- Page 1 ENR-1000 User’s Manual For V1.00.02 Firmware 2013/01/30...
-
Page 2: Legal Notice
Disclaimer The information contained in this document is intended for general information purposes. ACTi Corporation shall not be liable for errors contained herein or for incidental or consequential damages arising from the furnishing, performance, or use of this manual. -
Page 3: Regulatory Compliance Information
ENR-1000 User’s Manual Regulatory Compliance Information Federal Communications Commission Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: About This Manual
System Administrators. You may also check the product page http://www.acti.com/ENR1000 for updates and documents. Technical Support If you have any questions during system installation, please feel free to contact our engineers via our Customer Help Desk platform http://www.acti.com/CHD. www.acti.com... -
Page 5: Table Of Contents
ENR-1000 User’s Manual Table of Contents 1 Legal Notice Disclaimer 2 Copyright 2 Trademarks .................... 2 Regulatory Compliance Information ............ 3 2 About This Manual Target Audience ..................4 Technical Support .................. 4 3 Table of Contents 4 Introduction Product Overview .................. 8 ENR Server / Client Architecture ............ - Page 6 ENR-1000 User’s Manual 6 System Overview Main Screens Introduction ..............14 Input Devices ..................15 Virtual Keyboard Overview ............15 7 Monitoring Live View Menu ................... 16 Change Live View Layout ..............17 Watch All Channels ..............17 Watch a Single Channel .............. 17 Layout Patrol ..................
- Page 7 ENR-1000 User’s Manual Reverse playback Change play speed Change Screen Layout ................. 28 Take a Snapshot .................. 29 Export Video ..................29 Set Video Bookmark ................30 9 System Log Search Log .................. 31 Export Log ................... 32 www.acti.com...
-
Page 8: Introduction
Introduction Product Overview ACTi ENR-1000 (hereafter referred to as ENR) is a compact, delicate and reliable 2-bay 4-channel standalone NVR for small-medium sized IP video surveillance system. It features a stable embedded Linux operation system and capabilities of supporting mega-pixel resolution H.264 streaming, an HDMI output for local display, full PTZ control, video motion detection,... -
Page 9: Remote Client Pc Requirements
ENR-1000 User’s Manual Remote Client PC Requirements ENR itself is a self-contained unit. The table below provides basic guidelines only for selecting proper hardware for the remote PC client. PC Spec Minimum Requirements (*1) CPU Processor Intel Core 2 Quad 2.66 GHz... -
Page 10: At A Glance
ENR-1000 User’s Manual At A Glance Front Panel Power Button Reset Button USB 2.0 Ports LED Indicators Rear Panel LAN 2 HDMI Output Power Connector LAN 1 www.acti.com... -
Page 11: Power Button & Reset Button
ENR-1000 User’s Manual Power Button & Reset Button You can turn on/turn off the device with Power Button; with Reset Button, you may restore the device to factory default settings. Turn On the Device Press down the Power Button and release, the Power LED will light up and turn solid blue. -
Page 12: Reset To Factory Default
ENR-1000 User’s Manual Reset to Factory Default By resetting this device, all your system settings will return to factory default, while the previous recording files and system logs are still kept on storage disks. It is strongly recommended that you back up previous settings with Backup function before resetting to factory default. -
Page 13: Login & Logout
ENR-1000 User’s Manual Login & Logout To log into ENR system for the first time, you will have to key in the account name and password in Login window. Please contact your system administrator for account and password information. Log In To enter Live View screen: 1. -
Page 14: System Overview
ENR-1000 User’s Manual System Overview Main Screens Introduction ENR system has two main screens: ●Live View screen, which you will immediately see after logging in. You may watch live streaming, operate the PTZ cameras, take live view snapshots, execute manual recording and access the Setup Menu. -
Page 15: Input Devices
ENR-1000 User’s Manual Input Devices IN ENR system, a USB mouse is the required input device to do all the operations on user interface. All the input devices, including USB mouse and USB keyboard are ready to use when you connect them to ENR via USB 2.0 ports. You may adjust the mouse’s cursor speed via the path below: on Live View screen, right-click to bring up Live View menu ... -
Page 16: Monitoring
ENR-1000 User’s Manual Monitoring You can perform most live monitoring tasks on Live View screen. ENR may display all live channels on the screen, or 1x1 single channel in succession automatically. Aside from keeping an eye on the video, you may also take snapshots, control PTZ cameras, start or stop manual recording on a selected channel. -
Page 17: Change Live View Layout
ENR-1000 User’s Manual Description Layout Styles Click to switch layout styles Single Channel Switch Click to switch to a specific channel in 1x1 layout Take a snapshot The image of current live view layout will be saved as jpg format (at 720x480 resolution) onto the USB mass storage. -
Page 18: Layout Patrol
ENR-1000 User’s Manual Layout Patrol By performing the Patrol function, all the four channels can be displayed by 1x1 layout in turns. 1. On Live View menu, click to swtich to 1x1 layout. 2. Click 3. On Patrol Time Setting window, input the patrol interval (the maximum value is 999 seconds), and the click “OK”. -
Page 19: Single Channel Menu
ENR-1000 User’s Manual Single Channel Menu To start, select a channel by mouse, and the channel menu will appear: Take a Snapshot The image (at original resolution size) of current channel will be saved as jpg format onto the USB mass storage, named as yyyy-MM-dd-hh-mm-ss.jpg. Please make sure the USB mass storage has already been connected to ENR device. -
Page 20: Acknowledge Channel Status
ENR-1000 User’s Manual Acknowledge Channel Status On Live View screen, it is essential to observe the system status events, since unexpected environmental factors or human behaviors may take place, and they might pose security threats to your site. The channel status icons display important camera status and motion alerts for you. -
Page 21: Operate Ptz Camera
ENR-1000 User’s Manual Operate PTZ Camera On ENR Live View screen, you may also use the UI controls to perform PTZ navigation. The preset points move the camera to see pre-defined views; a preset tour is a combination of preset points, which can perform an auto-scan tour. -
Page 22: Go To A Preset Point
ENR-1000 User’s Manual Zoom out (available for cameras with a controllable zoom) Zoom in (available for cameras with a controllable zoom) Near focus (available for cameras with controllable focus) Far focus (available for cameras with controllable focus) Start/Stop Preset Tour... -
Page 23: Playback
ENR-1000 User’s Manual Playback Playback is the service that processes recorded video clips. You may search by time. by event or the bookmarks you have set. Playback may include up to 4 channels synchronized playback. Video clips may also be exported in either RAW or AVI formats. -
Page 24: Event Search
ENR-1000 User’s Manual Click Month or Year to choose exact value Previous Next month month Recording exists No recording exists 2. As the date has been selected, choose the hour from the 24-hour time bar. The color represents the event type of the recording. -
Page 25: Bookmark Search
ENR-1000 User’s Manual 1. Select Event Search tab, and define the start time and a search duration (In the example below, ENR will search recording from 2013/01/23 04:00 to 08:00.) the Cameras and Event Type. 2. Click “Search”. 3. On search result list, select an entry. -
Page 26: Play Back Video
ENR-1000 User’s Manual Play Back Video ENR will start playing back the video after you click “Play” on Playback Search window. Current Playback Time Current Play Speed www.acti.com... -
Page 27: Playback Menu
ENR-1000 User’s Manual Playback Menu On Playback screen, right-click anywhere on screen to bring up the Playback Menu. Description Layout Styles Provided layout styles are 1x1 / 2x2 screen Single Channel Switch Playback Controls Reverse Play Pause Play Increase Play Speed... -
Page 28: Change Play Speed
ENR-1000 User’s Manual Change play speed Increase the play speed by clicking , and decrease the speed by clicking . The provided speed rates are ½ x, 1x, 2x, 4x, 8x, 16x and 32x. The current play speed will be... -
Page 29: Take A Snapshot
ENR-1000 User’s Manual Take a Snapshot On Playback menu, click ,the image of current screen will be saved as jpg format (at 720x480 resolution) onto the USB mass storage. Please make sure the USB mass storage has already been connected to ENR device. -
Page 30: Set Video Bookmark
ENR-1000 User’s Manual 1. Select a channel and click 2. Select the Export Duration and Export Type. 3. Click “Start” The exported video will be saved onto the USB mass storage. Please make sure the USB mass storage has already been connected to ENR device and the available storage space is enough. -
Page 31: System Log
ENR-1000 User’s Manual System Log The activities performed by logged-in Users are recorded on server as System Log. With the access permission to Setup (for how to change the user group permissions, please refer to the User Group section in ENR1000_System_Administrator_Manual), a user may view, search and export this record for analysis or investigation. -
Page 32: Export Log
ENR-1000 User’s Manual Export Log You may export the system log of selected time period as .txt file onto the USB storage disk by clicking “Export”. www.acti.com...
