Quickcheck - TWO DIMENSIONAL INSTRUMENTS TV2 Quick Start Manual

The QuickCheck screen indicates the safe/unsafe condition of room pressure, temperature and
humidity at all times. If all the numbers are green the room is safe, but if any of them appear red
the clean room should not be used that condition is corrected.
Condition
Pressure
Temperature
Humidity
Alarm
Max/Min
Battery Icon
If any condition (pressure, temperature or
humidity) is red, it is outside the safe
conditions and the room should not be
used.
Safe limits are set in the alarm menu of
each sensor.
P O Box 159 • Crestwood, KY 40014 • (502) 243-0042 • (502) 243-0039 fax

QuickCheck

If Green
OK Do not use room until positive pressure is restored
OK
OK
Alarms set
OK Condition was unsafe in the past – Reset by touching
Charged
www.e2di.com
If Red
Adjust thermostat
Check humidity control
Enable alarms (sensor setup menu)
No action required – it will charge itself
