Welcome to the Repeater/Cross- Repeater Family!
Thank you for purchasing a Repeater/Cross- Repeater! We appreciate your business, and we
think you'll appreciate the many ways that your Repeater/Cross- Repeater system will save
you money, time, and effort.
That's because our Repeater/Cross- Repeater allows, to double the total allowed distance of a
DVXi KVM Extender system for remotely locating a console (DVI-monitor, keyboard and
mouse).
Wherever long distances are usual, e.g. airports, industrial plants, call- centres or in
distributed computer centres, the Repeater/Cross- Repeater is the best way, to solve all
problems in remotely locating your console. 6 different types are available: There are three
types for repeating the signals and doubling the distance and three types to extend the
distance and simultaneously convert from one medium to another (e.g. CATx to Multimode).
This manual will tell you all about your new Repeater/Cross- Repeater, including how to
install, operate, and troubleshoot it. For an introduction to the Repeater/Cross- Repeater, see
Chapter 2. The Repeater/Cross- Repeater product codes covered in this manual are:
Repeater Devices
K471-CT:
K471-MM:
K471-SS:
Cross- Repeater Devices
K471-CM:
K471-DM:
K471-CS:
K471-DS:
K471-MS:
Rev. : 09/25/2012
CATx Repeater to double the distance to up to 280m
Multimode Repeater double the distance to up to 800m
Singlemode Repeater double the distance to up to 20km
CATx/Multimode Cross Repeater; distance CATx up to 140m, Multimode
up to 400m
CATx/Multimode Dual Cross Repeater; distance CATx up to 140m,
Multimode up to 400m
CATx/Singlemode Cross Repeater; distance CATx up to 140m,
Singlemode up to 10.000m
CATx/Singlemode Dual Cross Repeater; distance CATx up to 140m,
Singlemode up to 10.000m
Multimode/Singlemode Cross Repeater; distance Multimode up to 400m,
Singlemode up to 10km
REPEATER/CROSS- REPEATER
1
Advertisement
Table of Contents
Related Manuals for Ihse K471-CT
Summary of Contents for Ihse K471-CT
- Page 1 For an introduction to the Repeater/Cross- Repeater, see Chapter 2. The Repeater/Cross- Repeater product codes covered in this manual are: Repeater Devices K471-CT: CATx Repeater to double the distance to up to 280m K471-MM: Multimode Repeater double the distance to up to 800m...
- Page 2 REPEATER/CROSS- REPEATER Copyrights and Trademarks ©2009. All rights reserved. This information may not be reproduced in any manner without the prior written consent of the manufacturer. Information in this document is subject to change without notice and the manufacturer shall not be liable for any direct, indirect, special, incidental or consequential damages in connection with the use of this material.
- Page 3 EMPTY PAGE Rev. : 09/25/2012...
- Page 4 2004/108/EG Council Directive on the approximation of the laws of the Member States relating to electromagnetic compatibility CE-marking 2009 Product list: K471-CT, K471-MM, K471-SS K471-CM, K471-DM, K471-CS, K471-DS, K471-MS Conformity to the Directives is assured through the application of the following standards:...
- Page 5 SAFETY PRECAUTIONS AND INSTALLATION GUIDELINES Safety Precautions and Installation Guidelines To ensure reliable and safe long-term operation, please note the following installation guidelines: • Do not use CATx-devices to link between buildings – please use fibre devices. • Only use in dry, indoor environments. •...
-
Page 6: Table Of Contents
REPEATER/CROSS- REPEATER Contents 1. Quick Setup 2. Overview Introduction Glossary Example of a Repeater/Cross- Repeater System Features Product Range How to Use This Guide 3. Installation Package Contents Interconnection Cable Requirements System Setup Device Views Diagnostics 4. Service Setup Setup at the Repeater/Cross- Repeater installation instruction 5. -
Page 7: Quick Setup
QUICK SETUP 1. Quick Setup This section briefly describes how to install your Repeater/Cross- Repeater system. Unless you are an experienced user, we recommend that you follow the full procedures described in the rest of this manual. Install system Connect Local unit to CPU or switch. Connect Local unit to Repeater and Repeater to Remote Unit using matching interconnection cable (CATx or Fiber) Connect Remote unit to KVM. -
Page 8: Glossary
REPEATER/CROSS- REPEATER Overview 2.1 Introduction A KVM Extender is used, to extend the distance between a CPU and its Keyboard / Monitor / Mouse considerably. The allowed distance is limited by the physics and the make of the cables. If the total distance expires the allowed distance, Repeater may double the total allowed distance. -
Page 9: Example Of A Repeater/Cross- Repeater System
OVERVIEW 2.3 Example of a Repeater/Cross- Repeater System Installation as Repeater to double the total allowed distance Installation as Cross- Repeater for inhomogeneous cable path Rev. : 09/25/2012... -
Page 10: Features
REPEATER/CROSS- REPEATER 2.4 Features The Repeater/Cross- Repeater offer the following features: • Support for DVXi KVM- and Media- Extender (all devices) • Support for Draco™ KVM- and Media- Extender (all devices) • When installing the Repeater device in the middle of a link, it will allow to double the total distance. -
Page 11: Product Range
OVERVIEW 2.5 Product Range Repeater/Cross- Repeater K471-CT CATx Repeater to raise the total allowed distance to up to 280m K471-MM Multimode Repeater to raise the total allowed distance to up to 800m K471-SS Singlemode Repeater to raise the total allowed distance to... -
Page 12: Installation
REPEATER/CROSS- REPEATER 3. Installation For first-time users, we recommend that you carry out a test placement, confined to a single room, before commencing full installation. This will allow you to identify and solve any cabling problems, and experiment with the Repeater/Cross- Repeater more conveniently. 3.1 Package Contents You should receive the following items in your extender package (all types): •... -
Page 13: Interconnection Cable Requirements
INSTALLATION 3.2 Interconnection Cable Requirements To install the Repeater/Cross- Repeater you will need: • CATx Cable: Recommended cable: S/UTP (Cat5) according EIA/TIA 56A, TSB 36 or Digital STP 17-03170. Four pairs AWG 24. connection according EIA/TIA 568A (10BaseT). Use of cables from a higher category (Cat5e, Cat6, Cat7) is possible.. The use of unshielded CATx Cable is possible, because of the higher electromagnetic noise/sensitivity the device class may not be reached, the compliance with CE regulations is... -
Page 14: System Setup
REPEATER/CROSS- REPEATER 3.3 System Setup To install your Repeater/Cross- Repeater system: Switch off all devices. Connect the interconnect cable to the INTERCONNECT socket(s) of the Local Unit and the Repeater/Cross- Repeater Connect the interconnect cable to the INTERCONNECT socket(s) of the Remote Unit and the Repeater/Cross- Repeater If you have bought a Cross Repeater, your device will have two CATx connectors but only one fiber connector. -
Page 15: Device Views
INSTALLATION Device Views To Local Unit To Remote Unit 5V universal switch mode p.s.u. Repeater/Cross- Repeater CATx view To Local Unit To Remote Unit Repeater/Cross- Repeater Fiber view Rev. : 09/25/2012... -
Page 16: Diagnostics
REPEATER/CROSS- REPEATER 3.5 Diagnostics Each Repeater/Cross- Repeater is fitted with three indicator LEDs: Power, Data Error, Link Status: The Power LEDs are next to the Power socket. The location of the LEDs is shown below: Diagnostic LED Diagnostic LED Diagnostic LED Diagnostic LED Link Status Power... -
Page 17: Service Setup
SERVICE SETUP Service Setup For most applications, you shouldn't need not to make any adjustments to set up your Repeater/Cross- Repeater. Under some special circumstances it could be necessary to setup configuration specials. For some applications, you may need to open the Local Unit and/or the Remote Unit. Unscrew the Philips-type screws at both sides at the bottom of the device. -
Page 18: Setup At The Repeater/Cross- Repeater
REPEATER/CROSS- REPEATER 4.1 Setup at the Repeater/Cross- Repeater After unscrewing and opening the upper shell, please place the device in this orientation: with the CATx/fiber connectors to the left and the Fiber connectors to the right (eventually not equipped with GBICs). The main PCB then will look like this: JPA B Use the diagram to locate jumpers. - Page 19 SERVICE SETUP Operating mode Dualhead Cross- Repeater If you want to alter the mode of operation after the date of purchase, e.g. to use it as a Dualhead Cross- Repeater, you need (probably) to install optical Transceiver (GBICs) and reconfigure the device. Operating mode JPA B Dualhead Cross- Repeater Local CATx...
- Page 20 REPEATER/CROSS- REPEATER CATx / Fiber Cross- Repeater Local Local Unit Remote Remote Unit The Local Unit is connected via CATx (Fiber) connector A, The fiber connector B is connected to the fiber connector A of the second Repeater. The Remote Unit is connected via CATx (Fiber) connector B.
-
Page 21: Troubleshooting
TROUBLESHOOTING Dualhead Cross- Repeater Local Unit Remote Unit The Cross Repeater look the same for the Local and the remote placement. Because of internal jumper settings the data direction is fixed. Please note to install the device, marked with „Cross Repeater Local CATX“ at a position where the CATx cable link to the Local Unit and the device, marked with „Cross Repeater Remote CATx“... -
Page 22: Appendix A: Example Applications
REPEATER/CROSS- REPEATER Appendix A: Example Applications This section illustrates some specific applications using the Repeater/Cross- Repeater: • Repeater in Industrial Plant to raise the allowed distance of the interconnection Repeater in Industrial Plant Rev. : 09/25/2012... - Page 23 APPENDIX A: EXAMPLE APPLICATIONS • Repeater/Cross- Repeater in public buildings. In some environments – especially public buildings - , the signal path may be inhomogeneous. This means, a part might be based on CATx, another part in Multimode. The Cross- Repeater hereby allow to convert from one medium to another, without laborious regaining the original signals and resending them.
- Page 24 REPEATER/CROSS- REPEATER • Repeater/Cross- Repeater for interconnection of two buildings. It is not allowed according VDE to make the interconnection of two buildings with CATx Cables. Because of this, the interconnection must be done in fiber. A server from the server room shall be connected with the user console in the plant.
-
Page 25: Appendix B: Rack Mount Options
APPENDIX B: RACK MOUNT OPTIONS Appendix B: Rack Mount Options Repeater/Cross- Repeater units can be mounted in a 19” rack using the mounting kit. Mounting Instruction Rackmount-Kit 473-5G Using the Rackmount-Kit 473-5G, up to 4 devices of the device size 80x110x29mm can be mounted into a 19“-Server Rack. - Page 26 REPEATER/CROSS- REPEATER The Rackmount- Kit 473-5G allows, to mount a different count of devices (1…5 pieces): Einbau 1 Gerät Einbau 2 Geräte mounting 1 device mounting 2 devices Einbau 3 Geräte Einbau 4 Geräte mounting 3 devices mounting 4 devices Einbau 5 Geräte mounting 5 devices Rev.
-
Page 27: Appendix D: Calling Technical Support
APPENDIX D: CALLING TECHNICAL SUPPORT Appendix D: Calling Technical Support If you determine that your Repeater/Cross- Repeater is malfunctioning, do not attempt to alter or repair it. It contains no user-serviceable parts. Contact Technical Support at. Before you do, make a record of the history of the problem. We will be able to provide more efficient and accurate assistance if you have a complete description, including: •... -
Page 28: Appendix F: Specifications
REPEATER/CROSS- REPEATER Appendix F: Specifications Power 90-240VAC-0.5A-47-63Hz/5VDC-2000 mA Voltage Repeater/ Cross- Repeater Unit : max. 5V/750mA Power required operation mode CATx – Repeater: ca. 500mA operation mode Fiber Repeater ca. 300mA operation mode Cross Repeater ca. 750mA Interface (Depending on type of device) Multimode or Singlemode –... - Page 29 APPENDIX F: SPECIFICATIONS Maximum Length of Interconnection Cable (Fiber - LC Connectors) 10.000m (32.750ft) Singlemode 9 µm 400m (1.300ft) Multimode 50µm 200m (650ft) Multimode 62.5µm Size and Shipping Weight Repeater/Cross- Repeater 80 x 110 x 29mm (3”x4.3”x1.1”) Weight: 0,2kg (0.6lb) 165x165x110mm (6.5”x6.5”x4.3”) Shipping box Weight: 0.6 kg (1.3lb)
-
Page 30: Appendix G: Connectors
REPEATER/CROSS- REPEATER Appendix G: Connectors Repeater/Cross- Repeater Connector Pin outs Power Supply Signal inner outer CATx- Interface Pin out according to EIA/TIA 568A (1000BaseT). Rev. : 09/25/2012... - Page 31 NOTES...
