- Page 1 P3 Lift Controllers 3007-2F (2 floors, two shafts) 3007-4F (4 floors, two shafts) Page 1...
-
Page 2: Important Safety Notes
IMPORTANT SAFETY NOTES Please read this manual carefully before attempting to install, program or operate the Progeny access control equipment. This equipment must be installed in line with all relevant regulations and standards. Make sure that wiring is rated according to fuses and current limits of relevant power supplies. -
Page 3: Table Of Contents
Connecting to the Lift Control Box ................. 7 Lock Relay Wiring Key (Clean Contact) ..............7 Network Connections ....................8 Connecting the P3 lift controller to a P3 or P3.net controller....... 8 Reset Button ......................8 Control Board LEDs ....................8 SPECIFICATIONS ................ -
Page 4: Introduction
The P3 Lift Controllers are available as either 2 floor, 2 shaft controllers (3007-2F) or 4 floor, 2 shaft controllers (3007-4F). The lift controllers can be added to an existing P3 system allowing for lift access to be controlled with a single reader in the lift cab. -
Page 5: What's In The Box
What’s in the Box? When opening the box you should have the following: 3007-2F (2 floor, 2 shaft) 1 x 3007-2F (Steel enclosure with cam lock containing two pre-wired lift controllers) 2 x Cam lock keys 3007-4F (4 floor, 2 shaft) 1 x 3007-4F (Steel enclosure with cam lock containing four pre-wired lift controllers) 2 x Cam lock keys Page 5... -
Page 6: Installation
Installation Mounting The optimum location for the controller depends on the application. As a general guide: Always mount the control equipment on the secure side of a door. Mount as close as possible to the lift control panel to be controlled. ... -
Page 7: Connecting To The Lift Control Box
When connecting the reader, it is only necessary to connect the positive connection to the first controller. The 0V from the reader should be connected to each controller in turn. Connecting to the Lift Control Box The output relays which are being used on each lift control circuit board should be used to interact with the lift control box. Due to there being a wide variance in lift control box design, the lift control documentation should be consulted to determine what signal from the lift controller is required. -
Page 8: Network Connections
Note that boards that have the PIC soldered on to the PCB are version 3.35) have the network connections identified with “A” and “B” simply connect A to A and B to B. When connecting a P3 lift controller to an earlier V1.xx or 2.xx P3 controller then the connections are marked “RX”... -
Page 9: Specifications
SPECIFICATIONS Controller Parameters Event Memory 2000 time date stamped Time Zones Time elements Calendars Card Channel Cards with host site code Up to 10,000 Custom Card Formats 36 as standard + user defined Reader Technologies Proximity, Wiegand, Barcode, Magstripe, Biometric. “Reader A”... -
Page 10: Safety Notes And Disclaimers
Safety Notes and Disclaimers Please read this manual carefully before attempting to install, program or operate the Progeny Chameleon access control equipment. This equipment must be installed in line with all relevant regulations and standards. This equipment should be powered by a power supply classed as SELV, as defined in BS EN 60950.
