Page 2
Telesis, Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesis, Inc. has been...
Page 3
Electrical Safety and Emissions Standards U.S. Federal Communications Commission Interference Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 4
European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment This Allied Telesis RoHS-compliant product conforms to the European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment. Allied Telesis ensures RoHS conformance by requiring supplier Declarations of Conformity, monitoring incoming materials, and maintaining manufacturing process controls.
Page 5
Translated Safety Statements Important: The indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” on the Allied Telesis web site at http:// www.alliedtelesis.com/support.
Page 8
Contents Inserting the Rubber Feet ............................59 Chapter 5: Wiring the DC Connectors ........................... 61 Required Materials and Tools............................62 Connecting the Grounding Wire ..........................63 Connecting the 48/60VDC or -48/-60VDC and RETURN Wires.................. 66 Monitoring the Switch Initialization Process......................... 71 Chapter 6: Installing SFP and SFP+ Transceivers ......................
Page 9
Figures Figure 1: AT-IE510-28GSX-80 Front Panel..........................20 Figure 2: AT-IE510-28GSX-80 Back Panel ..........................20 Figure 3: AT-IE510-28GSX-80 Management Panel ......................21 Figure 4: SFP Slot LEDs ..............................26 Figure 5: SFP+ Slot LEDs ..............................27 Figure 6: Switch ID LED ...............................28 Figure 7: Switch ID LED ...............................29 Figure 8: Switch ID LEDs in the Low Power Mode .......................30...
Page 10
Figures Figure 51: Moving to the Global Configuration Mode with the CONFIGURE TERMINAL Command........93 Figure 52: Activating VCStack with the STACK ENABLE Command ...................93 Figure 53: Returning to the Privileged Exec Mode with the EXIT Command ...............94 Figure 54: Saving the Change with the WRITE Command....................94 Figure 55: Rebooting the Switch with the REBOOT Command....................94 Figure 56: Removing the Dust Plug from the S1 Slot ......................96 Figure 57: Removing the Dust Cover from a TwinAx Cable ....................97...
Stacking (VCStack™). This preface contains the following sections: “Document Conventions” on page 14 “Contacting Allied Telesis” on page 15 Note The IE510 series switch requires AlliedWare Plus™ version 5.4.5 or later. The switch will not function with earlier versions of the...
Preface Document Conventions This document uses the following conventions: Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. Warning Warnings with the high voltage symbol inform you that performing or omitting a specific action may result in bodily injury.
AT-IE510 Series Installation Guide Contacting Allied Telesis If you need assistance with this product, you may contact Allied Telesis technical support by going to the Support & Services section of the Allied Telesis web site at www.alliedtelesis.com/support. You can find links for...
Chapter 1 Overview This chapter contains the following sections: “Feature Overview” on page 18 “Front and Back Panels” on page 20 “Management Panel” on page 21 “SFP+ Slots” on page 22 “Stacking Slots for VCStack” on page 23 ...
Stacking Slots Two of the SFP+ slots can be used to create a VCStack of up to four switches. The slots support any Allied Telesis SPF+ module. For information on virtual chassis stacking, see Chapter 2, “Virtual Chassis Stacking” on page 35.
AT-IE510 Series Installation Guide LEDs The port LEDs are: Link/activity LEDs for SFP and SFP+ slots Stack ID number LED eco-friendly button turns off the LEDs to conserve electricity Installation The installation options for the switch are: Options 19-inch or 23-inch equipment rack ...
AT-IE510-28GSX-80 SFP Slots Management Panel Alarm Ports SFP+ Slots SFP+ or Stacking Slots Figure 1. AT-IE510-28GSX-80 Front Panel Figure 2 shows the back panel of the switch. Grounding Post DC Power DC Power Connector Connector (Power Supply 2) (Power Supply 1)
AT-IE510 Series Installation Guide Management Panel Figure 3 identifies the components in the management panel on the switch. Console Management Port Switch ID LED eco-friendly Button USB Port Figure 3. AT-IE510-28GSX-80 Management Panel...
The switches support a variety of short and long distance SFP and SFP+ modules. For a list of supported SFP modules, contact your Allied Telesis representative.
AT-IE510 Series Installation Guide Stacking Slots for VCStack The front panel of the switch contains four SFP+ slots. Slots 27 and 28 can be used to build a VCStack of up to four switches. The switches of a VCStack act as a single virtual unit. They synchronize their actions so that switching operations, like spanning tree protocols, virtual LANs, and static port trunks, span across all the units and ports.
Chapter 1: Overview Alarm Ports The switch contains two alarm ports: One for alarm input and one for alarm output. Each alarm port contains three contact points. The alarm ports use RJ-45 connectors. To connect either the alarm input or alarm output, use 24 to 18 AWG cable properly rated for the deployment environment.
AT-IE510 Series Installation Guide eco-friendly Button You may turn off the port LEDs to conserve electricity when you are not monitoring the switch. The LEDs are toggled with the eco-friendly button on the front panel of the switch or the ECOFRIENDLY LED and NO ECOFRIENDLY LED commands in the Global Configuration mode of the command line interface.
Chapter 1: Overview LEDs Here are descriptions of the LEDs. LEDs for the SFP The LEDs for the SFP slots are located between the slots, as shown in Figure 4 on page 26. Each SFP slot has one LED. The left-hand LED is for Slots the top slot and the right-hand LED is for the bottom slot.
AT-IE510 Series Installation Guide SFP+ Slot LEDs Figure 5. SFP+ Slot LEDs The LEDs are described in Table 2. Table 2. SFP+ Slot LEDs State Description Link/Activity The slot is empty, the SFP or SFP+ transceiver has not established a link to a network device, or the LEDs are turned off.
Chapter 1: Overview Table 3. Stacking Slot LEDs State Description Link/Activity The slot is empty, the transceiver has not established a link to a network device, or the LEDs are turned off. To turn on the LEDs, use the eco-friendly button. Solid green The transceiver has established a link at 10 Gbps to another switch in the stack.
AT-IE510 Series Installation Guide The switch is booting up. The switch has encountered a fault condition. The switch is operating as a stand-alone unit, with the ID number 0. The switch has an ID number of 1 to 4 as part of a VCStack. The dot in the lower right corner flashes when the switch accesses USB memory.
Chapter 1: Overview The switch is the master switch of a VCStack. The switch is operating as a stand-alone unit. The switch is a member switch of a VCStack. Figure 8. Switch ID LEDs in the Low Power Mode...
AT-IE510 Series Installation Guide USB Port The management panel has a USB port. You may use the port to store configuration files on flash drives and to restore configuration files to switches whose settings have been lost or corrupted, or to quickly configure replacement units.
Chapter 1: Overview Console Port The Console port is used to establish a management session with the switch to configure its features and parameter settings. This type of management uses serial RS-232 and is commonly referred to as local or out-of-band management because it is not conducted over your network.
AT-IE510 Series Installation Guide Power Supplies The switch is powered on or off by connecting or disconnecting the power cords. Please review the following information concerning the power supplies: The switch has two pre-installed DC power supplies. The pre-installed DC power supplies have separate connectors on ...
Chapter 1: Overview Specifying Ports in the Command Line Interface The command line interface in the management software uses the PORT parameter to specify the individual ports. The format of the PORT parameter is: port1 Stack ID Module ID Port Number Figure 9.
Chapter 2 Virtual Chassis Stacking The sections in this chapter are: “Benefits of VCStack” on page 36 “Stacking Slots” on page 37 “Stacking Port Topologies” on page 38 “Master and Member Switches” on page 42 Note This chapter provides an overview of the Virtual Chassis Stacking (VCStack) feature, which allows you to connect up to four switches to form a virtual switch where the devices function as a single...
Chapter 2: Virtual Chassis Stacking Benefits of VCStack The benefits of the VCStack feature are: Simplifies management - You can manage the devices of the stack as a single unit, rather than individually. Your local and remote management sessions automatically give you management access to all the devices.
AT-IE510 Series Installation Guide Stacking Slots The switch comes with two stacking slots. The slots are the last two SFP+ slots on the switches and are labeled “S1/27” and “S2/28” on the switch. The slots have two functions. You can use them with the VCStack feature to build a stack of switches, or you can disable the VCStack feature and use them as additional networking slots.
Chapter 2: Virtual Chassis Stacking Stacking Port Topologies There are two possible wiring topologies when you use the S1/27 and S2/ 28 slots to build a VCStack. The first topology is called the linear topology. In this topology the switches are connected with a single pathway. A transceiver in one switch is connected to a transceiver in the next switch, which is connected to the next switch, and so on.
AT-IE510 Series Installation Guide Figure 11. Stack of Four Switches in the Linear Topology The second topology is called a ring topology. It is similar to the linear topology, except that the unused stacking ports on the end switches of the stack are connected to form a physical loop.
Chapter 2: Virtual Chassis Stacking Figure 12. Stack of Two Switches in the Ring Topology Figure 13 is an example of a stack of four switches in the ring topology.
AT-IE510 Series Installation Guide Figure 13. Stack of Four Switches in the Ring Topology The topologies are the same in terms of network speed and performance. However, the ring topology is the recommended wiring configuration because of the secondary path through the stacking ports. The two pathways protect the switches of the stack against the loss of communications due to a failure of a stacking port, cable, or switch.
Chapter 2: Virtual Chassis Stacking Master and Member Switches The stack has one master switch. The functions of the master switch include: Coordinating and monitoring stack operations. Verifying that the switches are using the same version of management software. It automatically downloads its management software over the stacking cables to switches with different software versions.
AT-IE510 Series Installation Guide ID Numbers Each switch must be assigned an ID number. The range is 1 to 4 and the default is 1. The ID numbers are displayed on the ID LEDs on the front panels of the units. You can assign the numbers yourself or you can let the master switch assign the numbers automatically.
Chapter 3 Beginning the Installation The chapter contains the following sections: “Reviewing Safety Precautions” on page 46 “Choosing a Site for the Switches” on page 50 “Planning a Stack” on page 51 “Unpacking the Switch” on page 52 ...
Chapter 3: Beginning the Installation Reviewing Safety Precautions Please review the following safety precautions before beginning the installation procedure. Note Safety statements that have the symbol are translated into multiple languages in the Translated Safety Statements document at www.alliedtelesis.com/support. Warning Class 1 Laser product.
Page 47
AT-IE510 Series Installation Guide Warning Do not work on equipment or cables during periods of lightning activity. Warning This equipment must be earthed. The ground lug on the switch must be connected to a properly earthed bonding point. Note Ground resistance from the building primary bonding point to earth should be less than 25 ohms.
Page 48
