AF6 Commercial
Deluxe Upright
Cleaner
Read these
instructions before
operating the
cleaner
Index
Assembling Cleaner ..........................2-5
Cleaner Description ..........................6
Cleaning Tools ..................................7
Upright Cleaner ..............................6-7
If You Have a Problem ........................11
Clearing Blockages ........................12
Important Safeguards ..........................1
Authorized Service ..........................11
Lubrication ......................................11
Replacing Belt ................................10
Replacing Brush Roll ................10-11
Replacing Filter Bag ......................8-9
Replacing Final Filter ........................9
Serial number______________________
(Located on bottom of cleaner as shown)

Important Safeguards

When using an electrical appliance, always follow
basic precautions, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
Warning:
• Do not use outdoors or on wet surfaces.
• This appliance is provided with double insulation. Use only identical replacement
parts. See instructions for servicing double insulated appliances.
• Close supervision is necessary when any appliance is used by or near children.
Do not allow vacuum cleaner to be used as a toy or to run unattended at any time.
• Keep hair, loose clothing, fingers, feet and all parts of body away from openings,
rotating agitator and other moving parts. Do not operate cleaner in bare feet or
when wearing open toe shoes or sandals.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches, or
hot ashes.
• Do not use to pick up flammable or combustible materials such as gasoline or fine
wood sandings or use in areas where they may be present.
• Avoid picking up hard, sharp objects with the cleaner. They may damage the cleaner
and the bag.
• Do not use without dust bag or filters in place. Change bag frequently when picking
up very fine materials such as powder.
• Use extra care when cleaning on stairs.
• Do not put any object into openings. Do not use with any opening blocked; keep
free of dust, lint, hair, or anything that may reduce air flow.
• Do not pull or carry by cord, use cord as a handle, close door on cord or pull cord
around sharp edges or corners. Do not run appliance over cord. Keep cord away
from heated surfaces.
• Always disconnect cord from electrical outlet before servicing the cleaner.
• Unplug cleaner when not in use. Turn off all controls before unplugging.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord. Never
handle plug or appliance with wet hands.
• The use of an extension cord is not recommended.
• Do not use with damaged cord or plug. If appliance is not working as it should, has
been dropped, damaged, left outdoors, or dropped into water, take it to a Triple S
Authorized Dealer.
• Use vacuum cleaner only for its intended use as described in the instructions.
Use only attachments recommended by Triple S; others may cause hazards.

Save these instructions!

DOUBLE INSULATED: When servicing, use only
identical replacement parts.

Operating Instructions

ENGLISH
ESPAÑOL
FRANÇAIS
To reduce the risk of fire, electric shock, or injury:
pp.1-12
pág 14-20
p. 22-28

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AF6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Triple S AF6

Summary of Contents for Triple S AF6

  • Page 1: Table Of Contents

    • Do not use with damaged cord or plug. If appliance is not working as it should, has Replacing Belt ........10 been dropped, damaged, left outdoors, or dropped into water, take it to a Triple S Replacing Brush Roll ....10-11 Authorized Dealer.

  • Page 2: Assembling Cleaner

    Assembling cleaner It is extremely important to read and follow all the instruction steps in order. Carton contents Remove all parts from carton and identify each item shown. Note that some of the items are shipped together in the sealed bag with the owner’s manual.
  • Page 3 Step 2 Attach cord With (E) pointing downward, press groove (F) into slot Rotate cord protec- (G). tor (E) as shown (toward back of Pull cord tight. handle). With side marked “UP” visible, insert large rectangular end of cord into pocket in bottom of handle.
  • Page 4 Step 4 Attach bag compartment 1-14 1-13 1-12 Pull bag door latch forward and Slide large tab (N) on bottom of bag Note round opening and hooks (P) remove door. Set bag door aside. housing into slot between the brack- on back of bag compartment.
  • Page 5 Step 6 Position tools 1-22 1-20 1-21 Open tool cover. Position dusting brush (V), Raise handle to upright position. Position wand,with smaller diameter furniture nozzle (W), and crevice Bring hose toward front of cleaner end down, at side of cleaner as tool (X), into tool storage area and stretch hose over hose rack.

  • Page 6: How To Use

    The assembled cleaner will look like the 2. How to use drawing. 1. Handle Cleaner description 2. ON/OFF switch 3. Cord hooks: wrap cord around hooks for storage. The top hook can be rotated for easy cord release. 4. Furniture nozzle 5.

  • Page 7: Cleaning Tools

    Return the control to the correct setting when cleaning floors. Do not leave the control in the Cleaning Tools setting when cleaning floors. Place end of hose firmly into tool rack for CLEANING TOOLS 5 BARE FLOOR LOW peak performance when cleaning carpets. For maximum cleaning performance, the following carpet height settings are recommended.

  • Page 8: Replacing Filter Bag

    2-10 2-11 2-12 How to attach tool cover B. Select proper clean- C. Attach wand and ing tool The tool cover is designed with a tools “break-away” feature which allows it to The tools are attached to the hose or the A.

  • Page 9: Replacing Final Filter

    Where to buy Filter bags may be purchased from a When to replace Triple S Authorized Dealer. Check filter bag from time to time. It is recommended that you change the filter bag when dirt reaches the bottom of the When ordering bags, be sure to give bag collar.

  • Page 10: Replacing Belt

    To assure effective operation, use only Place handle in low position and turn cleaner over. genuine Triple S belts with your cleaner. When purchasing a new belt, Remove the 4 screws as shown with a ask for part No. 38528040.

  • Page 11: If You Have A Problem

    Fig. 3-16 to reposition belt, new brush To obtain approved Triple S service and • No voltage in wall receptacle roll and bottom plate. genuine Triple S parts, contact a Triple S • Check fuse or breaker Authorized Dealer. • Blown fuse/tripped breaker Edge groomer •...

  • Page 12: Clearing Blockages

    3. Continue with Fig. 3-16 to reposition belt, brush roll and bottomplate. If a blockage is not found and a Removing hood problem persists, contact a Triple S 2. Using a phillips head screwdriver, Authorized Dealer. remove the 4 hood screws (A) and lift off carpet height control (B).

  • Page 14: Importantes Medidas De Seguridad

    Concesionario de servicio de garantía de Triple S. • Use la aspiradora sólo para su uso específico según se describe en las instrucciones. Use solamente los accesorios recomendados por Triple S; otros pueden ser un riesgo. © 2001 ¡Guarde estas instrucciones!

  • Page 15: Ensamblado De La Aspiradora

    Compare las instrucciones la fig. 1-3. Al apretar las partes del sión, sobre la base de la aspiradora. numeradas de cada sección mango mientras se las une, no Mueva el mango de lado a lado, mien- en español con los diagramas coloque las manos en los extremos tras lo empuja con firmeza.

  • Page 16: Cómo Usar

    rotando mientras el mango de la NOTA: Para minimizar el riesgo de 1-17 aspiradora se mantenga en posición choque eléctrico, este aparato tiene un Empuje la bolsa de papel vertical. Evite inclinar la aspiradora o enchufe polarizado (una pieza es más firmemente contra el tubo.

  • Page 17: Accesorios De Limpieza

    Accesorios de limpieza Los accesorios se añaden a la de limpieza”. manguera o al tubo de extensión de la Vuelva a colocar el seleccionador en la Los accesorios le permiten limpiar misma manera. posición correcta cuando limpie los superficies por encima de los pisos y pisos.

  • Page 18: Para Reemplazar Correas

    papel, y sacúdala hasta que quede Para reemplazar limpia. Al ordenar las bolsas, asegúrese la correa de dar el número de modelo de su La correa de su aspiradora hace rotar el aspiradora. agitador y es importante para el eficaz Para volver a colocar la pinza de Qué...

  • Page 19: Si Tiene Algún Problema

    Problema: La accesorios de las, pida la pieza No. 48414-061. To obtain approved Triple S service and limpieza no succionan genuine Triple S parts, contact a Triple S Cómo reemplazarlo Authorized Dealer. Causa posible Desconecte la aspiradora de la toma Posible solución...

  • Page 20: Para Desatascar Obstrucciones

    Concesionario Autoriza- limpiadora de su aparato. do de Triple S. Siga los siguientes pasos para rastrear las obstrucciones, continuando con cada paso hasta encontrarlas. A. Si la obstrucción ocurre mientras se está...
  • Page 22 à un atelier de service garanti autorisé Triple S. • N’utiliser cet aspirateur que conformément à son usage prévu, tel que décrit dans le présent guide. N’utiliser que les accessoires recommandés par Triple S ; d’autres accessoires pourraient s’avérer dangereux.
  • Page 23 Utiliser les instructions numérotées de cile, vérifier les points suivants : cette section française avec les illustra- En s’assurant que le côté marqué • le positionnement correct de l’at- tions numérotées correspondantes de « UP » est visible, insérer la grosse tache (Fig.
  • Page 24 rainures du compartiment. tion et mettre l’appareil en marche. Placer le manche à la verticale, puis tirer sur 2. Utilisation S’assurer que tous les rebords du sac celui-ci jusqu’à ce que le devant de se trouvent à l’intérieur du comparti- l’appareil (B) s’élève au dessus du tapis.
  • Page 25 • Réglage 5 : pour utilisation avec le 3. Entretien tuyau et les accessoires seulement. A. Réglage de *Note : S’il est difficile de déplacer la hauteur l’appareil pendant le nettoyage, régler Faire glisser le sélecteur jusqu’à Débrancher l’aspirateur de la prise sur la position supérieure à...

  • Page 26: Remplacement De La Courroie

    38766017. faisant glisser son extrémité face à la Les sacs filtrants peuvent être achetés courroie dans la rainure rectangulaire (E) auprès d’un détaillant autorisé Triple S. sur le côté de l’appareil. Remplacement de la Au moment de commander, assurez- Mettre l’autre côté du rouleau-brosse (F) courroie vous d’indiquer le numéro de modèle...
  • Page 27 • Mauvais réglage de la hauteur de pièces authentiques, contactez votre ne touchent pas le carton. tapis. détaillant autorisé « Triple S ». • Régler la commande de hauteur selon Quelle courroie acheter? le tapis à nettoyer. Au moment de demander des renseigne- Au moment d’acheter un nouveau...
  • Page 28 Vérification du tuyau et remise en place du couvercle 4. Vérifier si le tuyau ou la base de l’ap- pareil, à l’entrée du tuyau, est obstrué. Si tel est le cas, enlever l’objet qui obstrue le passage. 5. Replacer le couvercle du conduit et les 4 vis.
