Page 1: Quick Installation Guide
Quick Installation Guide INR-310 64-Channel 6-Bay Tower Standalone NVR INR-320 64-Channel 6-Bay RAID Tower Standalone NVR INR-330 64-Channel 8-Bay Rackmount Standalone NVR... -
Page 3: Before You Start
For detailed instructions on installation, operation and how to log in to INR as a web client, please refer to the product manuals provided on ACTi corporate website. The items below are prerequisite for installation:... - Page 4 INR-310/320 HARDWARE INSTALLATION UNPACK This package contains: INR x 1 Accessories Warranty Card x 1 Printed QIG x 1 Power Cord x 1 Universal Converter x 1 AT A GLANCE Storage Disks System Disk Power Button USB Ports Power Status...
-
Page 5: Hard Disk Installation
HARD DISK INSTALLATION TURN OFF THIS UNIT before REMOVE THE TRAY you move the trays. Repeat the Step 2 Step 1 Pull the hinge tab to 90 following steps to install the Slide the lock tab up, degress from the front, the hinge tab will pop disks into Storage Disk bays. - Page 6 START-UP 1. On the unit’s front panel, press down Power Button to turn on the unit. 2. As this unit starts up, you will enter Windows logon screen. Input the password “123456“ to log in as administrator. CREATE HARDWARE RAID As INR-320 supports hardware RAID configuration, you can make disk arrays using the bundled software utility.
- Page 7 INR-330 HARDWARE INSTALLATION UNPACK This package contains: INR x 1 Accessories Warranty Card x 1 Printed QIG x 1 Power Cord x 1 Universal Converter x 1 HDD Tray Keys Dust Cover x 1 AT A GLANCE Power Status LED Indicator System Disk (DO NOT REMOVE) Power Button...
-
Page 8: Rackmount The Unit
2. Prepare a rack shelf rated for the unit’s weight or purchase the rail kit from ACTi, and install that to support the entire unit. 3. Secure the unit onto the rack. - Page 9 CONNECT THE DEVICES The example below displays a network consisting of only INR, network cameras and required peripherals. Please remember to enable the DHCP service on your router for INR to obtain an IP assress automatically. Switch Note To assign a static IP address to INR, enter Windows and configure the network settings in Network and Sharing Center.
-
Page 10: Software Configuration
SOFTWARE CONFIGURATION CREATE DISK VOLUMES Use Windows Disk Management to create disk volumes so that INR can access the available storage space. 1. In Windows Search Box, search and enter “ ”. computer management 2. Select “Disk Management”, right-click on a disk title and select “Initialize Disk”, choose “GPT”... - Page 11 Note For detailed instructions on choosing the RAID types and troubleshooting hard disk issues, please refer to System Administrator’s manual provided on http://www.acti.com/downloadcenter ACTi Download Center at Standalone NVR QIG...
-
Page 12: Create Users
LOG IN On Windows Destop, double-click on to enter NVR interface. Input the default account and password to log in. Account: admin Password: 123456 “123456” is the default password of NVR system administrator’s user account. For security reasons, please remember to change it. CREATE USERS On NVR screen, click Setup button to enter Setup page and then Users tab. -
Page 13: Add Cameras
Add Camera Manually Search Cameras Use “Search Cameras” to auto-search If you are adding a camera located in the network for ACTi cameras, or “Search another network, use “Add Camera ONVIF Cameras” for ONVIF-compliant Manually”. Fill in Media Type, Proto- cameras of any brand. -
Page 14: Configure Camera Settings
3. Drag on the time table to define the time session. 4. Click “Apply“. Note If you have any question during system installation, please feel free to contact our engineers via ACTi Customer Help Desk platform at http://www.acti.com/CHD Standalone NVR QIG... -
Page 15: Customize Views
CUSTOMIZE VIEWS 1. Go to Live View page. On top of the screen, click on view tool bar to create a new layout, then click to enter edit mode. 2. Select a layout style. 3. To add a camera view, pull a camera from Camera List to a channel. To add a map view, select a channel and click , upload the map, drag the lower right corner... - Page 16 Due to continuous product improvements, some contents may have changed from the time this documentation was printed. You can download the latest user documentation, which shall prevail over the printed version http://www.acti.com/downloadcenter provided in the package, from www.acti.com...
