Page 1: Quick Installation Guide
Quick Installation Guide INR-440 200-Channel 12-Bay RAID Rackmount Standalone NVR with Redundant Power Supply... -
Page 3: Before You Start
BEFORE YOU START Thank you for purchasing ACTi Standalone Network Video Recorder. This guide contains all the information you need to quickly set up ACTi INR server system via local interface. For detailed instructions on installation, operation and how to log in to INR as a web client, please refer to the product manuals provided on ACTi corporate website. -
Page 4: Hardware Installation
HARDWARE INSTALLATION UNPACK This package contains: • • Accessory Pack x 2 • INR x 1 • Rail Kit x 1 • Quick Installation Guide x 1 • Warranty Card x 1 AT A GLANCE Front Panel Storage Disk Bays x 12 Smart Panel Rear Panel Power Switch... -
Page 5: Rackmount The Unit
RACKMOUNT THE UNIT This unit is designed to be mounted on a standard server rack, which occupies 2U (3.5″) of vertical space. Install this unit into the rack with the supplied rail kit using the screws provided. Step 1 Step 2 Loosen the screws locked on In the rack, adjust the rails’ length to both rails. -
Page 6: Mount The Disk
INSTALL THE TRAY MOUNT THE DISK Step 4 Step 3 Step 5 Place your thumb on Secure the hard disk Press the hinge tab on the tray with the the key lock to push until it clicks into place. the tray into position in provided disk screws , the chassis. - Page 7 CREATE HARDWARE RAID As this unit supports hardware RAID configuration, you can make disk arrays using the bundled software utility. 1. On Windows Desktop, double-click on the shortcut to initialize the RAID management utility. 2. On Remote servers list, select “INR-Series” and click on “Login“. On logon window, input the credentials and click on “Login“. User Name: administrator Password:...
- Page 8 4. Choose “Simple“ mode and then click on “Next“. 5. Select the RAID level, number of Virtual drives (arrays) and the Capacity of the array, and then click on “Next”. On confirmation window, click on “Finish“ to start building arrays. Standalone NVR Quick Installation Guide...
-
Page 9: Software Configuration
SOFTWARE CONFIGURATION CREATE DISK VOLUMES Use Windows Disk Management to create disk volumes so that INR can access the available storage space. 1. In Windows Search Box, search and enter “computer management”. 2. Select “Disk Management”, right-click on a disk title and select “Initialize Disk”, choose “GPT”... - Page 10 To make a Striped volume, a Mirrored volume or a RAID-5 volume, it is recommended to select disks of the same model and capacity. Note For detailed instructions on choosing the RAID types and troubleshooting hard disk issues, please refer to System Administrator’s manual provided on ACTi Download Center at http://www.acti.com/downloadcenter Standalone NVR Quick Installation Guide...
-
Page 11: Create Users
LOG IN On Windows Destop, double-click on to enter NVR interface. Input the default account and password to log in. Account: admin Password: 123456 “123456” is the default password of NVR administrator’s user account. For security reasons, please remember to replace it with a new one. CREATE USERS On NVR screen, click Setup button to enter Setup page and then Users tab. -
Page 12: Add Cameras
Search Cameras Add Camera Manually Use “Search Cameras” to auto-search If you are adding a camera located the network for ACTi cameras, or in another network, use “Add “Search ONVIF Cameras” for Camera Manually”. Fill in Media ONVIF-compliant cameras of any Type, Protocol, IP Address, HTTP brand. -
Page 13: Configure Camera Settings
3. Drag on the time table to define the time session. 4. Click “Apply“. Note If you have any question during system installation, please feel free to contact our engineers via ACTi Customer Help Desk platform at http://www.acti.com/CHD Standalone NVR Quick Installation Guide... -
Page 14: Customize Views
CUSTOMIZE VIEWS 1. Go to Live View page. On top of the screen, click on view tool bar to create a new layout, then click to enter edit mode. 2. Select a layout style. 3. To add a camera view, pull a camera from Camera List to a channel. To add a map view, select a channel and click , upload the map, drag the lower right corner... - Page 16 Due to continuous product improvements, some contents may have changed from the time this documentation was printed. You can download the latest user documentation, which shall prevail over the printed version http://www.acti.com/downloadcenter provided in the package, from www.acti.com V2015.06.18...
