGE 61 Programming Summary The codes used in the main programming menu are given as a summary below. Voices (page 50) Directories (page 51) Hardware Configuration (page 53) General Configuration (page 62) Group Configuration (page 64) (not used) Reset Database (page 66) Module Status (page 67) Wireless Module Programming (page 68)
  • Page 66 PAGE 62 HANDSET PROGRAMMING Voices Link: "Enter Voice Code" You: 0** Playback or record voices for Site Name, then Groups 1 to 8 then Block 0 Playback or record voices for Block 1 Playback or record voices for Block 2 ...
  • Page 67 HANDSET PROGRAMMING PAGE 63 Directories Link: "Enter Directory" You: 1** Directory 1 Directory 2    32** Directory 32 Exit to Main Menu Exit to Main Menu Directory Line Refer to the command list that follows for the available directory entries.
  • Page 68 PAGE 64 HANDSET PROGRAMMING Directory Commands Directory programming requires you to enter a sequence of digits that corresponds to a directory line in the PC programming. All of the commands that would appear on that line have to be entered with one string ending in **.
  • Page 69 HANDSET PROGRAMMING PAGE 65 Hardware Configuration Link: "Enter Module Address" You: 0** Address 0 (Main) Note: The switch uses the Address 1 letters A to F to represent    the numbers 10 to 15 15** Address 15 Exit to Main Menu Next module Address 1 Link: "Module Zero is M1"...
  • Page 70 PAGE 66 HANDSET PROGRAMMING General Configuration Link: "Acknowledge Timer is . . ." You: X** Enter new value (0 = off, 1 = 30 min, 2 = 60 min, 3 = 120 min, 4 = 120min) Exit to Main Menu Next setting Link: "Relay voices are .
  • Page 71 HANDSET PROGRAMMING PAGE 67 Link: "Primary Phone Modem Code is . . ." You: X** Enter new DTMF code Exit to Main Menu Next setting Link: "Backup Phone Modem Code is . . ." You: X** Enter new DTMF code Exit to Main Menu Next setting...
  • Page 72 PAGE 68 HANDSET PROGRAMMING Group Configuration Link: "Enter Group Number" You: 1** Group 1 Group 2    Group 8 Exit to Main Menu Exit to Main Menu Link: "Group One is . . ." You: X** Enter new value (0 = off, 1 = on) #** Exit to Main Menu Next setting Link: "Acknowledge Code is .
  • Page 73 HANDSET PROGRAMMING PAGE 69 Link: "On Shift One Use Directory . . ." You: X** Enter new value (1 to 32) #** Exit to Main Menu Next setting    repeats for the number set in Shift Count Link: "On Shift Eight Use Directory . . ." You: X** Enter new value (1 to 32) #** Exit to Main Menu Exit to Main Menu...
  • Page 74 PAGE 70 HANDSET PROGRAMMING Reset Database Link: "Enter Empty Code" You: #31** Link: "Program is Empty"...
  • Page 75 HANDSET PROGRAMMING PAGE 71 Module Status Link: "Enter Module Address" You: 0** Address 0 (Main) Note: The switch uses the Address 1 letters A to F to represent    the numbers 10 to 15 15** Address 15 Exit to Main Menu Next module Address 1 Link: "Module One is {module type or empty}"...
  • Page 76 PAGE 72 HANDSET PROGRAMMING Wireless Module Programming The W1 module is a GSM based module that is configured through a removable SIM module. This program code will only announce the Mobile Number that is assigned to the installed SIM module. The W2 module is a CDMA based module that is pre-configured at the factory except for the assigned Mobile Number.
  • Page 77 HANDSET PROGRAMMING PAGE 73...
  • Page 78 PAGE 74 HANDSET PROGRAMMING 99** Local Handset Callout Link: "beep" You: X** Enter the phone number you want to call If the system has two callout modules (T1, W1, W2 and W3) the call will be placed through the one that is set as primary. Hang-up to end the call.
  • Page 79 HANDSET PROGRAMMING PAGE 75 * ** Query Version Link: "Enter Module Address . . ." You: X** Enter the module address (0 to 15) You: #** Exit to Main Menu You: ** Exit to Main Menu Link: "Module M0 is . . ." (speaks serial number) You: #** Exit to Query Version You: ** Next...

  • Page 80: Warranty Statement

    (2) Exclusive Warranty: The warranty set forth herein is the only warranty, oral or written, made by Barnett Engineering Ltd. and is in lieu of and replaces all other warranties, expressed or implied, including the warranty of merchantability and the warranty of fitness...

  • Page 81: Notices

    WARRANTY STATEMENT PAGE 77 15. NOTICES CSA Certification The ProTalk Link product has 60950-1 safety certification for Canada and USA. Compliance This Class A digital apparatus complies with Canadian ICES-003. This device complies with part 15 of the FCC Rules. Operation is...
