- Page 1 INSTALLATION INSTRUCTIONS ELECTRIC DRYER FOR MODELS: 3RLEC8600, 3RLEQ8033, 3RLEQ8600 W10115523B...
-
Page 2: Table Of Contents
Table of Contents INSTALLATION INSTRUCTIONS ......... 7 DRYER SAFETY................2 Install Vent System ..............7 INSTALLATION REQUIREMENTS ..........3 Install Leveling Legs ............... 7 Tools and Parts ................3 Electrical Connection ............. 7 Location Requirements.............. 3 Level the Dryer ............... 7 Electrical Requirements ............ -
Page 3: Installation Requirements
INSTALLATION REQUIREMENTS Tools and Parts Location Requirements Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here. Tools needed level sealing gun ■ ■ and compound 200 to 250 mm (8" or 10") knife ■... - Page 4 A level floor with a maximum slope of 25 mm (1") under entire ■ dryer. If slope is greater than 25 mm (1"), install Extended Dryer Feet Kit. Clothes may not tumble properly and models with automatic sensor cycles may not operate correctly if 310 cm dryer is not level.
-
Page 5: Electrical Requirements
Exhaust dimensions Recommended Earthing Method It is your responsibility to contact a qualied electrical installer ■ to ensure that the electrical installation is adequate and in conformance with all local codes and ordinances. Venting Requirements 10 mm 108 mm (4") ") 359 mm 260 mm... -
Page 6: Plan Vent System
Flexible metal vent must be fully extended and supported when 2. Determine vent length. the dryer is in its final position. Remove excess flexible metal vent The maximum length of the exhaust system depends upon: to avoid sagging and kinking that may result in reduced airflow The type of vent (rigid metal or flexible metal). -
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS Install Vent System Electrical Connection 1. Install exhaust hood. Use sealing compound to seal exterior wall opening around exhaust hood. 2. Connect vent to exhaust hood. Vent must fit inside exhaust hood. Secure vent to exhaust hood with 102 mm (4") clamp. 3. -
Page 8: Connect Vent
(see rating plate in door opening for full model details) 220-240V ~ 50 Hz, 1 ph 4575W, IP24 Clothes capacity: 9.0 Kg max. W10115523B © 2009 Whirlpool Corporation. 6/09 All rights reserved. Printed in U.S.A. ® Registered Trademark/TM Trademark of Whirlpool, U.S.A.
