5. Installation

General Notice
The compressor should be connected to an 16 Ampere plug.
Note: Check direction of rotation immediately after the first start. If the direction of rotation
is wrong, the pistons may adhere to the piston sleeve due to the lack of lubrication!!
Furthermore, the unit would not be cooled properly. When facing the front of he
compressor (water separator side), the direction of rotation should be clockwise (check
arrows on compressor block and cover). Don't place compressor closer than 0.5 m to any
walls and ensure good ventilation.
5-1 Installation area must
￭ be well-ventilated.
￭ keep out of the sun, snow and rain.
￭ have little effect on the weather.
￭ be flat ground.
5-2 Requirements for environmental condition
￭ No erosion.
￭ No the inflammables.
￭ No explosive gas.
￭ Clean area.
￭ No an interference around the Compressor.
￭ Stay away at least 500mm from walls for the COOLING & MAINTENANCE of Compressor.
￭ Install the SUCTION FILTER outside(if possible).
￭ Install the engine ventilation opening and suction filter to be the maximum distance.

6. Operation

6-1 The user position of the Compressor
￭ Be located near the STOP SWITCH of Compressor
6-2 The check condition of a trial run
￭ Check the electric current complied with the electrical specifications of motor.
￭ Check the hindrance around rotating area.
￭ Check the oil capacity.
￭ Check the filter location if it is keep out of the sun, snow and rain or not.
￭ Check the tightness of bolt and the leakage of air
￭ Check the tension of BELT.
￭ Be well acquainted with preventive maintenance check list.
