Megapix DWC-MF4Wi4 Manual page 46

Setup -
RTSP Information
1
Target Stream
Select the channel you want to set.
2
Time out
Set the RTSP time out.
The session is disconnected after the specified time out.
3
RTP Multicast
Check RTP Multicast On/Off. To activate RTP Multicast,
1. Click "On" button
2. Enter accessible RTP Multicast IP, port for video stream
control, RTP packet TTL
3. Click "Apply" button.
It is possible to set each RTP Multicast for CH1~3.
4
Click 'Apply' to make above setting effective.
Click this button when completed setup each channels.
5
It shows RTSP Connection information.
46
1
2
3
4
5
