Panasonic PT-56SX30B Service Manual

Service Manual
This Simplified Service Manual is issued to add listed models to the Main Service Manual order No. MTNC000211C1.
(PT-61D30B/CB) A full set of schematics, disassembly procedures, and a complete parts list are included in this
Simplified Manual. Please file and use this Simplified Service Manual together with Main Service Manual, order No.
MTNC000211C1. (PT-61D30B/CB)
"WARNING! This Service Manual is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this Service Manual by anyone else could result in serious injury or death."
The service technician is required to read and follow the "Safety Precautions" and "Important Safety Notice" in the Main Manual.
Color Video Projection System
Simplified Manual
Models
PT-56SX30B
PT-56SX30CB
PT-56D30B
PT-56D30CB
Note:
Appearance may
vary depending on model
.
characteristics
Copyright 2000 by Matsushita Electric Corporation of
America. All rights reserved. Unauthorized copying
and distribution is a violation of law.
®
ORDER NO. MTNC000524A1
B2
(P4C)
Panasonic
Chassis
FP816
FP816
GP816
GP816
