Grandstream Networks, Inc.
DP715_US/DP710_US
IP DECT Phone
DP715_US/DP710_US User Manual
www.grandstream.com
Firmware Version 0.0.0.8
http://esupport.grandstream.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP715 US and is the answer not in the manual?

Questions and answers

Related Manuals for Grandstream Networks DP715 US

Summary of Contents for Grandstream Networks DP715 US

  • Page 1 Grandstream Networks, Inc. DP715_US/DP710_US IP DECT Phone DP715_US/DP710_US User Manual www.grandstream.com Firmware Version 0.0.0.8 http://esupport.grandstream.com...

  • Page 2: Table Of Contents

    PGRADE THROUGH : ................41 NSTRUCTIONS FOR PLOAD FROM OCAL IRECTORY TFTP : ............41 NSTRUCTIONS FOR LOCAL FIRMWARE UPGRADE USING SERVER ....................... 41 ONFIGURATION OWNLOAD Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 2 of 38 Firmware 0.0.0.8 Last Updated: 01/2012...
  • Page 3 4. S CREENSHOT OF ROFILE ONFIGURATION 5. S CREENSHOT OF TATUS SCREENSHOT OF OGIN PAGE SCREENSHOT OF EBOOT PAGE 8. S CREENSHOT OF EBOOTING PAGE Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 3 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 4: Dp715-Us/Dp710-Us User Manual

    Reproduction or transmittal of the entire or any part, in any form or by any means, electronic or print, for any purpose is not permitted without the express written permission of Grandstream Networks, Inc. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 4 of 43 Firmware 0.0.0.8...

  • Page 5: Installation

    2. Connect the network socket on the underside of the base unit to the network connection socket using the Ethernet cable provided. 1. Network socket 2. Network cable 3. Underside of the base unit 4. Cable from the power supply plug Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 5 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 6: Setting Up The Charging Station

    4. To charge the rechargeable batteries for the first time, place the handset in the base unit or charging unit for 16 hours. The Charge/In use indicator (LED) on the base unit lights up. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 6 of 43 Firmware 0.0.0.8...

  • Page 7: Table 2: Definitions Of The Dp71X Connectors

    0.25sec ON/ 0.25sec OFF registration failure. LED-10 Call is active. Any DECT handset is in an active call with Call an external line. LED-11 No active call. Call Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 7 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 8: Product Overview

    Independent SIP account per handset station Multiple handsets per SIP account HTTP, HTTPS, TELNET, TFTP, TR-069 (pending), secure and automated Provisioning provisioning, syslog Security Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 8 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...
  • Page 9 ETSI EN 301 489-6 V1.3.1 ETSI EN 301 406 V1.5.1 Efficient use of Frequency Spectrum CENELEC EN 50360:2001-07 Health CENELEC EN 50385:2002-08 Directive 2009/125/EC (EuP) Regulation 278/2009 Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 9 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 10: Controls And Menu Structure

    The batteries are only 25% charged. • The batteries are almost flat. The battery icon in the display flashes and the “Battery Low!” message appears. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 10 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 11: Symbols

    Their current function is shown directly above in the display. The most important display key functions are: Phone book Mute function OK/Confirm Previous Menu Cancel Delete Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 11 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 12: Menu Structure

    Ring Tone Ringer Volume Handset Name Keypad Beep Handset Contrast Auto Talk Select Base Language Registration Set Alarm Time Set Time Format Appointment Tools Stop Watch Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 12 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 13: Handset - Settings And Operation

    • Move closer to the base unit. • The no longer flashes and is shown steadily. • You are back within the base unit's range. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 13 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 14: Completing Calls

    To call a number from the phonebook: 1. Press 2. The first number in the phonebook appears on the display. 3. Press to browse the phonebook. 4. Press Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 14 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 15: Answering Calls

    If the calls list is empty and you press , Calls List Empty appears. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 15 of 43 Firmware 0.0.0.8...
  • Page 16 5. All calls are deleted. Note: Only the old calls are deleted. New calls, i.e. calls that have not been read or answered, are retained. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 16 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 17: The Phonebook

    2. Enter the initial letter of the name required using the alphanumeric keys and/or scroll to the entry required. 3. Press Option. 4. Scroll with to Delete Entry? to delete the current entry only. 5. Or Delete All to delete all entries. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 17 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 18: Handset Functionality

    You can choose between 5 different settings. The default setting is level 3: Volume 1 Volume 2 Volume 3 Volume 4 Volume 5 Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 18 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...
  • Page 19 8. Press repeatedly, to select the desired melody. 7. Press Save to confirm your selection, or press to quit the menu without saving the setting. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 19 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...
  • Page 20 7. Press Save to set the new handset name. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 20 of 43 Firmware 0.0.0.8...
  • Page 21 (18 melodies) and press Save. b. Delete to delete the selected appointment. Press to confirm or to cancel. 6. Switch the appointment reminder off when it sounds by pressing Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 21 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 22: Understanding Dp715 Voice Prompt

    TFTP / HTTP / HTTPS Firmware Version Firmware version information. Firmware Upgrade Firmware upgrade mode. Press “9” to toggle among the following three options: Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 22 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 23: Direct Ip Calls

    “***” 2. Dial “47” to access the direct IP call menu 3. Enter the IP address after the dial tone and voice prompt “Direct IP Calling” Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 23 of 43 Firmware 0.0.0.8...

  • Page 24: Call Hold

    4xx response for the INVITE and we will try to recover the call. The busy tone is just to indicate to the transferor that the transfer has failed. c. Continuous busy tone: The phone has timed out. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 24 of 43 Firmware 0.0.0.8...

  • Page 25: 3-Way Conferencing

    Send Caller ID (for all subsequent calls) Direct IP Calling. Dial “*47” + “IP address”. No dial tone is played in the middle. Detail see Direct IP Calling section on page 12. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 25 of 43 Firmware 0.0.0.8...

  • Page 26: Base Station - Configuration Guide

    Select voice menu option 14 to configure the IP address of the configuration server. PGRADE ROTOCOL Select voice menu option 15 to choose firmware and configuration upgrade protocol. User can choose between TFTP and HTTP. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 26 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 27: Browser

    If you plan to keep the DECT phone within a private network behind a firewall, we recommend using STUN Server. The following three (3) settings are useful in the STUN Server scenario: Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 27 of 43 Firmware 0.0.0.8...

  • Page 28: Table 7: Basic Settings

    DHCP hostname Default is blank. This option specifies the name of the client. This field is optional but may be required by some Internet Service Providers. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 28 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...
  • Page 29 Note: After you choose the reset type, you will have to click the reset button for it to take effect. In addition to the Basic Settings configuration page, end users also have access to the Device Status page. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 29 of 43 Firmware 0.0.0.8...

  • Page 30: Advanced User Configuration

    Advanced User configuration includes the end user configuration and the advanced configurations including: a) SIP configuration, b) Codec selection, c) NAT Traversal Setting and d) other miscellaneous configuration. DP715 has two (2) profiles for the four (5) Handset DP710. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 30 of 43 Firmware 0.0.0.8...

  • Page 31: Table 9: Advanced Settings

    Firmware File Prefix Default is blank. If configured, DP715 will request firmware file with the prefix. This setting is useful for ITSPs. End user should keep it blank. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 31 of 43 Firmware 0.0.0.8...
  • Page 32 OFF should be zero. Otherwise it will ring ON ms and a pause of OFF ms and then repeat the pattern. Example configuration for N.A. Dialtone: f1=350@-13,f2=440@-13,c=0/0; Syntax: f1=freq@vol, f2=freq@vol, c=on1/off1-on2/off2-on3/off3; [...] (Note: freq: 0 - 4000Hz; vol: -30 - 0dBm) Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 32 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...
  • Page 33 Primary RADIUS Auth Default is 1812. Specifies the port to be used for the Primary RADIUS Authentication. Port Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 33 of 43 Firmware 0.0.0.8...

  • Page 34: Table 10: Profile Settings

    “User=Phone” parameter will be attached to the “From header” in the SIP request to indicate the E.164 number. If server supports TEL URI format, then this option needs to be selected. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 34 of 43 Firmware 0.0.0.8...
  • Page 35 Default is No. If set to yes, flash will be sent as DTMF event. Enable Call Features Default is Yes. (If Yes, call features using star codes will be supported locally) Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 35 of 43 Firmware 0.0.0.8...
  • Page 36 2 and 9, followed by any 7 digit number OR Allows any length of numbers with leading digit 2, replacing the 2 with 011 when dialed. 3. Default: Outgoing – {x+} Allow any length of numbers. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 36 of 43 Firmware 0.0.0.8...
  • Page 37 UAS Specify As a Callee, select UAC to use caller or proxy server as the refresher, or UAS to Refresher use the phone as the refresher. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 37 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 38: Table 11: Dp715 Handsets Settings

    Hunting Group that is not registered with a SIP account, will be able to place outbound calls using the SIP credentials of the primary Hunting Group Handset. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 38 of 43 Firmware 0.0.0.8...

  • Page 39: Saving The Configuration Changes

    At boot-up, Grandstream devices by default point to Grandstream provisioning server GAPS, based on the unique MAC address of each device, GAPS provision the devices Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 39 of 43 Firmware 0.0.0.8...

  • Page 40: Software Upgrade

    Grandstream’s latest firmware is available at http://www.grandstream.com/support/firmware Oversea users are strongly recommended to download the binary files and upgrade firmware locally in a controlled LAN environment. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 40 of 43 Firmware 0.0.0.8 Last Updated: 03/2012...

  • Page 41: Instructions For Upload From Local Directory

    When Grandstream Device boots up or reboots, it will issue request for configuration file named “cfgxxxxxxxxxxxx”, where “xxxxxxxxxxxx” is the MAC address of the device, i.e., “cfg000b820102ab”. The configuration file name should be in lower cases. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 41 of 43 Firmware 0.0.0.8...

  • Page 42: Dp715-Us/Dp710-Us User Manual Firmware

    2. Locate a needle-sized hole on the back panel of the gateway unit next to the power connection. 3. Insert a pin in this hole, and press for about 7 seconds. 4. Take out the pin. All unit settings are restored to factory settings. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 42 of 43 Firmware 0.0.0.8...

  • Page 43: Handset

    FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 43 of 43 Firmware 0.0.0.8...
  • Page 44 —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Privacy of communications may not be ensured when using this telephone! Grandstream Networks, Inc. DP715-US/DP710-US User Manual Page 44 of 43 Firmware 0.0.0.8...
