- Page 1 USER MANUAL CTS700 TOUCH BY NILAN Compact P / Compact P Polar (English) Version 2.00 - 03.10.2016...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Important information ..................................................Power supply ....................................................Heat pump domestic hot water ........................................... Disposal ..........................................................Ventilation system ..................................................Heatpump ......................................................Quickguide Safety switch ....................................................... Emergency stop ventilation ............................................The control panel ....................................................Front page elements ................................................Front page setting options ............................................... - Page 3 Compact P / Compact P Polar (English) BY NILAN CE declaration Compact P / Compact P Polar ............................................
-
Page 4: Important Information
Responsibility for maintenance of the heat pump rests with the owner/user. Disposal Ventilation system Nilan units mainly consist of recyclable materials. They should therefore not be disposed of with household refuse. Take them to your local recycling centre. Heatpump Conserning disposal og units with heat pumps, it ist important to contact the local authorities for information about correct handling of these. -
Page 5: Quickguide Safety Switch
Compact P / Compact P Polar (English) BY NILAN Quickguide Safety switch Emergency stop ventilation If the ventilation has been stopped for a lengthy period, condensation will occur in the duct system. This occurs when the warm air in the dwelling penetrates into the cool ducts. This presents the risk that the water will drip out of the ceiling valves, damaging floors and furniture. -
Page 6: The Control Panel
The control panel Front page elements The front page of the touch-panel contains the settings and information a user normally need. 1. Show the actual temperature in the house, measured by the extract air or an external temperature sensor 2. Show the actual outdoor temperature, measured in outdoor air intake 3. -
Page 7: Front Page Setting Options
Compact P / Compact P Polar (English) BY NILAN Front page setting options The settings which the user need in daily use, can be changed on the front page. 1. By touching the actual room temperature, the wanted room temperature is shown. You can change the wanted room temperature, by touching the red or blue arrow. -
Page 8: Information
Information By touching the information button, you get an overview about the actual operation state of the unit. -
Page 9: Warnings And Alarms
Compact P / Compact P Polar (English) BY NILAN Warnings and alarms If an error in the unit occurs, a warning or an alarm will be shown in the user-panel A warning is a yellow button, which tells you to notice something etc. filter or anode must be changed. -
Page 10: Settings Menu Overview
Settings menu overview The setting menu is build in a way, which makes it easy to use. Ventilation: Here are settings made concerning the ventilation of the house. Domestic hot water production: Here are settings made concerning the domestic hot water production.. -
Page 11: User And Installer Rights
• Settings with a white lock can only be set by installers • Settings with a red lock can only be set by Nilan The reason why some settings is locked for the user, is because to change them you need some knowledge about how the unit works, and if they are set wrongly the unit does not work properly and can be damaged. -
Page 12: Service And Maintanance Maintenance
Maintenance Regular maintenance Your Nilan ventilation unit will last for many years if it is correctly maintained. Correct maintenance will also ensure that the unit runs optimally at all times with low energy consumption. In the following we point out the regular maintenance which you can perform yourself and the annual service which should be carried out by a professional. -
Page 13: Illustration Of Filter Change
Compact P / Compact P Polar (English) BY NILAN Illustration of filter change 1. Set the unit to stand-by on the control panel in the 2. Turn the thumb screws in the door at the top right of "Filter settings" menu under Ventilation before opening the unit and open the door the door. -
Page 14: Water Trap
Water trap If the water trap in the condensate outlet dries out, air will blow into the unit. This will prevent condensate from draining away. Instead it will accumulate in the condensate tray. When there is no space left in the condensate tray, it will run over, possibly causing water damage on the floor. The water trap must therefore be checked at regular intervals and filled with water. -
Page 15: Service
Compact P / Compact P Polar (English) BY NILAN Service Annual service It is important to perform an annual service on the unit to ensure it will continue to perform optimally with low energy consumption and long service life. You are recommended to take out a service agreement with the installer, as certain elements of the service require an authorised technician. -
Page 16: Check Ventilation Ducts
If roof stacks have been fitted to the air intake and outlet, check that they are not blocked with birds' nests, leaves or other dirt which can hamper air passage. If, instead of roof stacks, grilles have been mounted in facades or eaves, check that they are not clogged with leaves or dirt. -
Page 17: User Settings Ventilation
Compact P / Compact P Polar (English) BY NILAN User settings Ventilation Filter settings The filter alarm has a timer which is set at the factory to give 90 days between filter changes. Supply air filters and extract air filters are set separately. The unit leaves the factory with a G4 standard filter, but an F7 pollen filter can be purchased for the outdoor air. -
Page 18: Operating Mode
Operating mode It is possible to provide the unit with an input which determines whether it will operate in Auto, Heating or Cooling. Ventilation Operating mode Settings: Auto / Heating / Cooling Standard setting: Auto Description: Auto: The unit operates in according with the set values. -
Page 19: Humidity Control
Compact P / Compact P Polar (English) BY NILAN Humidity control The primary purpose of ventilation is to remove humidity from the home to avoid damages to the building, and simultaneously, to achieve good indoor air quality for the residents. During longer periods fo sub-zero temperatures, air humidity in the home may fall to a level which is critical for the building and the indoor climate. -
Page 20: Settings Active Cooling
Settings active cooling Depending on architecture, the home may require cooling in summer. Compact P has an integral heat pump, primarily used for production of domestic hot water. The heat pump has a reversible cooling cycle, and in summer is able to cool the supply air while simultaneously producing domestic hot water. Thus, in principle, the cooling is "free of charge". - Page 21 Compact P / Compact P Polar (English) BY NILAN 1. User program 2 and 1 with high priority for ventilation User program 2 2. High ventilation in connection with cooling User program 1 3. Low ventilation in connection with low outdoor air...
-
Page 22: Ventilation At Times Of Low Outdoor Air Temperature
Ventilation at times of low outdoor air temperature It is possible to prevent low humidity in the home by reducing ventilation in case of low outdoor temperatures. This function can be used in countries with heavy frosts and at high altitudes where the outdoor air is very dry. -
Page 23: Co2 Control
Compact P / Compact P Polar (English) BY NILAN control ATTENTION A CO sensor is not standard in all units, but may be purchased as an accessory. If the occupancy varies greatly, it may be better to control ventilation by the CO -level in the extract air. -
Page 24: Reading Off Temperatures
Reading off temperatures Here all temperature sensors can be read off. Ventilation Temperature sensor overview ↳ TExt room temperature (°C) Description: Indicates the room temperature measured by an external room sensor (only if connected) ↳ Status Description: Indicates whether sensor is in working order (OK / Error / Absent). -
Page 25: Domestic Hot Water
Compact P / Compact P Polar (English) BY NILAN Domestic hot water DHW standby function It is possible to set hot water production on standby for a period between 1 and 180 days. In this way, energy on heating the domestic hot water can be saved when on holiday, or in closed holiday cabins during the winter months. -
Page 26: Dhw Settings Domestic Hot Water Production
DHW settings domestic hot water production Settings for hot water production have been set at the factory, but it may be necessary to adjust them to match the user´s needs. Domestic hot water DHW domestic hot water ↳ Hot water settings ↳... -
Page 27: Dhw Anti Legionella
Compact P / Compact P Polar (English) BY NILAN DHW anti legionella The control has an antigral anti-legionella function for destroying any legionella in the hot water tank. Domestic hot water DHW domestic hot water ↳ Anti legionella settings ↳ Start anti legionella manually... -
Page 28: Dhw Reading Off Temperatures
DHW reading off temperatures Here the temperature sensors in the hot water tank can be read off. Domestic hot water DHW hot water tank ↳ Temperature overview ↳ T11 top temperature (°C) Description: Shows the temperature at the top of the hot water tank. -
Page 29: General Settings
Compact P / Compact P Polar (English) BY NILAN General settings Display settings The brigtness of the display can be adjusted. It is also possible to set the display to shut down after a time to save energy. General settings Display settings ↳... -
Page 30: Week Programme
Week programme It is possible to programme the unit to run in accordance with specific settings at fixed times of the week via a weekly programme. General settings Week program ↳ List of week programmes Description: This shows a list of weekly programmes. ↳... -
Page 31: Information
Compact P / Compact P Polar (English) BY NILAN Information Event log Warnings, alarms or changes to settings can be read off in the event log. It is also possible to reset warnings and alarms in this menu. Information Event log ↳... -
Page 32: Compact P All Device Data
Compact P all device data Overview of the current data for Compact P ventilation and hot water production. Information Compact P all device data ↳ Software version Description: Shows software versions installed. ↳ Product Shows the name of the product the software is Description: programed for. - Page 33 Compact P / Compact P Polar (English) BY NILAN ↳ T1 outdoor temperature Shows the current outdoor temperature, if no external Description: preheating element is fitted. ↳ T2 supply air temperature Description: Shows supply air temperature without after-heating element. ↳ T3 extract air temperature Description: Shows the room temperature.
- Page 34 CE declaration Compact P / Compact P Polar...
- Page 35 Compact P / Compact P Polar (English) BY NILAN...
