4.

Applied Model

◩ (Fig_01) MODEL : MSF-390
.1
2
3
4
5
1 OIL IN-LET
2 SEPARATOR
3 ELECTRIC CONTROL BOX
4 PRESSURE GAUGE
5 TROLLEY WHEEL
6 CONNECTION
7 DISCHARGE VALVE(STOP VALVE)
8 OIL OUT-LET
9 3STAGE SAFETY VALVE
18
6
7
8
17
16
9 10
10 DRAIN VALVE (MANUAL)
11 RUBBER
12 HANDLE
13 MOTOR
14 DISCHARGE FILTER HOUSING(MP21)
15 PRESSURE HOSE
16 OIL GAUGE
17 SAFETY PULLEY NET
18 SUCTION FILTER
- 9 -
AIR COMPRESSOR MANUAL
15
14
13
12
11
